Owner's Instruction and Operation Manual
Model Number:
CGWS3500
TR007-P
Report Number: F20-586
Tested Per EPA Methods ALT-125, ASTM
E2515, ASTM E3053 and CSA B415 Certified
to UL 1482-2022, CAN/ULC S627:2023
Approved
for
mobile
building installation
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result. For
your safety, follow the installation instructions. Never use make-shift compromises
during the installation of this heater. Contact local building or fire officials about
permits, restrictions and installation requirements in your area. NEVER OPERATE
THIS PRODUCT WHILE UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury, or
even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
World Marketing of America, Inc, 12256 William Penn Hwy, Mill Creek, PA 17060
R
home/transportable
Email: info@worldmkting.com PH: 1-800-776-9425
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
854097-1102N
www.P65warnings.ca.gov
Advertisement
Table of Contents
Related Manuals for Comfort Glow CGWS3500
Summary of Contents for Comfort Glow CGWS3500
- Page 1 Owner’s Instruction and Operation Manual Model Number: CGWS3500 TR007-P Report Number: F20-586 Tested Per EPA Methods ALT-125, ASTM E2515, ASTM E3053 and CSA B415 Certified to UL 1482-2022, CAN/ULC S627:2023 Approved mobile home/transportable building installation * All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
- Page 2 The instructions pertaining to the installation of your wood stove comply with UL 1482-2022 and CAN/ULC S627:2023 standards. This manual describes the installation and operation of the Comfort Glow, CGWS3500, TR007-P wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s cordwood emission limits for wood heaters sold after May 15, 2020.
-
Page 3: Installation Checklist
INSTALLATION CHECKLIST Your Wood Stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified.org/public/find-an-nfi-pro/ CUSTOMER SERVICE 1-800-776-9425 COMMISSIONING CHECKLIST This checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference. Failure to install and commission according to the manufacturer’s instructions and complete this checklist will invalidate the warranty. -
Page 4: Pedestal Assembly
ASSEMBLY FOR CUSTOMER SERVICE CALL: 1-800-776-9425 PEDESTAL ASSEMBLY STOP!! Before proceeding prepare and position the wood stove for assembly of the pedestal to the wood stove. NOTE: Remove the included parts/hardware from the NOTE: The wood stove is heavy and requires 2 or more wood stove. -
Page 5: Blower Assembly
ASSEMBLY Slide the pedestal heat shield through the front opening only with a stove that is marked to indicate such use. Do of the pedestal assembly. Use the nine (9) provided #10 not route the supply cord near or across hot surfaces! x 1/2”... -
Page 6: Installation
INSTALLATION the most efficient heat distribution possible throughout SAFETY NOTICE the house. The stove must therefore be installed in the • IF THIS STOVE IS NOT PROPERLY INSTALLED, room where the most time is spent, and in the most A HOUSE FIRE MAY RESULT. TO REDUCE THE spacious room possible. -
Page 7: Outside Combustion Air
INSTALLATION • The clearance between the flue pipe and a wall are valid Your stove does not draw steadily, smoke roll-out only for vertical walls and for vertical flue pipe. occurs, wood burns poorly, or back-drafts occur whether or not there is combustion present. •... -
Page 8: Chimney Connector (Stove Pipe)
INSTALLATION SECURE APPLIANCE TO THE FLOOR should never be more than two 90 degrees elbows in the smoke exhaust system. The installation of a “barometric Use the designated holes to secure the unit to the floor. draft stabilizer” (fireplace register) on a smoke exhaust system is prohibited. -
Page 9: Factory Built Chimney
INSTALLATION an adequate draft from your chimney. Do not connect When a metal prefabricated chimney is used, the this unit to a chimney flue serving another appliance. manufacturer’s installation instructions must The following recommendations may be useful for the followed. You must also purchase (from the same installation of your chimney: manufacturer) and install the ceiling support package or wall pass-through and “T”... -
Page 10: Combustible Wall Chimney Connector Pass-Throughs
INSTALLATION COMBUSTIBLE WALL CHIMNEY CONNECTOR PASS-THROUGHS METHOD A - 12” (304.8 mm) Clearance to Combustible Wall Member: Using a minimum thickness 3.5” (89 mm) brick and a 5/8” (15.9 mm) minimum wall thickness clay liner, construct a wall pass-through. The clay liner must conform to ASTM C315 (Standard Specification for Clay Fire Linings) or its equivalent. - Page 11 INSTALLATION METHOD D - 2” (50.8 mm) Clearance to Combustible NOTES: Wall Member: Start with a solid-pak listed factory • Connectors to a masonry chimney, excepting method built chimney section at least 12” (304 mm) long, with B, shall extend in one continuous section through the insulation of 1”...
