  • Page 1 Kit HMI Remota Kit HMI Remota Kit HMI Remota Kit HMI Remota Kit HMI Remota Kit HMI Remota Kit HMI Remota Kit HMI Remota SSW-07 Installation Guide Installation Guide Installation Guide Installation Guide Installation Guide Guia de Instalación Guia de Instalación Guia de Instalación...

  • Page 3: Table Of Contents

    SUMMARY 1. DESCRIPTION OF THE KIT ................. 5 2. SAFETY NOTICES ..................5 3. DEGREE OF PROTECTION ................ 5 4. OPTIONAL MODULE DESCRIPTION ............5 5. KEYPAD CONNECTION CABLE ..............7 6. REMOTE KEYPAD KIT INSTALLATION PROCEDURE ......7 INDICE 1.

  • Page 5: Description Of The Kit

    Remote Keypad 2. SAFETY NOTICES ATTENTION! Switch off the Soft-Starter SSW-07 before installing the Remote Keypad kit. The electronic boards have components that are susceptible to electrostatic discharge. Never touch any of the electrical components or connectors without following the proper grounding procedures. If it is necessary to do so, touch the grounded heatsink or use a suitable grounded wrist strap.
  • Page 6 Figure 1 - Remote Keypad external dimensions 52mm (2.05in) Figure 2 - Remote Keypad dimensions for mounting in panels...

  • Page 7: Keypad Connection Cable

    The Remote Keypad Kit does not include any cable. Table 2 - Keypad Connection Cables Remote Keypad Connection Cables Description Part number 1m (3.28ft) SSW-07 - Remote Keypad Connection Cable 0307.7827 2m (6.56ft) SSW-07 - Remote Keypad Connection Cable 0307.7828 3m (9.84ft) SSW-07 - Remote Keypad Connection Cable 0307.7829...
  • Page 8 3. Replace the cover with the optional plug-in module and connect the Keypad cable. Make sure that both are connected. 4. Fixing the Keypad to the panel. Place the supports at the panel inner side. 5. Use an appropriate tool to tighten the screws.

  • Page 9: Descripción Del Kit

    NOTA! La programación de los parámetros de la HMI debe ser realizada de acuerdo con el manual de programación del SSW-07 disponible en el CD que acompaña el Arrancador suave o en la página web de WEG (www.weg.net). Las dimensiones de la HMI Remota son presentadas en las figuras 1 y 2.
  • Page 10 Figura 1 - Dimensiones externas de la HMI Remota 52mm (2.05in) Figura 2 - Dimensiones de la HMI Remota para el montaje en tableros...

  • Page 11: Cables De Conexión De La Hmi

    Tabla 2 - Cables de conexión de la HMI Cables para la conexión de la HMI Descripción Ítem Cable de 1m para conexión SSW-07 – HMI remota 0307.7827 Cable de 2m para conexión SSW-07 – HMI remota 0307.7828 Cable de 3m para conexión SSW-07 – HMI remota 0307.7829...
  • Page 12 3. Sustituya la tapa por el módulo opcional Plug-In y conecte el cable para la HMI. Certifíquese que ambos estén conectados. 4. Fijación de la HMI en el tablero. Coloque los suportes con los tornillos por la parte interna del tablero. 5.

  • Page 13: Descrição Do Kit

    HMI Remota 2. INFORMAÇÕES DE SEGURANÇA ATENÇÃO! Desligar a Soft-Starter SSW-07 antes de instalar o kit HMI Remota. Os cartões eletrônicos possuem componentes sensíveis a descargas eletrostáticas. Não toque diretamente sobre componentes ou conectores. Caso necessário, toque antes na carcaça metálica aterrada ou utilize pulseira de aterramento adequada.
  • Page 14 Figura 1 - Dimensões externas da HMI Remota 52mm (2.05in) Figura 2 - Dimensões da HMI Remota para montagem em painéis...

  • Page 15: Cabos De Conexão Da Hmi

    Tabela 2 - Cabos de conexão da HMI Cabos para conexão da HMI Descrição Item Cabo de 1m para conexão SSW-07 – HMI remota 0307.7827 Cabo de 2m para conexão SSW-07 – HMI remota 0307.7828 Cabo de 3m para conexão SSW-07 – HMI remota 0307.7829...
  • Page 16 3. Substitua a tampa pelo módulo opcional Plug-In e conecte o cabo para a HMI. Certifique-se que ambos estejam conectados. 4. Fixação da HMI no painel. Coloque os suportes com os parafusos pela parte interna do painel 5. Utilize a ferramenta apropriada para apertar os parafusos.
  • Page 20 WEG Drives & Controls - Automação Ltda. Jaraguá do Sul - SC - Brazil Phone 55 (47) 3276-4000 - Fax 55 (47) 3276-4020 São Paulo - SP - Brazil Phone 55 (11) 5053-2300 - Fax 55 (11) 5052-4212 automacao@weg.net www.weg.net www.weg.net...
