Table of Contents English ...................... 1 1. Before You Start ................2. Hardware Installation ................. Troubleshooting ..................9 Version 04.12.2009...
1. Before you start Package Contents TV-H500 Quick Installation Guide 1 x Wall Mount Bracket 4 x Hex Screws 4 x Mounting Screws 4 x Mounting Screw Anchors 4 x Mounting Washers 1 x Allen Wrench 1 x Cable Strain Relief Plug* Installation Requirements The following items below are not included.
2. Hardware Installation Note: Configure your IP Camera to match your network before installing the device. Hardwire Installation 1. Lift up the latch and pull the roof upward. 2. Remove the black bracket from the camera enclosure. 3. Use a screw to mount the base of the IP camera to the black bracket.
Page 5
4. Connect the black bracket back inside the enclosure. Move the camera as close to the glass as possible. This example shows a TRENDnet TV-IP100W-N. 5. Insert the IP Camera's power adapter and Ethernet cable through the mounting bracket. 6. Insert the IP Camera's power adapter and Ethernet cable through the hole.
Page 6
8. Close and secure the back panel. 9. Plug the IP camera power adapter into an available power outlet. English...
Page 7
Installing External Antenna to Wireless IP Camera Note: 1. Before installation, you need the following products: TEW-ASAK, antenna cable (TEW-L406 or TEW-L412) and an external antenna (TEW-AO14D). 2. Since the TV-IP512W requires two surge arresters (TEW-ASAK), two antenna cables (TEW-L406 or TEW-L412) and two external antennas (TEW-AO14D), you will need to perform steps 3, 4, 5 and 8 for each surge arrester (TEW-ASAK).
Page 8
5. Connect the SMA end of the TEW-ASAK(s) to the IP camera. 6. Connect the IP camera's power adapter to the IP camera. 7. Follow steps 8-9 in the Hardware installation section above. 8. Follow the directions in the QIG for the TEW-ASAK to connect the surge arrester to your external antenna (eg.
Page 9
Mounting the Camera Housing 1. Place the mounting bracket against the wall and mark each of the four holes with a pencil. 2. Drill holes for the screw anchors at each marked position. Make sure the drill bit matches the size of the provided screw anchors.
Page 10
Your installation is now complete. For detailed information regarding the TV-H500 configuration and advanced settings, please visit TRENDnet's website at www.trendnet.com Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register...
If you still encounter problems or have any questions regarding the TV-H500, please contact TRENDnet's Technical Support Department.
