- Page 1 ASUS ProArt W7604J H7604J Series Repair Manual...
-
Page 3: Service Overview
Service Overview • ASUS is not responsible for direct, indirect, intentional o unintentional damages resulting from improper installation and operation. • Carefully read through this Service Guide for a look at various components of the device before performing any service and repairs. - Page 4 Pre-repair checklist • Read the entire manual before starting any service procedures and follow all instructions. • Back up the data on your device. • Place your device on a clean and stable surface. • Turn off your device. • Disconnect all connected peripherals and cables.
- Page 5 ASUS ProArt W7604J H7604J Series Overview Top View Top View Bottom View ❶ Array microphones ❷ Camera indicator ❸ Camera IR Camera ❹ Touch screen panel ❺ Microphone off indicator ❻ Keyboard ❼ Capital lock indicator ❽ ASUS Dial ❾ Touchpad ❿...
- Page 6 Components Top View OLED MODULE BOTTOM CASE SPEAKER WIFI ANTENNA ENCODER SWITCH TOUCHPAO MODULE LED FFC WIFI CARD KEYBOARD MODULE THERMAL MODULE BATTERY KNOB CAP ASM TOP CASE DECO BATT CABLE LCD TOUCH DECO ENCODER FFC BATT AL FOIL MAIN BOARD IO BOARD GRAPHITE KNOB HOLDER ASSY...
- Page 7 Components Bottom View OLED MODULE BOTTOM CASE KEYBOARD MODULE MAIN BOARD TOUCHPAO MODULE IO BOARD LED BOARD THERMAL MODULE Back...
- Page 8 Repair Overview This chapter describes disassembly and assembly (Assemble document please look up from the last page), please follow the information provided in this section to perform the complete disassembly procedure. Precautions: Before you perform any service or repair on the notebook, please pay special attention to the cautions prevent any damages to the notebook. 1.
- Page 9 ASUS ProArt W7604J H7604J Series Appropriate Tools Screwdriver Alcohol 95% Glove Dust-free Cloth Please accord to different screw specification to choose different screwdriver and head. Plastic Blade Plastic Tweezers Thermal Pad (Substitute: Thermal Grease) Use a pair of tweezers to remove/insert/tidy cables.
-
Page 10: Bottom Case
BOTTOM CASE Disassembly Notice Torque(kgf-cm) Screws Spec Step 1 : Remove screw *10pcs. SCREW M2*11.5L+0.5(3.3,0.3)(K)+H T5 2.0±0.2 Step 2 : Use plastic blade to pry the BOTTOM CASE. SCREW M2*0.5+4.5(3.3,0.3)(K)+H 2.0±0.2 SCREW M2*9.5L+0.5(3.3,0.3)(K)+H T5 2.0±0.2 Start Please follow above arrow direction To avoid the bottom case with using plastic blade to pry bottom hook, don't insert plastic blade... - Page 11 DISCONNECT BATTERY CONNECTOR Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Step 1 : Use the non-conductive pry tool to push iron sheet.
- Page 12 Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the screws *2pcs and then remove the SSD *2pcs (red mark). Screws Spec Torque (kgf-cm) Step 2 : Tear off the Thermal PAD from the SSD. SCREW M2*3L (4.5,0.5) (K)#1 2.0±0.2 Remove...
- Page 13 MEMORY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Remove the MEMORY *2pcs (red mark). Step 2 : Remove the ABSORBER (with GRAPHITE）from the MEMORY . Outside is Please check and remove GRAPHITE the spec label from the Remove...
- Page 14 BATTERY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Before disassembly battery connector, please be sure to pull out adapter and disconnect the battery more than ten seconds in order to avoid IC damage. Torque(kgf-cm) Screws Spec Step 1 : Remove screws *4pcs.
- Page 15 WLAN CARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the RF CABLE connector*2pcs. Step 2 : Remove the screw*1pc. Screws Spec Torque(kgf-cm) Step 3 : Remove the WLAN CARD. SCREW M2*3L (4.5,0.5) (K)#1 2.0 ±...
- Page 16 ENCODER SWITCH ASSY Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect the ENCODER FFC from the MB (red mark). Screws Spec Torque (kgf-cm) Step 2 : Remove the screw *4pcs and then remove the ENCODER SWITCH ASSY. SCREW M2*9.5L (4,0.8) (K) #1 2.0±0.2 Step 3 : Disconnect the ENCODER FFC from the ENCODER SWITCH ASSY.
- Page 17 MB (with THERMAL MODDULE and FAN) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect and remove the LAN_IO_FPC (red mark). Screws Spec Torque (kgf-cm) Step 2 : Disconnect the EDP CABLE (purple mark) and CMOS CABLE (pink mark) and FAN connector SCREW M2*4.2L (4.5,0.6) (K) #1 2.0±0.2 (yellow mark) from MB.
- Page 18 THERMAL MODULE(with FAN) Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Loosen the screw *7pcs. Step 2 : Remove the THERMAL MODULE (with FAN). Recommend that the force point is at green block, and pull up thermal module to take it out.
-
Page 19: Main Board
MAIN BOARD Mainboard connector placement FFC_USB LAN_IO_FPC CMOS CABLE EDP CABLE SPEAKER BL FPC LED FFC BATTERY TP FFC K/B FPC Back... - Page 20 MAIN BOARD (W/H7604J) Materials on mainboard For H7604JV W7604J3D GPU X4 MYLAR For H7604JI / W7604J3D W7604J3D GPU X6X7 MYLAR W7604J3D I9 CPU KAPTON W7604J3D MB RF WLAN MYLAR Back...
- Page 21 MAIN BOARD (W/H7604J) Materials on mainboard W7604J3D CPU GPU BKT ASSY W7604J3D MB MYLAR W7600H5A USB TOP COMPOSITE W7604J3D RF CONN ABSORBER Back...
- Page 22 IO BOARD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove screw *2pcs on the IO BOARD. Step 2 : Remove IO BOARD. SCREW M2*3L (4.5,0.5) (K)#1 2.0±0.2 Remove Remove Back...
- Page 23 SPEAKER WIFI ANTENNA SET Please be sure to pull out adapter and disconnect the battery. Disassembly Notice Step 1 : Remove SPEAKER WIFI ANTENNA SET. Remove Assembly Notice For SPEAKER WIFI ANTENNA SET assembly, please follow the mark below to tidy cable. 23 23 Back...
- Page 24 LED BOARD and TOUCHPAD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Disconnect and remove FFC *2pcs (yellow mark). Screws Spec Torque (kgf-cm) Step 2 : Remove screw *2pcs and then remove the LED BOARD. Step 3 : Remove the screw *8pcs on the TOUCHPAD.
-
Page 25: Keyboard Module
KEYBOARD MODULE Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Step 1 : Use plastic blade to pry loosen the snap position (red Mark). Screws Spec Torque (kgf-cm) Step 2 : Remove the TOP CASE DECO. Step 3 : Remove screw *10pcs (on the hinge, hinge cover and KB) and then remove the hinge cap. - Page 26 TOUCHPANEL_CONTROL_BD Disassembly Notice Please be sure to pull out adapter and disconnect the battery. Screws Spec Torque (kgf-cm) Step 1 : Remove the LCD TOUCH DECO. Step 2 : Remove the screw *2pcs (red mark) and then remove the LCD TOUCH CABLE. SCREW M1.6*2L (3.5,0.3) (K) #0 1.0±0.2 Step 3 : Disconnect the connector *3pcs(green mark) from the TOUCHPANEL_CONTROL_BD.
