  • Page 1 About This Document MC610 Hardware Guide V1.2 Copyright © Fibocom Wireless Inc.

  • Page 2: Trademark Statement

    Trademark Statement The trademark is registered and owned by Fibocom Wireless Inc. Other trademarks, product names, service names and company names appearing in this document are owned by their respective owners. Contact Information Website: https://www.fibocom.com Address: 10/F-14/F, Block A, Building 6, Shenzhen International Innovation Valley, Dashi First Road, Xili...

  • Page 3: About This Document

    This document describes information on electrical characteristics, RF performance, structural dimension, application environment, etc. of the MC610 series wireless module. With the help of this document and other related documents, the application developer can quickly understand the hardware functions of MC610 series modules and develop the hardware of the product.

  • Page 4: Related Documents

    - DCE) interface for Short Message Service (SMS) and Cell Broadcast Service (CBS) 1.4 Related Documents Fibocom_MC610_ADP User Guide ⚫ FIBOCOM_MC610_SMT Design Guide ⚫ FIBOCOM_Design Guide_RF Antenna ⚫ FIBOCOM_MC610_AT Commands ⚫ FIBOCOM_MC610 GPIO Function Multiplexing ⚫ FIBOCOM_MC610_Reference Design ⚫ Copyright © Fibocom Wireless Inc.

  • Page 5: Product Overview

    2 Product Overview 2 Product Overview 2.1 Product Introduction MC610 series module is a kind of broadband wireless terminal product suitable for TDD-LTE/FDD-LTE multiple network systems and multiple bands. Item LTE FDD LTE TDD MC610 Band 1, 2, 3, 4, 5, 7, 8, 28, 66...
  • Page 6 Software Protocol stack Embedded TCP/IP and UDP/IP protocol stack AT command 3GPP TS 27.007 and 27.005, and proprietary FIBOCOM AT Firmware update USB HR, FR, EFR, AMR, caller display, call transfer, call holding, call waiting, multi-party Voice service call, etc.
  • Page 7 Band 66 AWS-1 1700 LTE FDD 1710 - 1780 2110 - 2180 3.2 RF Output Power of MC610 The RF output power of MC610 series modules is shown in the following table. Table 3. Output power Mode Band Tx Power(dBm) Note GSM 850 33±2...
  • Page 8 23±2 Band 28 10MHz Bandwidth, 1 RB Band 66 23±2 10MHz Bandwidth, 1 RB Band 38 23±2 10MHz Bandwidth, 1 RB Band 40 23±2 10MHz Bandwidth, 1 RB Band 41 23±2 10MHz Bandwidth, 1 RB Copyright © Fibocom Wireless Inc.

  • Page 9: Product Appearance

    4 Structural Specification 4 Structural Specification 4.1 Product Appearance The appearance of MC610 series modules is shown in the figure: Figure 1. Module product appearance (top) Copyright © Fibocom Wireless Inc.
  • Page 10 4 Structural Specification Figure 2. Module product appearance (bottom) 4.2 Structure Size The structure size of MC610 series modules is shown in the following figure: Figure 3. Structural dimension drawing (unit: mm) Copyright © Fibocom Wireless Inc.

  • Page 11: Rf Pcb Design

    5 RF PCB Design 5 RF PCB Design 5.1 Antenna RF Connector The antenna of the MC610 series modules is led from bonding pads. It is recommended that customers use the U.FL-R-SMT-1 antenna connector and use the matching RF adapter lines.
  • Page 12 ● There should be a good reference ground around the PCB routes to avoid other signal lines close to the antenna. ● It is recommended to use intact formations as reference ground. ● The ground around the antenna strengthens the connection with the main ground. Copyright © Fibocom Wireless Inc.

  • Page 13: Appendix A Red Conformance Information

    The device could beused with aseparation distance of 20 cm to the human body. Declaration of conformity Hereby, [Fibocom Wireless Inc.] declares that the radio equipment type [Model Name: MC610] is in compliance with Directive 2014/53/EU. For the declaration of conformity, visit the Web site www.fibocom.com/certification.

  • Page 14: Appendix B Fcc Conformance Information

    Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Copyright © Fibocom Wireless Inc.
  • Page 15 When testing the host device for compliance with Part 15 Subpart B, the host manufacturer is required to show compliance with Part 15 Subpart B while the transmitter module(s) are installed and operating. The modules should be Copyright © Fibocom Wireless Inc.

  • Page 16: End Product Labeling

    Fibocom Wireless Inc. that they wish to change the antenna trace design. In this case, a Class II permissive change application is required to be filed by the USI, or the host manufacturer can take responsibility through the change in FCC ID (new application) procedure followed by a Class II permissive change application.

  • Page 17: Manual Information To The End User

    FCC ID/IC ID cannot be used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC/IC authorization. Manual Information to the End User Copyright © Fibocom Wireless Inc.

  • Page 18: Information To User

    If you desire to increase antenna gain and either change antenna type or use same antenna type certified, a Class II permissive change application is required to be filed by us, or you (host manufacturer) can take responsibility through the change in FCC ID (new Copyright © Fibocom Wireless Inc.
  • Page 19 The module is limited to installation in mobile application, a separate approval is required for all other operating configurations, including portable configurations with respect to §2.1093 and difference antenna configurations. Copyright © Fibocom Wireless Inc.
