- Page 1 ANALOG ADDRESSABLE PHOTOELECTRIC SMOKE DETECTOR IP 212-34A DIP-34A-03-S User’s Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Description and Operation ....................5 Purpose ........................5 Specifications ....................... 6 Scope of Delivery......................7 Arrangement and Operation ..................7 Measuring Instruments, Tools, and Accessories ............9 Marking ........................9 Packaging........................9 Intended Use........................10 Operating Restrictions ....................10 Preparing for Use ....................... - Page 3 This User’s Manual (the full version) explains the principles and rules of operating IP 212-34A DIP-34A-03-S Analog Addressable Photoelectric Smoke Detector (hereinafter referred to as the detector). Only the personnel who have studied this manual are allowed to operation activities. All activities on mounting, start-up, programming, and testing shall be performed in compliance with the requirements of the regulatory documentation in force at the place of operation.
-
Page 4: Description And Operation
S2000-KDL-2I, S2000-KDL-2I rev.01, S2000-KDL-S as a component of Orion ISS. The detector communicates data and consumes power via a two-wire multiplex addressable polling loop. 1.1.3 The IP 212-34A DIP-34A-03-S detector features extended operating temperature range. 1.1.4 The detector is intended for round-the-clock operation. -
Page 5: Specifications
Specifications Table 1.2.1 Parameter Value 1.2.1 Power input voltage (from the polling loop), V 8 through 11 1.2.2 Consumed current, mA, max 1.2.3 The number of detectors per a single polling loop, pcs. Up to 127 1.2.4 Maximum effective resistance of the polling loop wires, ohms, 1.2.5 Minimum insulation resistance between the polling loop wires, kilo-ohms, min 1.2.6 Start-up time, s, max... -
Page 6: Scope Of Delivery
MK-8 Mounting Kit* to improve ingress protection up to the IP44 degree — Wire cage* to protect against mechanical damage — Documentation: IP 212-34A DIP-34A-03-S Analog Addressable Photoelectric Smoke Detector. 1 pc. Operations Manual. * – Supplied by separate order Arrangement and Operation 1.4.1 The detector is composed of a printed circuit board, a disassemblable enclosure, and a mount... - Page 7 As a laser tester, one can use laser DIP-Test manufactured by Bolid, System Sensor testers, TEKO Astra-942, and Rubezh OT-1 testers. 1.4.2 The detector meets the requirements of Appendix “Р” of the Russian code of rules “СП5.13130.2009”. The detector answers to requests for levels of smoke concentration and contamination in the smoke chamber.
-
Page 8: Measuring Instruments, Tools, And Accessories
Measuring Instruments, Tools, and Accessories While mounting, commissioning, and maintaining the detector, please use the instruments, tools, and accessories shown in Table 1.5.1 Table 1.5.1 Instrument Specifications AC/DC voltage up to 500 V, AC/DC current up to 5 A, resistance Digital multimeter up to 2M Ohm Flat head screwdriver... -
Page 9: Intended Use
Intended Use 2.1 Operating Restrictions The design of the detector doesn’t provide its operation in aggressive and / or dusty environments as well as in explosion hazardous and flammable premises. Correct performance of the detector cannot be guaranteed if electromagnetic environment does not meet the requirements defined in Section 1.2 of this manual. - Page 10 Overall dimensions are presented on the side view, in Figure 2.2.2.2 and on the bottom view, in Figure 2.2.2.3. Figure 2.2.2.2 Figure 2.2.2.3...
-
Page 11: Mounting The Detector
The mounting dimensions for the detector are shown in Figure 2.2.2.4. Figure 2.2.2.4 2.2.3 Mounting the Detector While considering mounting location for the detectors, please be guided by actual national codes and mounting rules for fire detectors, for example, by the code of practice “СП 484.1311500.2020”, in particular by the requirements shown in the table 2. -
Page 12: Wiring
2.2.4 Wiring Figure 2.2.4.1 shows the typical diagram for wiring the detector into the polling loop of a PL controller with specifying number of terminals of the mount base. The first terminal of the detector base can be used to connect a shield of the connecting wire. Figure 2.2.4.1 Figure 2.2.4.2 For leading wires up to the mount base, on its side surface there are weak spots shown in... -
Page 13: Indication
2.2.6 Indication Table 2.2.6.1 shows the operation modes of the detector and the relevant local indication patterns. The pattern period is 4 s, the number of steps in the pattern is 8, and the time between steps is 0.5 s. Table 2.2.6.1 Indication Pattern Operation Mode... -
Page 14: Using The Detector
The parameter Analysis Delay after Reset should be selected not less the value specified in Table 2.2.7.1. Table 2.2.7.1 Input Type 21: Fire Request Type Analysis Delay after Reset 8 seconds 2 seconds To get more detailed information about input types and setting them in the controller configuration, please refer to the operating documentation for the polling loop controller and UProg Configuration Tool utility. -
Page 15: Extreme Situation Actions
2.3.2 Extreme Situation Actions Warning! If sparks, fire, smoke, or smell of burning is found at the installation site of the detector, the detector must be de-energized and sent for repair 2.3.3 Troubleshooting Table 2.3.3.1 Symptom Possible Cause Solution Check the voltage between the No power is applied mount base contacts 2 and 5 No LED indication... -
Page 16: Maintenance
3.3.2 On receiving a Service Required message from the detector, one should clean the sensing chamber. The description of the dust remove routine can be found online at the Bolid website. 3.3.3 Operability of the detector is to be tested in line with Section 3.4 of this manual. -
Page 17: Technical Examination
Claims shall be submitted to the following address: NVP BOLID, #4 Pionerskaya Str., Korolyov, Moscow Region, 141070, Russia Phone: +7 (495) 775-71-55, E-mail: info@bolid.ru. In case of any issue related to use of the detector, please contact the technical support: +7 (495) 775-71-55 or e-mail: support@bolid.ru. -
Page 18: Manufacturer Warranty
ЕАЭС N RU Д-RU.РА02.В.28332/24. DIP-34A-03-S detector meets the requirements of Technical Regulations of Custom Union TR CU 020/2011 ‘Electromagnetic Compatibility of Technical Equipment’ and is covered by the conformity declaration ЕАЭС N RU Д-RU.РА02.В.28335/24.
