Bristan Cruzar BNCRUBSMBLK Installation Instructions & User Manual

Dynamic Water Pressure
Max: 5.0 bar
Min: 0.5 bar
2.0 3.0
1.0
4.0
0 5.0
Pressure
BAR
Maximum Static Pressure: 10.0 bar
Pack Contents Pack Contents
x1
Cruzar Tap
x2
Rubber Washer
Backnut
x2
Plinth
Rubber Seal
Tools Required for Installation/ Maintenance Tools Required for Installation/ Maintenance
ø6mm
Drill Safety Glasses
All products manufactured and supplied by Bristan are safe to use provided that they are installed,
operated and receive regular maintenance in accordance with these instructions.
This product needs to be installed in accordance with, and meet the requirements of The Water Supply (Water
Fittings) Regulations (Northern Ireland) 2009 and The Water Supply (Water Fittings) (Scotland) Byelaws 2014.
For full Installation Requirements & Notes (IRN) please visit www.wrasapprovals.co.uk/approvals-directory
Isolation valves must be fitted to the inlet water supplies to ensure ease of future maintenance. Before installing this
product the water supply must be thoroughly flushed in order to remove any swarf, solder etc. Full access must be
made available for future maintenance/servicing purposes.
If power tools are used do not forget to:
This product must not be modified in any way as this will invalidate the guarantee.
Specifications
Inlet Water Temperature
Maximum Hot 60°C
x1
Bracket
x1
Handset
x1
Hose
Pencil Adjustable Hexagonal Key
Spanner (Grub Screws)
Prior to Installation
- Wear eye protection
Installation Instructions
Please leave these instructions
Cruzar Bath Shower Mixer Range | CRU BSM BB (D1)
Inlet Connections
60°C
3/4" BSP
On
Hot
2.5mm
2mm 8mm
Hexagonal Key Hexagonal Key
(Diverter Peg) (Spout)
- Unplug equipment after use
& User Guide
with the end user
M16 Recessed
Flow Straightener
Operation Operation
Diverter Operation
• Turn handle left for hand-set
• Turn handle right for bath-fill
32mm
17mm
Box Spanner
Socket Spanner
(Inlets)
Spare Parts
To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
Outlet
On
Cold
Size 1
Philips Head
Screwdriver
and search for your
product.
