Air curtain: Recessed Optima
INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Please, read these instructions carefully before attempting installation
¡Attention, Danger, Safety Advice!
Injuries risk!
Important information.
SAFETY WARNING SYMBOLS
Danger from electric current or high voltage!
Danger! Do not stay underneath: Heavy load.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Airtecnics Recessed Optima
Summary of Contents for Airtecnics Recessed Optima
- Page 1 Air curtain: Recessed Optima INSTALLATION, OPERATION AND MAINTENANCE MANUAL Please, read these instructions carefully before attempting installation SAFETY WARNING SYMBOLS Danger from electric current or high voltage! ¡Attention, Danger, Safety Advice! Injuries risk! Danger! Do not stay underneath: Heavy load.
-
Page 3: Table Of Contents
INDEX CAUTIONS ��������������������������������������������������������������������������������������������������������������������������������������4 INSTALLATION �������������������������������������������������������������������������������������������������������������������������������5 TRANSPORTATION AND STORAGE �������������������������������������������������������������������������������������������12 OPERATING INSTRUCTIONS ������������������������������������������������������������������������������������������������������12 WIRING DIAGRAMS ���������������������������������������������������������������������������������������������������������������������23 DATASHEET����������������������������������������������������������������������������������������������������������������������������������30 MAINTENANCE INSTRUCTIONS ������������������������������������������������������������������������������������������������32 REPAIRS AND REPLACEMENTS ������������������������������������������������������������������������������������������������36 TROUBLESHOOTING ������������������������������������������������������������������������������������������������������������������41 DECLARATION OF CONFORMITY ����������������������������������������������������������������������������������������������44 IDENTIFICATOR ���������������������������������������������������������������������������������������������������������������������������46 GUARANTEE ��������������������������������������������������������������������������������������������������������������������������������46 Instructions manual - Air curtain Recessed Optima... -
Page 4: Cautions
15� The optimal working temperature of the fans is between 5ºC and 40ºC (41ºF to 104ºF) to protect the electrical components and at most should not exceed 50ºC (122ºF). SAVE THESE INSTRUCTIONS Instructions manual - Air curtain Recessed Optima... -
Page 5: Installation
INSTALLATION Tips and recomendations for a good installation LENGTH CENTERED / HEIGHT (*) Unless it has been de- signed to be installed at that height. DOOR DISTANCE Instructions manual - Air curtain Recessed Optima... - Page 6 AIR DISCHARGE AIR ASPIRATION MAINTENANCE ACCESSIBILITY CONTROL (CLEVER) Instructions manual - Air curtain Recessed Optima...
- Page 7 The minimum recommended distance between the suction grille and any obstacle is 200 mm (Dimension C) Dimension D: service opening distance. C1 and C2 refer to the space needed to install the air curtain inside the false ceiling. Instructions manual - Air curtain Recessed Optima...
-
Page 8: Connection Diagram
Connection diagram Standard without heating and with water heating 220-240Vx1 Instructions manual - Air curtain Recessed Optima... - Page 9 Standard electrical heating 400Vx3 and 220-240Vx1 Instructions manual - Air curtain Recessed Optima...
-
Page 10: Power Supply
The installation can be done using threaded rods, tensioners or other sup- ports (see available supports in the accessories section). Air Curtain Instructions manual - Air curtain Recessed Optima... -
Page 11: Water Heating
During the first uses, the electric battery can give off some odor that disappears in a few days. According to battery power, the regulation is carried out by: Size of the air curtain Heater power (kW) Regulation type 1000 / 1500 6 / 9 1 PRBEO 2000 2 PRBEO Instructions manual - Air curtain Recessed Optima... -
Page 12: Transportation And Storage
In addition, it allows to select different speeds and heating stages depending on the state of the door. It has a “Boost” function that to ensure comfort, increases the heating when the door is open. Instructions manual - Air curtain Recessed Optima... - Page 13 - Water heated: a single stage (ON/OFF) can be selected depending on open and closed door. If it has a proportional valve it can be regulated on 3 stages. Instructions manual - Air curtain Recessed Optima...
-
Page 14: Device Initialization
Example: Space between version and subver- ADVANCED PRO version: 01 sion� Unit Working in P1� ADVANCED PRO subversion: 02 2 units connected to the control Scanning units� (last number shown during initializa- tion) Instructions manual - Air curtain Recessed Optima... - Page 15 (To validate) CLOSED DOOR (*) Flashing ON (*) If the door contact is not detected, the door open and door closed icons will not appear. Only one speed and one heating will be available� Instructions manual - Air curtain Recessed Optima...
