Moen SANI-STREAM 8132 Installation Instructions

SANI-STREAM
"
4
H
DECK HOLE
SIZE (1-3/8")
1/2" IPS
HOT INLET
NOTE: Spout No.'s S0006, S0008, S0010, SV006, SV008 and SV010 cannot be used with
these models. Check local code requirements when selecting spout.
CAUTION:
Before turning water on during either rough-in or trim-out, make sure that the cartridge retainer nut is in place. The cartridge and
retainer nut were properly installed and tested before leaving the factory. Although it is unlikely, it is nevertheless possible that through
the handling of the valve by any number of persons the retainer nut may not be properly installed. This should be carefully checked
at time of rough-in and trim-out. If the retainer nut is not properly installed, water pressure could force the cartridge out of the casting.
Personal injury or water damage to the premises could result.
by MOEN
2 HANDLE WIDESPREAD
Model #8132 (6" Wrist Blade Handles)
Model #8133 (4" Wrist Blade Handles)
DECK HOLE
SIZE (3/4" to 1")
4" TO 38" CENTERS
Always turn water off before disassembling the valve. Open both faucet handles to
alleviate water pressure to insure that complete water shut-off has been accomplished.
®
INSTALLATION INSTRUCTIONS
THESE INSTRUCTIONS MUST BE
SPOUT BASE
2-1/4" DIA.
FLEXIBLE
HOSE
LEFT AT INSTALLATION SITE
6"
C
1-1/4" MAX
DECK THICKNESS
1/2" IPS
COLD INLET
MT017B
(78393)
4"
