Outputting In Multi-Image Mode - Fujitsu Fi-6750S Operator's Manual

Chapter 5 Various Documents
4
Select the [Rotation] tab, and then select the [Split Image]
checkbox.
When a document is scanned in Duplex Scan mode, the
scanned back side image(s) are output according to the
[Flip Side Rotation] settings in the order below:
• Book: Upper half
• Fanfold: Lower half
This function is not available with:
• [Multi Image Output] selected
• [Color/Monochrome Auto Detection] selected
• the resolution set to 1200 dpi
5
Click the [OK] button.
⇒
You are returned to the [TWAIN Driver (32)] dialog box.
6
In the [TWAIN Driver (32)] dialog box, click the [OK]
button.
⇒
Changes made are saved.
7
From ScandAll PRO, perform a scan.
For how to perform a scan, refer to
PRO" (on page 51).
Lower half
Upper half
"Chapter 3 How to Use ScandAll

Outputting in Multi-Image Mode

You can obtain both color/grayscale and binary black-and-
white image outputs at a single scan (this is called the Multi
Image Output function).
This function is not supported by all applications.
ABC
Original
Example: When a color document is scanned
1
Load a target document on the scanner.
For how to load documents on the scanner, refer to
Loading Documents" (on page
2
Start up ScandAll PRO, and then open the [TWAIN Driver
(32)] dialog box.
For how to open the [TWAIN Driver (32)] dialog box, refer to
3 How to Use ScandAll PRO" (on page
ABC
Created images
"Chapter 2
38).
"Chapter
51).
TOP
Contents
Index
Introduction
Scanner
Overview
Loading
Documents
How to Use
ScandAll PRO
Scan Pa-
rameters
Various
Documents
Daily Care
Consumables
Trouble-
shooting
Operational
Settings
Appendix
Glossary
101
