INSTALLATION INSTRUCTIONS
DXV Modulus
Lavatory
21" Model D21040021 Series
36" Model D21045036 Series
55" Model D21060055 Series
36" Model D21050036 Series— Concrete
Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin.
(Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work has begun.
Electric
Channel Locks
Drill
Phillips Screwdriver
10'
Tape Measure
Regular Screwdriver
LAVATORY MODELS
21 " Model
D21040021 Series
D
W
D: 21" (533 mm)
W: 21" (533 mm)
REPLACEMENT USE
When replacing an original unit be sure to shut off water supply before removing the lavatory or disconnecting
water supply lines and drain fittings. Original supplies and shutoff valves should be replaced on installation.
INSTALLATION PROCEDURES
Typical installation includes cabinet support preparation, installation of faucet and pop-up drain, connection of flexible water
supply lines, attachment of lavatory to cabinet, sizing and installation of drain and water supplies.
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
™
Adjustable Wrench
Pipe Wrench
36 " Model
D21045036 Series
w
D: 21" (533 mm)
W: 36" (914 mm)
Tubing Cutter
Saber Saw
55 " Model
D21060055 Series
D
D: 21" (533 mm)
W: 55" (1397 mm)
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
1
2
3
4
5
6
7
8
9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
Square
Sealant
Level
Hacksaw
w
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
7302323-100 Rev. A (10/18)
D
Advertisement
Related Manuals for DXV Modulus D21040021 Series
Summary of Contents for DXV Modulus D21040021 Series
- Page 1 36" Model D21050036 Series— Concrete Thank you for selecting DXV. To ensure this product is installed properly, please read these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
- Page 2 ROUGHING-IN DIMENSIONS: 21" Model #D21040021 Series 1-1/2" (38 mm) 21" 8" (533 mm) (203 mm) 16" (406 mm) 12-1/4" 1-1/16" 4-9/16" (311 mm) (26 mm) (116 mm) 4-1/8" 2-11/16" (68 mm) 11/16" (104 mm) 21" (18 mm) (533 mm) 1-1/16" 1-1/16"...
- Page 3 LAVATORY INSTALLATION (SLAB MOUNTED): 1. Place template on top of slab and against back of wall surface. Figure A. Note: Carefully position the template so the center line of the lavatory drain outlet is directly in line with the center line of P trap in the wall. 2.
- Page 4 LAVATORY INSTALLATION (VANITY MOUNTED): LEVEL 1. Place lavatory on top of vanity and insure lavatory is level. Figure A. Figure A. 2. Remove top drawer and mark wall where mounting screws will go through the rear of lavatory then remove lavatory. Figure B. SINK MOUNTING HOLES 3.
