- Page 1 OPERATION MANUAL PLASMA CUTTER CUT 70 S PILOT Modell 2017 Please read the operating instructions before use! There is a risk of non-reading! The devices are marked with the CE marking. © 2017 Stand 05/2017 – Subject to change...
- Page 2 OPERATION MANUAL CUT 70 S PILOT Contents Disclaimer Important nstructions Control panel- / Connection panel description Functions / Capability characteristics Technical specifications Construction Plasma / CUT-Burner Before implementing Implementing Mains supply / Network configuration Service / Check Cleaning Problem handling...
-
Page 3: Important Instructions
If you have any problems with the repair or use of the appliance, please contact a specialist. Please follow the instructions for the control examination. If you do not fully understand the operating instructions or if you cannot correct the error by means of operating instructions, you should contact your dealer for professional help. www.stahlwerk-schweissgeraete.de... - Page 4 OPERATION MANUAL CUT 70 S PILOT DANGER Electrical shock can lead to death! A welding machine works with high voltages. These can lead to life-threatening burns or even to fatal electric shock. Also when touching low voltages you can be frightened and in the event of an accident.
- Page 5 Electromagnetic interference! According to IEC 60974-10 the devices are intended for use in industrial areas. If, for example, used in residential areas, difficulties can arise if electromagnetic compatibility is to be endured. • Check the influence of other devices! www.stahlwerk-schweissgeraete.de...
-
Page 6: Control Panel Description
OPERATION MANUAL CUT 70 S PILOT CONTROL PANEL DESCRIPTION *Picture may differ Display The cutting current is infinitely variable between 20 and 70 Ampere. Overheat protection (CURRENT“ and/or „OC“ luminaire. Starts as soon as the device is overloaded (depending on the model – URRENT). A yellow (if applicable, green is the case of a POWER) indicator light turns on and goes out as soon as the unit has cooled down again. -
Page 7: Technical Specifications
FUNCTIONS / CAPABILITY CHARACTERISTICS With the integrated Plasma Cutter CUT 70 S Pilot can be cut without problems all conductive metals. For example: aluminum, steel, copper, brass, titanium and so on. Cutting power up to 25 mm Material thickness (depending on material). - Page 8 OPERATION MANUAL CUT 70 S PILOT TECHNICAL SPECIFICATIONS NOTE Values are only valid for correct operation and use of STAHLWERK original parts. Operating Temperature range -5 °C to +40 °C Transport and Storage Storage in closed room, Temperature range -15 °C to +55 °C...
- Page 9 The female connector and the gas-threaded connector marked with – (minus) are both current-carrying. The connection of a cable-hose assembly with gas and current supply in one is thus easily possible. The clamp of the ground cable is connected to the workpiece to be cut. www.stahlwerk-schweissgeraete.de...
- Page 10 OPERATION MANUAL CUT 70 S PILOT The compressed air must be connected to the rear of the unit. The water separator with manometer is required for this. The output of the water separator is connected to the input of the cutting unit. The compressed air is then connected to the inlet of the water separator.
- Page 11 This voltage is still up to 5 minutes after the power cord is unplugged. 1. Turn the unit off. 2. Disconnect the appliance reliably from the mains: pull the mains plug! 3. Wait at least 5 minutes until the capacitors are discharged! www.stahlwerk-schweissgeraete.de...
- Page 12 OPERATION MANUAL CUT 70 S PILOT DANGER Danger due to improper mains connection! Incorrect mains connection can lead to persons or property damage! • The power cord must be properly connected to the ground. • Only operate the appliance at a socket with a protective grounding conductor.
-
Page 13: Mains Supply
Green- conductor Yellow ATTENTION Operating voltage – Mains voltage! The operating voltage must correspond to the mains voltage in order to avoid damage to the device! • Plug the mains plug of the disconnected device into a suitable socket. www.stahlwerk-schweissgeraete.de... -
Page 14: Maintenance
OPERATION MANUAL CUT 70 S PILOT MAINTENANCE NOTE Proper, regular maintenance and cleaning of the device is a prerequisite for the maintenance of your warranty claims. Daily maintenance General visual inspection Check the mains plug Correct connection Weekly maintenance External relief from dust... - Page 15 The resistance must not exceed 0.3 ohm for a mains connection cable up to 5m length. For longer lines, the permissible value is increased by 0.1 ohm 75 m line. However, the maximum permissible value is 1 ohm. www.stahlwerk-schweissgeraete.de...
- Page 16 OPERATION MANUAL CUT 70 S PILOT CLEANING DANGER Risk of electric shock! The device must be cleaned only when the device is disconnected from the mains. 1. Turn the unit off. 2. Disconnect the device from the mains: pull the mains plug! 5.
- Page 17 DISTURBANCE In the event of a fault, please contact our customer service. Please send an e-mail to technik@stahlwerk-schweissgeraete.de GUARANTEE years warranty on electronic components. Three year durability warranty following two year legal warranty. The warranty period is two years and starts the day on which you received the goods.
-
Page 18: Eg-Konformitätserklärung
Hansestr. 101 Anschrift des Herstellers DE - 51149 Köln Address of manufacturer Germany Gerätebezeichnung STAHLWERK CUT 70 S PILOT Description of the machine Zutreffende EG - Richtlinien EG - Niederspannungsrichtlinie (2006/95/EG) Applicable EU - guidelines EC – Low Voltage Directive (2006/95/EC) - Page 19 Service STAHLWERK Schweißgeräte Deutschland Phone 0049 228 243317 13 Fax 0049 228 243317 23 Hauptsitz Auf dem Schurwessel 31 E-Mail info@stahlwerk-schweissgeraete.de D-53347 Alfter © Der Inhalt dieser Bedienungsanleitung begründet keinerlei Ansprüche seitens des Käufers. Nachdruck - auch auszugsweise – ist nicht gestattet.
