TRENDnet TEG-424WS Specifications

FEATURES
• 24 x 10/100Mbps Auto-Negotiation, Auto-MDIX Fast Ethernet ports
• 4 x 10/100/1000Mbps Auto-Negotiation, Auto-MDIX Gigabit ports
• 2 x 1000Base Mini-GBIC slots (shared with Gigabit port 25~26)
• Store-and-forward switching architecture with non-blocking wire-speed performance
• Integrated address look-up engine with 8K absolute MAC address table and 128Kbytes RAM data buffering
• Provides 802.1Q VLAN, Broadcast storm control and IEEE 802.1p Quality of Service (QoS)
• Includes Trunking, Port Mirroring and IGMP Snooping
• Duplex mode and adjustable port speed settings
• Intuitive Windows based utility and easy configuration via Web browser
• Standard 19" (1U) Rack mount design
• 3-Year Limited Warranty
28-Port Gigabit Web Smart Switch
TEG-424WS (V1.0R)
The 28-Port Gigabit Web Smart Switch incorporates Layer 2 features
delivering a 12.8Gbps switching capacity with 24 10/100Mbps ports, 4
Gigabit ports and 2 shared Mini-GBIC slots. Management features such
as 802.1Q VLAN, QoS, IGMP snooping, Broadcast Storm Control,
Trunking and Mirroring provide a cost effective, scalable and secure
backbone SMB networking solution.
Connect a fiber network to the shared Mini-GBIC slots and/or link to other
switches using the Gigabit RJ-45 ports. Access the Web-browser
management interface and segment up to 256 Virtual Local Area
Networks, manage network priority with 802.1p support and dedicate
bandwidth with port-based Trunking.
gigabit
TEG-424WS
rev:06.29.2010
