DXV Equility D21070022 Installation Instructions

INSTALLATION INSTRUCTIONS
Equility
®
Console Lavatory Kit
Model D21070022
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully
before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Basin Wrench
Hacksaw
Pipe Wrench
ROUGHING-IN DIMENSIONS:
• For reference
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2022
Regular Screwdriver
Phillips Screwdriver
Adjustable Wrench
22"
(558 mm)
8"
(203 mm)
12"
(304 mm)
19-7/16"
(494 mm)
11"
(280 mm)
FINISHED
FLOOR
18-1/2"
(471 mm)
Screw
Drill
Channel Lock
4-1/8"
(105 mm)
- 1 -
10'
Tape Measure
Level Saber Saw
Putty Knife Tubing Cutter
18"
(457 mm)
FINISHED
WALL
FINISHED
FLOOR
11-9/16"
(294 mm)
770298-100 Rev. A (9/22)
