Summary of Contents for Maxcess FIFE SE-22-M12
- Page 1 FIFE GUIDING SOLUTIONS SE-22-M12 Operating Instructions Infrared Light Sensor Edition 10/2022 MI 1102 1 -...
-
Page 2: Table Of Contents
Adresses ............7-1 MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 3: Introduction
For more information, see the web guide controller operating instructions. The sensor must only be used in accordance with its intended purpose and in a technically flawless conditions. The sensor must not be changed or opened. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 4: Improper Usage
Figure 1.1: SE-22-M12 network environment. Additional sensor data can be provided to other hardware equipment if the Fife D-MAXE is linked appropriately to the network. The protectors can be made of plastic or glass. MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 5: Safety Instructions
The signal word CAUTION refers to a possible danger which could lead to slight to moderate injury. The signal word ATTENTION refers to a possible danger which could lead to material damage. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 6: Symbols
Keep for future use. Additional markings – Bulleted list ∙ Instructions 1. Instructions which must be processed in the specified order 2. End of the instructions Reference or cross-reference Note: Reference to important information. MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 7: Personnel Requirements
The electrician is specially trained for the field in which he or she works and is familiar with the relevant standards and regulations. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 8: Preventing Hazards
These risks must be recorded in a risk assessment by the machine/system builder and taken into consideration in the operating instructions. MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 9: Installation
– Do not place close to strong magnetic fields: The electronic components may be damaged. – Do not place close to strong electrostatic fields: The electronic components may be damaged. – Not in places where there is a risk of explosions. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 10: Dimensions
1 M8 threading for sensor bracket type M and MO 3 M5 threading for sensor bracket type MB 2 7/16-20 UNF threading for sensor bracket type 4 Connection cable length 40mm (without plug) type M and MO Figure 3.1: SE-22-M12 Dimensions, GW=51mm (standard) MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 11: Mechanical Fastening
Tighten the M5 fastening screws to a max. torque of 3Nm. Tighten the M8 fastening screws to a max. torque of 9Nm. Tighten the 7/16-20 UNF fastening screws to a max. torque of 12Nm. www.maxcess.com SE-22-M12 MI 1102 1 -... - Page 12 MO-25/8 MO-25/7/16 max 55 Sensor bracket type MB max. 55 1 – square bar Figure 3.3: SE-22-M12 with senor bracket type MB Square bar Sensor max. bracket length MB-20 1600 MB-25 2200 MB-30 2400 MI 1102 1 - SE-22-M12 www.maxcess.com...
-
Page 13: Electrical Connection
(PELV). – The negative potential must be connected to ground. – The sensor housing must be grounded via the cable screen. see also the drawing for the sensor cable in the system documentation www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 14: Operation
Information on this topic is available in the Operating Instructions for the web guide controller. Before the sensor is used for working with transparent material, the sensor must always be calibrated to the contrast with the web guide controller. MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 15: Maintenance
3. Unscrew the sensor from its bracket. 4. Store the sensor in a cool, clean and dry place. Ambient conditions, page 6-1 Dispose of the sensor according to your national requirements. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 16: Technical Data
Sensor field of view 17mm Linearity 5% max. error (at 10% .. 90% of signal) Web plane change 5% max. error (10% .. 90% of gap width) Temperature error 2% (at 10°C .. 50°C) MI 1102 1 - SE-22-M12 www.maxcess.com... -
Page 17: Electrical Connection
Housing = Shield 3 P-GND 4 Output signal Figure 6.1: M12 connector Standards The SE-22-M12 sensor was constructed in accordance with the standards and regulations of the European Union. A Declaration of Conformity is available. www.maxcess.com SE-22-M12 MI 1102 1 -... -
Page 18: Service
Oklahoma City, OK 73114, USA Telefon: +1 - 405 - 755 - 1600 E-Mail: service@maxcessintl.com Web: www.maxcess.com EUROPE, MIDDLE EAST NORTH, CENTRAL ASIA AND AFRICA AND SOUTH AMERICA PACIFIC Phone +49.6195.7002.0 Phone +1.844.MAXCESS Phone +86.756.881.9398 www.maxcess.com sales@maxcess.eu sales@maxcessintl.com info@maxcessintl.com.cn © 2022 Maxcess...