- Page 16 (To validate) CLOSED DOOR (*) Flashing ON (*) If the door contact is not detected, the door open and door closed icons will not appear. Only one speed and one heating will be available� Instructions manual - Air curtain Recessed Optima...
- Page 17 (To validate) (To validate) Flashing ON (*) If the door contact is not detected, the door open and door closed icons will not appear. Only one speed and one heating will be available� Instructions manual - Air curtain Recessed Optima...
- Page 18 (power supply fail). Information of the Menu Menu (to escape fast temperature outside (To validate) temperature setting) (**) Flashing ON (**) Only if an outside temperature sensor is installed on the air curtain PCB. Instructions manual - Air curtain Recessed Optima...
-
Page 19: Control Locking
Flashing ON To unlock the unit, the user must repeat the same combination of buttons as for locking. Then it will be hear a higher-pitched beeping sound, indicating that the control has been unlocked. Instructions manual - Air curtain Recessed Optima... -
Page 20: Operation Parameters Menu
In this menu is possible to modify operation parameters of the air curtain like the door delay, the max speed and max heating with open or closed door, the frecuency of filter maintenance, temperature units system used, memory or setting the boost mode. Instructions manual - Air curtain Recessed Optima... - Page 21 SET temperature, fan can be set to continue ON and be ready for when the door is opened again, as an immediate protection. If function is set to OFF, the air curtain will stop if the same conditions are met. Instructions manual - Air curtain Recessed Optima...
-
Page 22: Remote Control Features
In air curtains with electrical heating, it modifi es the power of the heating. On air curtains with water heating, it opens and closes the solenoid valve. It works with batteries of type AAA / LR03. Instructions manual - Air curtain Recessed Optima... -
Page 23: Wiring Diagrams
2 Velocidades 1000 / 1500 / 2000. Batería Agua / aire 2-Speed 1000 / 1500 / 2000. Water Heater & Only Air In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima... - Page 24 2 Velocidades 1000 6kW / 1500 6kW / 1500 9kW. Batería Eléctrica 400x3 2-Speed 1000 6kW / 1500 6kW / 1500 9kW. Electrical Heater 400x3 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
- Page 25 WIRING DIAGRAM OF AIR CURTAIN 2-SPEED CONTROLLER RJ11 ADVANCED PRO 2 Velocidades 1000 9kW. Batería Eléctrica 400x3 2-Speed 1000 9kW. Electrical Heater 400x3 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
- Page 26 WIRING DIAGRAM OF AIR CURTAIN 2-SPEED CONTROLLER RJ11 ADVANCED PRO 2 Velocidades 2000 12kW. Batería Eléctrica 400x3 2-Speed 2000 12kW. Electrical Heater 400x3 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
- Page 27 2 Velocidades 1000 6kW / 1500 6kW . Batería Eléctrica 230x1 2-Speed 1000 6kW / 1500 6kW . Electrical Heater 230x1 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
- Page 28 WIRING DIAGRAM OF AIR CURTAIN 2-SPEED CONTROLLER RJ11 ADVANCED PRO 2 Velocidades 1500 9kW. Batería Eléctrica 230x1 2-Speed 1500 9kW. Electrical Heater 230x1 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
- Page 29 WIRING DIAGRAM OF AIR CURTAIN 2-SPEED CONTROLLER RJ11 ADVANCED PRO 2 Velocidades 2000 12kW. Batería Eléctrica 230x1 2-Speed 2000 12kW. Electrical Heater 230x1 In case there is a need to connect the curtain to a PLC, the corresponding diagram is attached. Instructions manual - Air curtain Recessed Optima...
