Toto TX1DB Quick Start Manual

SPECIFICATIONS
115
Ø100.2
PF 2
ATTENTION
1. Don't use abrasive cleaners or solvents on faucets
and fittings.
2. As the product model is constantly updated, the
actual product may not look the same as it shown in
the diagram, but the basic installation principles are
the same.
S06279N
FLOOR DRAIN W/ SQUARE FLANGE
(FOR 2" G.I. PIPE) (115 x 115 mm)
INSTALLATION
1.
Water Outlet PF 2
2.
Floor Drain
Flange
3.
Cover Plate
TROUBLESHOOTING
Hole Ø100.5
1. FLOOR DRAIN
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm
water. Wipe entire surface completely dry with clean
soft cloth. Many cleaners may contain chemicals, such
as ammonia, chlorine, toilet cleaner etc. which could
adversely affect the finish and are not recommended
for cleaning
TX1DB
R3
