- Page 1 OWNER’S MANUAL VACREEL ® MAN.VAC.BI Patent pending 15/587, 994 PRINTED IN CANADA (10-24)
-
Page 2: Table Of Contents
REQUIRED TOOLS / SUPPLIED EQUIPMENT / EQUIPMENT YOU NEED ..6 • Do not allow the VacReel to be used as a toy. Close supervision is necessary when THE MAIN SUPPORT ........... . . 7 used near children. - Page 3 Lateral discs Commercial hose Main support Security ring Arm guide Hose guide VREEL.50 • 50’ (15 m) commercial hose VREEL.50A • 50’ (15 m) antistatic commercial hose...
-
Page 4: Installation
REQUIRED TOOLS 1) THE MAIN SUPPORT Install the main Drainvac support to the desired area (either wall, ceiling or floor) by using the bolt pattern provided at the centrefold of this manual. Make sure the lateral discs have sufficient space to spin without any obstruction. -
Page 5: The Arm Guide
INSTALLATION INSTALLATION 2) THE ARM GUIDE • Mount the arm with the provided bolts and washers. Install the arm guide according to the VacReel’s emplacement. Ceiling Floor Wall Installation Installation Installation The hose guide can be mounted in any desired position, as long as the hose is placed in a tangential and natural manner instead of being forced into position. -
Page 6: The Reel Disc
Drainvac logo. out of the disc) and the center of the disc with a pipe WARNING: This step is crucial for the proper functioning of the VacReel. clamp and the 3 preinstalled wing nuts. -
Page 7: Hose Setup
INSTALLATION INSTALLATION 5) HOSE SETUP • It is now safe to cut off the • Untie the main hose. white tie wrap off the ratchet. • Make it go through the arm guide. • Secure the hose by placing the safety ring to the desired length, this will keep the hose from reeling all the way back and breaking the internal clock spring. -
Page 8: Make A P-Trap
VacReel in order to make a p-trap. the hose and the right one holds the tools supplied with the VacReel. • On the evacuation pipe, in the centre of the reeling disc, there are 3 lines indicating •... -
Page 9: Tension Adjustment
If the VacReel was installed onto the ceiling, you probably needed extra length in order to get a reach of the hose. If the VacReel was installed higher than 10’ (3m), you may consider tightening the tension. Otherwise, the initial tension is generally EXAMPLES OF A PROPER INSTALLATION sufficient for most cases. -
Page 10: Examples Of A Proper And Improper Installation
PIPING INSTALLATION PIPING INSTALLATION EXAMPLES OF PROPER AND EXAMPLES OF PROPER AND IMPROPER INSTALLATIONS IMPROPER INSTALLATIONS Thick wall Thin wall For wall plates only Smooth joint without Joint with inside stoppers inside stoppers... -
Page 11: How To Use
4. Start cleaning. please contact your representative. Ring seal • Reassemble. HOW TO STORE THE HOSE 1. Move closer to the VacReel and pull the hose until locking mechanism stops clicking. The VacReel starts reeling the hose. SUPPORT 2. SAFETY MEASURE:...