-
Page 30: Datasheet
+ Rectangular perforated RECESSED OPTIMA air curtain for commercial building entrances with recommended height of installation up to 2,8 meters. Inlet and outlet integrated in a single frame full view slatted grille for an easy installation. Stylish design, finished optionally in any colour to blend in with the building's internal or external aesthetics. -
Page 31: Optional Accessories
Magnetic door contact Mechanical door contact External Temperature Solenoid valve Proportional valve Anti-freezing sensor Valve 3 ways DC-MAG Sensor V-ACT DC-MEC V-S (ON/OFF) AFS-INS CAD drawings, BIM files, installation manuals and other documentation Instructions manual - Air curtain Recessed Optima... -
Page 32: Maintenance Instructions
Exterior cleaning Semiannual (recommended quarterly) Interior cleaning Semiannual (recommended quarterly) Internal inspection Biannual (recommended annual) Consumption and auditory Biannual (recommended annual) control Water heating maintenance Semiannual (recommended quarterly) Electrical heating maintenance Semiannual (recommended quarterly) Instructions manual - Air curtain Recessed Optima... -
Page 33: Exterior Cleaning
Make sure that the board and internal wiring connectors are still well connected. Check that the motors do not move from their mountings and check that the turbines have no impediments to rotate freely (turn it by hand, first turn off the device). Instructions manual - Air curtain Recessed Optima... - Page 34 Check the inlets and outlets of the water tubes to ensure that there are no fluid leaks. If a water leak has been detected in the battery, possible corrosion problems in both the battery and the air curtain components should be checked. Instructions manual - Air curtain Recessed Optima...
- Page 35 24,6 1000 9kW 1500 6kW 16,5 5,65 24,6 1500 9kW 26,1 26,1 2000 12kW 16,5 16,5 16,5 11,3 16,5 16,5 16,5 24,6 24,6 PS1 = Power Supply 1 PS2 = Power Supply 2 Instructions manual - Air curtain Recessed Optima...
-
Page 36: Repairs And Replacements
External rotor motor 4RET45-55S Y18-03 1500 Recessed Optima ECOCME06046 External rotor motor 4REC35 J10-A0 2000 Recessed Optima: Air/ VSACCO33005 PCB Air/water 2 speed PCB-2SO-AIR/WAT Water Recessed Optima: VSACCO33010 PCB Electrical 2 speed PCB-2SO-ELE Electrical Instructions manual - Air curtain Recessed Optima... -
Page 37: Motor Replacement
Next, open the grille, identify and release the fan cables. Remove the lateral (4 screws), unscrew the mo- tor, unscrew the turbine from the shaft and mount the replacement motor following the process in reverse order� Instructions manual - Air curtain Recessed Optima... - Page 38 Change fuse: remove the pcb from the air curtain for better maneuverability, remove the fuse protection casing and remove the fuse by hand or with the help of a screwdriver. Proceed to install the replacement and follow the reverse process to leave the curtain functional. Instructions manual - Air curtain Recessed Optima...
- Page 39 2.Drain the water battery with the drain plug of the main collector as shown in the picture and disconnect the battery from the installation. 3. Open the door as explained before. 4� Unscrew the screws that secure the battery to the housing� 5.Remove the battery from the air curtain housing. Instructions manual - Air curtain Recessed Optima...
- Page 40 (see table at the bottom of the page to count the screws to be removed), disconnect the PRBEO cables from both parts of the battery and remove the battery with both hands. Air curtain size Nº battery fixing screws 1000 1500 2000 Instructions manual - Air curtain Recessed Optima...
-
Page 41: Troubleshooting
The heating is blocked and switched Flashing ON off. It is the overheating safety program. Service must check the unit and fix the problem to avoid internal damages. Once solved, reset the unit� Instructions manual - Air curtain Recessed Optima... - Page 42 Fire Alarm (A6) Stops and locks the unit. To unlock it, the power supply must be switched off. It is activated with DIN3 digital IN on the con- trol unit� Instructions manual - Air curtain Recessed Optima...
-
Page 43: Error Lists
Some fan has stopped. Check the unit. Unit operation remains normal. Not available in 2-speed range. External Alarm (E5) Indicates an external alarm. Unit operation remains normal. Only programmable with CLEVER PRO control (consult CLEVER PRO Manual). Instructions manual - Air curtain Recessed Optima... -
Page 44: Declaration Of Conformity
DECLARATION OF CONFORMITY Instructions manual - Air curtain Recessed Optima... - Page 45 Instructions manual - Air curtain Recessed Optima...
-
Page 46: Identificator
If you detect some error in this manual, we’ll be pleased to receive your feedback, it helps us to improve even more. Airtècnics reserves the right to modify some of the specifi cations in this manual Instructions manual - Air curtain Recessed Optima... - Page 47 Instructions manual - Air curtain Recessed Optima...
- Page 48 Conca de Barberà, 6 - Pol. Ind. Pla de la Bruguera E-08211 Castellar del Vallès (Barcelona) Spain ☏ + 34 93 715 99 88 airtecnics@airtecnics.com www.airtecnics.com AIRDOM05710-R19(09/24) ORIGINAL MANUAL Airtècnics reserves the right to modify some of the specifications in this manual.
