Pulsar EXPANDER2/SP/GRADE 3 Mounting Instructions

1. Destination:
AWO454 metal enclosure compliant with EN50131 GRADE3 are designed as components in intrusion alarm system,
access control systems, security systems etc. It is intended for installation:
 expander (modules) inputs/outputs etc.
 GSM transmiter, ISDN module
 other to dedicated devices, components etc.
2. Installation:
Metal enclosure must be installed by a qualified installer, holding the relevant certificates, required and necessary in the
Enclosure should be installed indoor, where air humidity is normal (RH=90% max. without condensation) and
Caution!
electric charges. Prior to installation, these charges must be removed.
1. Install metal casing in dedicated place and bring in the connecting and signal conductors through cables bushings.
2. Mount the device with dedicated holes (use: distance pins, bracket screw).
3. Make other connections required for the correct type of system / device.
Remarks: consistent with requirements and recommendation of equipment producer.
4. Start the system, adjust or configure: according to procedure of the producer's system.
5. After installing and checking the proper operation of the system, close enclosure.
particular country for connecting (interfering with) low-voltage installations.
temperature in the range of -10°C do +40°C.
Electronic devices contains electronic components sensitive to
During installation, avoid touching any elements on the board.
MOUNTING ISTRUCTIONS
Code: AWO454
Name: EXPANDER2/SP/GRADE 3
Metal enclosure for: expanders, GSM/ISDN module, etc.
Edition: 5 from 25.06.2024
Supercedes edition: 4 from 15.03.2022
v1.3
IM454
EN