- Page 12 OPERATING INSTRUCTIONS NEVER OPERATE THIS PRODUCT WHILE UNATTENDED be burned. Any type of well seasoned natural wood OPERATING SAFETY PRECAUTIONS may be used in your stove, but specific varieties have • NEVER OVERFIRE THIS APPLIANCE better energy yields than others. Higher efficiencies BUILDING EXCESSIVELY HOT FIRES AS A and lower emissions generally result when burning air HOUSE/BUILDING FIRE MAY RESULT.
-
Page 13: Testing Your Wood
OPERATING INSTRUCTIONS the center then the wood should be dry enough to burn. fuel. The lower heating value is when water leaves the If your wood sizzles in the fire, even though the surface combustion process as a vapor, in the case of woodstoves is dry, it may not be fully cured and should be seasoned the moisture in the wood being burned leaves the stove longer. - Page 14 OPERATING INSTRUCTIONS CAUTION: DO NOT LEAVE APPLIANCE UNATTENDED THE WITH DOOR OPEN. For a cold start-up, place 4 to 5 pieces of newspaper into the firebox. On top of the newspaper, lay 5 lbs of kindling in a random placement to ensure airflow through the kindling.
-
Page 15: Air Tubes
OPERATING INSTRUCTIONS VISIBLE SMOKE BLOWER OPERATION The amount of visible smoke being produced can be The variable-speed blower circulates air warmed by the an effective method of determining how efficiently the firebox into the living area to distribute the heat more combustion process is taking place in the given settings. -
Page 16: Chimney Maintenance
CHIMNEY MAINTENANCE NEVER OPERATE THIS PRODUCT WHILE UNATTENDED • Always check for creosote deposit once every two CAUTION: months and have your chimney cleaned at least once OVERFIRE APPLIANCE. a year. OVERFIRING IF ANY PART OF THE APPLIANCE • If a chimney or creosote fire occurs, close all dampers GLOWS RED. -
Page 17: Glass Care
CHIMNEY MAINTENANCE GASKET CARE confined areas can be dangerous. Make sure your stove gaskets and chimney joints are in good working order and sealing properly to ensure unintended exposure. It is WARNING: recommended that you use both smoke and CO monitors NEVER OPERATE THE STOVE WITHOUT THE in areas having the potential to generate CO. -
Page 18: Wiring Diagram
WIRING DIAGRAM DANGER: SHOCK HAZARD. DISCONNECT POWER SOURCE BEFORE INSTALLATION AND WHENEVER SERVICING BLOWER ASSEMBLY. CAUTION: MOVING PARTS CAN CAUSE INJURY. DO NOT OPERATE WITH COVER REMOVED. Black White Black Black Black Black Blower Blower Rheostat Motor Blower Specs: Attach Ground 110, 60 Hz AC, Green White... -
Page 19: Repair Parts
REPAIR PARTS Part # Description Part # Description 892279 Hearth Trim 894153 Ped Back, 32 892278 Top Trim 894158 Ped Right Side, 32 892268 Shield-Left, Heat 894154 Ped Base, 32 892269 Shield-Rear, Heat 894156 Ped Front, 32 891492 Blower Assembly (B36) 894157 Ped Left Side, 32 25598... - Page 20 REPAIR PARTS Part # Description 88194 C-Cast Bottom 891414 Half Firebrick 892280 Notched Firebrick 89066 Firebrick (4-1/2 x 9) 892281 1.5” Firebrick 86698 Tube(1), Air Secondary (4mm Holes) 86699 Tube(2,3), Air Secondary (3mm) 86700 Tube(4), Air Secondary (2.5mm) 86701 Tube(5), Air Secondary (2.0mm) 86702 Tube(6), Air Secondary (No Holes) 88192...
-
Page 21: Service Record
SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. -
Page 22: Limited Warranty
LIMITED WARRANTY Limited Warranty (Wood and Pellet Stoves) Warranty Period Branded Solid Fuel Burning Products Component Parts Labor Pellet Wood Component Parts Covered by this Warranty Cast Iron Components, Steel liners, Retainers, Gaskets, Firebrick and All 2 Years from Electrical Components. All Parts including handles, external enameled Date of Purchase components and other material except as covered by Warranty conditions, Warranty Exclusions, and Warranty Limitations listed. -
Page 23: Limitations Of Liability
LIMITED WARRANTY • WMAI’s obligation under this warranty does not extend to the appliance’s capability to heat the desired space. Information is provided to assist the consumer and the dealer in selecting the proper appliance for the application. Consideration must be given to appliance location and configuration, environmental conditions, insulation and air tightness of the structure. - Page 24 NOTES...
- Page 25 NOTES...
