- Page 1 ATHERTON RANGEHOOD INSTALLATION INSTRUCTIONS...
- Page 2 Rangehood Installation Instructions...
- Page 3 Important Information Instructions for Models SOMERTON / AVENEL / STIRLING Instructions to change from Top to Back Ducted Model Technical Specification Drawings Remote Switching Specifications Ducting Pieces Operation Details, Rangehood Cleaning, Filter Cleaning Appliance Guarantee Guarantee Exclusions Standard Warranty / Extended Warranty Rangehood Installation Instructions...
- Page 4 Do not reduce the duct size or have sharp bends. Enlarge the duct size if the duct is to run 6 metres or longer. Advice from Condari is available to ensure optimum performance.
- Page 5 5. NOTE: Condari recommend minimum air movement of 2000 cubic metres per hour and recommend up to 3600 cubic metres per hour over a barbecue, depending on the length of the duct run. Barbecues should be positioned under the centre of the hood where the fans are mounted and not near the outer edges where leakage may occur.
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Somerton, Avenel & Stirling Models 1. Determine hood position on wall 1200mm to 1400mm above barbecue. 2. Unpack rangehood. 3. Mark centre line on wall. 4. Mark base line on wall (Note: if shroud is being used, take note of the height of the shroud as it may impact the rangehood position). - Page 7 INSTRUCTIONS TO CHANGE THE ORIENTATION OF THE RANGEHOOD OUTLET PLATE. Instructions to change the orientation of the rangehood outlet plate from top ducted to back ducted or vice-versa. 1. Locate and remove 12x M4 screws as shown below. 2. Once all screws are removed, push rangehood outlet plate from the inside of the rangehood outwards. 3.
- Page 8 DIAGRAM SHOWING OUTLET PLATE IN TOP AND BACK DUCTED POSITIONS. Top Ducted as Supplied Back Ducted Shown Rangehood Installation Instructions...
-
Page 9: Technical Specification Sheet
Atherton Technical Specification Sheet SOMERTON - SOM Somerton Wall Mounted Shown as Top Ducted. Power entry location is the same for all Somerton models. 430.00 Shown as Remote Switched. Back Ducted shown with Shroud. Electrical connection is made at junction box inside rangehood. Somerton comes top ducted and can be converted to back ducting on site by the installer. - Page 10 Atherton Technical Specification Sheet AVENEL - AVE Avenel Wall Mounted Showing as Top Ducted Power entry location is the same for all Avenel models. Shown as Back Ducted Remote Switched. shown with Shroud. Electrical connection is made at junction box inside rangehood. Avenel comes top ducted and can be converted to back ducting on site by the installer.
- Page 11 Atherton Technical Specification Sheet Stirling Wall Mounted STIRLING - STIR Showing as Top Ducted. Power entry location is the same for all Stirling models. Back Ducted Shown as shown with Shroud. Remote Switched. Electrical connection is made at junction box inside rangehood. Stirling comes top ducted and can be converted to back ducting on site by the installer.
- Page 12 SHROUD TO SUIT ALL ATHERTON RANGEHOODS. Model ATH SHROUD Min Height ( ( H H = = ) ) 75mm Max Height ( ( H H = = ) ) 1400mm Coatings Condari Pty Ltd. Page 1 of 1 Version: C 08/03/2024 Rangehood Installation Instructions...
- Page 13 Be aware that active voltage must NOT be applied to both the ‘Black-High’ and ‘Brown-Low’ wires at the same time. This will cause the fan to fail. For further information, please contact Condari Pty Ltd CONDARI PTY LTD S. Stopher...
- Page 14 ATHERTON DUCTING All Atherton ducting pieces are available in zincalume, stainless steel, colourbond material or powderkote colour. 400. DL-4 401. HB-450X250 DL-4 SS HB-450X250 SS DL-4 C/P HB-450X250 C/P 402. VB-450X250 403. HB-450X250/45 VB-450X250 SS HB-450X250/45 SS VB-450X250 C/P HB-450X250/45 C/P 404.
- Page 15 ATHERTON DUCTING All Atherton ducting pieces are available in zincalume, stainless steel, colourbond material or powderkote colour. 406. BD/WV-V-450X250 407. RCB RCB SS BD/WV-V-450X250 SS BD/WV-V-450X250 C/P RCB C/P 408. RCBA 409. WVC-H-450X250 RCBA SS WVC-H-450X250 SS RCBA C/P WVC-H-450X250 C/P 410.
-
Page 16: Operation Details
Ensure the filters are completely dry before placing them back. Do not operate the rangehood without the filters installed. Condari does not recommend the use of corrosive, caustic or acidic products, particulary industrial or citric products. Condari has experienced problems with many of the dishwashing detergents now on the market. -
Page 17: For Example
If there is a breach of this warranty, Condari will rectify, free of charge, at it’s nearest service centre or authorised service agency any fault caused by faulty workmanship or material at the time of manufacture occurring in the appliance within 36 months from the date of purchase of the appliance to the customer. - Page 18 Outdoor barbecues will have a rating plate on them specifying that they are approved for outdoor use only. Any modification to the Atherton rangehood will void the warranty. If our standard Atherton rangehoods do not suit your requirements, Condari can manufacture a special rangehood to suit your alfresco area.
-
Page 19: Standard Warranty
ATHERTON Rangehoods are made in Ringwood, Australia. Tel: +61 3 9482 7088 Fax: +61 3 9482 7011 Email: sales@condari.com.au The Standard Warranty is from the date of purchase. Proof of purchase date is required to obtain service under this warranty. -
Page 20: Extended Warranty
ATHERTON WARRANTY Condari provides an extended warranty from 36 months to 72 months if installed by an authorised Condari installer and the below form is completed. The authorised installer also offers a warranty on their workmanship for the same period of 72 months with a guarantee that the installation is in compliance with ‘Atherton installation instructions’. - Page 21 NOTES Rangehood Installation Instructions...
- Page 22 NOTES Rangehood Installation Instructions...
- Page 23 NOTES...
- Page 24 Tel: 1300 360 563 Email: sales@qasair.com.au #05-03 Centrepoint Singapore 238843 Tel: 03 9482 7088 Email: sales@qasair.com.au Tel: +65 6369 1168 Fax: +65 6733 8133 CONDARI RESERVES THE RIGHT TO CHANGE SPECIFICATION WITHOUT NOTICE ATHERTON RANGEHOODS MADE IN RINGWOOD 3134 www.condari.com.au...
