200-350 VERADO FOURSTROKE
INSTALLATION MANUAL

Table of Contents

Important Steering Installation Guidelines ............................... 4
Notice to Installer ..................................................................... 4
Bracket .............................................................................. 6
Unacceptable Accessory Mounting ................................... 6
Avoiding Loss of Throttle and Shift Control ............................. 7
Boat Horsepower Capacity ...................................................... 8
Selecting Accessories for Your Outboard ............................... 8
Routing Connections Through the Cowl .................................. 8
Procedure .......................................................................... 8
Fuel Hose Connection ............................................................. 9
Fuel Hose Size .................................................................. 9
Accessory Electric Fuel Pump ................................................. 9
Avoiding Fuel Flow Restriction ................................................ 9
Low Permeation Fuel Hose Requirement ............................ 10
Fuel Demand Valve ............................................................... 11
Fuel Supply Module Priming Procedure ................................ 11
Priming the FSM with a Purge Tool ................................. 11
Installing Outboard ................................................................ 12
Multiple Engine Steering Requirements........................... 12
Multiple Steering Cylinders............................................... 12
Installation Specifications................................................. 14
Maximum Static Waterline................................................ 14
Maximum Outboard Mounting Height............................... 14
Drilling Outboard Mounting Holes..................................... 15
Checking Boat Transom Construction.............................. 17
Lifting the Outboard (200-300)......................................... 17
Page 1 / 44
© MERCURY MARINE. All rights reserved. Reproduction in whole or in part without permission is
prohibited. Alpha, Axius, Bravo One, Bravo Two, Bravo Three, Circle M with Waves Logo, K-planes,
Mariner, MerCathode, MerCruiser, Mercury, Mercury with Waves Logo, Mercury Marine, Mercury
Precision Parts, Mercury Propellers, Mercury Racing, MotorGuide, OptiMax, Quicksilver, SeaCore,
Skyhook, SmartCraft, Sport-Jet, Verado, VesselView, Zero Effort, Zeus, #1 On the Water and We're
Driven to Win are registered trademarks of Brunswick Corporation. Pro XS is a trademark of Brunswick
Corporation. Mercury Product Protection is a registered service mark of Brunswick Corporation.
Battery ................................................................................... 25
Wiring and Installation ........................................................... 32
Wire Harness Diagrams ........................................................ 36
System Wiring Installation Checklist ..................................... 43
© 2016 Mercury Marine
Lifting the Outboard (350)................................................. 18
Fastening the Outboard.................................................... 21
Battery Requirements....................................................... 25
Battery Connections......................................................... 29
Verado Engine Battery Specifications.............................. 30
Wire Color Code Abbreviations........................................ 32
DTS Wiring Guidelines..................................................... 32
Data Harness Pulling Procedure...................................... 33
Switch............................................................................... 33
Wiring Accessories........................................................... 34
.......................................................................................... 36
.......................................................................................... 38
.......................................................................................... 40
.......................................................................................... 42
Data Cable ....................................................................... 43
Junction Box (if equipped) ............................................... 43
Electronic Remote Control ............................................... 43
DTS Command Module Harness ..................................... 43
Battery ............................................................................. 44
Lanyard Stop Switch ........................................................ 44
90-8M0118154
eng APRIL 2016
