Aiwa HS-J07 Service Manual

MODEL NO.
TYPE. Y
SPECIFICATIONS.
<Radio Section >
Frequency range:
FM: 88— 108 MHz
Dimensions:
81 (W) x114 (H) x29 (D) mm
AM: 530—1,605 kHz
;
.
(excluding any projecting parts)
Antenna:
FM headphone antenna
Maximum dimensions:
82 (W) x 115.5 (H) x30.9 (D) mm
AM ferrite bar antenna Weight: _ 300 g (including batteries)
Accessories: Stereoheadphones x1
<Tape Recorder Section >
Belt clip x1
Track arrangement:
4-track, 2-channel, stereo
Carrying case
x1
Frequency range:
40 to 12,500 Hz (NORMAL tape)
'
Remote controller
x1
40 to 16,000 Hz (METAL tape)
Microphone:
ey
electret condenser micro-
phon
Maximum output: 20 mW + 20 mW (EIAJ/17 0)
Input terminal:
MIC jack, 3.5 ¢stereo mini x1
Output terminal:
Phones jack, 3.5¢ stereo mini x2
Power source:
Battery
DC 3V R6P
(SUM-3, AA,
LR-6) x2
Domestic AC power (using optional
AC adapter)
Battery life:
@
Using manganese batteries (REP,
SUM-S, AA)
Approx. 4.5 hours {EIAJ, record-
ing mode)
.
Soe 3 '
:
Approx. 7.5 hours (ElAJ, 1 mW
Design
and specifications
are subject to change
without
output, playback mode)
notice.
je
ae
alkaline batteries (LR-6,
Noise reduction
system manufactured
under
license from
Approx. 9 hours {ElAJ, recording
Dolby Laboratories Licensing Corporation.
mode)
Doiby and the D0 symbol are trademarks of Doiby Labo-
