Pre-Delivery Manual

Read the operator's manual entirely. When you see this symbol, the

subsequent instructions and warnings are serious - follow without

exception. Your life and the lives of others depend on it!

Illustrations may show optional equipment not supplied with standard unit.

ORIGINAL INSTRUCTIONS

Table of Contents

Index

HT1100-20 - HT1100-30

Manufacturing, Inc.

www.greatplainsmfg.com

Printed 2024-06-04

Index

Terra Max

TP-69605

586-831Q

Table of Contents

Need help?

Do you have a question about the Terra Max HT1100-20 and is the answer not in the manual?

Questions and answers

Summary of Contents for GREAT PLAINS Terra Max HT1100-20

Page 1 Table of Contents Index Pre-Delivery Manual HT1100-20 - HT1100-30 Terra Max Manufacturing, Inc. www.greatplainsmfg.com Read the operator’s manual entirely. When you see this symbol, the subsequent instructions and warnings are serious - follow without exception. Your life and the lives of others depend on it! TP-69605 Illustrations may show optional equipment not supplied with standard unit.
Page 2 HT1100-20 - HT1100-30 Table of Contents Index Great Plains | 586-831Q | 2024-06-04 Table of Contents Index...
Page 3 Great Plains Manufacturing, Inc. assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained herein. Great Plains Manufacturing, Inc. reserves the right to revise and improve its products as it sees fit.
Page 4 HT1100-30 Single Reel/Chopper Layout (S/N GP- E2955H+) ................84 HT1100-30 Single Reel/Chopper Layout (S/N GP- E2955H+) ................85 HT1100-30 Single Reel/Chopper Layout (S/N GP-E2954H- ) ..................86 HT1100-30 Single Reel/Chopper Layout (S/N GP-E2954H- ) ..................87 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 5: Important Safety Information
 Be prepared if a fire starts  Keep a first aid kit and fire extinguisher handy.  Keep emergency numbers for doctor, ambulance, hospital and fire department near phone. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 6: Wear Protective Equipment
 Lower implement, put tractor in park, turn off engine, and remove the key.  Secure Terra Max using blocks and supports provided.  Detach and store Terra Max in an area where children normally do not play. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 7: Tire Safety
 Wear snug-fitting clothing to avoid entanglement with moving parts.  Watch out for wires, trees, etc., when folding and raising machine. Make sure all persons are clear of working area. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 8: Pre-Assembly Check List
 Have at least two people on hand while assembling.  Make sure area is level and free of obstructions (preferably an open concrete area).  Have all major components  Have all fasteners and pins shipped with machine. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 9: Using This Manual
An orientation rose in some line art illustrations shows the directions of: Up, Back, Left, Down, Front, Right. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 10: Unload Smaller Items First
See “Assembly” on page 8 to install components needed to pull off side of trailer. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 11: Unpacking Boxes
Further Assistance Great Plains Manufacturing, Inc. wants you to be satisfied with your new Terra Max. If for any reason you do not understand any part of this manual or are otherwise dissatisfies with the product please contact: Great Plains Service Department 1525 E.
Page 12 2 Gr. 8 hex   bolts (7), lock washers and nuts. 23. Bolts may be tightened to specs, See “Torque Values Chart” on page 41 and cotter pins bent. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 13 29. Be sure hoses are routed as shown in, See “Valve Brackets & Hoses” on page 10.  Bolts may be tightened to specs, Bolts may be tightened to specs, See “Torque Values Chart” on page 41. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 14 587-186K is installed in the front position. See “HT1100-20 Machine Layout” - “HT1100-30 Machine Layout” for proper location. Use    u-bolts (5) to install on the center frame. 69599 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 15 HT1100-20 - HT1100-30 Table of Contents Index Assembly This page intentionally left blank. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 16 (19), 1.5 x 1.00 x 0.075  machine washer (11) and x 2 cotter pin (5). 38. Hook gang cylinder hoses to gang cylinders, be sure all fittings are tightened to specs, See “Hydraulic Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 17 HT1100-20 - HT1100-30 Table of Contents Index Assembly 69624 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 18 See “Purging Hydraulic System” on page 20. 46. Bolt may be tightened to specs, See “Torque Values Chart” on page 41 and all cotter pins may be bent. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 19 HT1100-20 - HT1100-30 Table of Contents Index Assembly 69627 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 20: Hitch Assembly
 Before adhering the decal to the level gauge bracket, be sure to retract the cylinder all the way, position A lines up with the red indicator. 69590 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 21 57. Do not hook up rod end of fold cylinder (7) until system is purged of air. See “Purging Hydraulic System” on page 20. 58. Bolt may be tightened to specs, See “Torque Values Chart” on page 41. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 22: Gauge Wheel
65. Fasten hoses to wings with bolts and clamps (provided). Attach hose wraps on hoses to prevent hoses from dragging or getting pinched. 66. Also see Hydraulic Layouts in “Appendix Section” for all hose routing. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 23: Attach Hose Clamps And Hose Wraps
43972 Hydraulic Hose Hookup 69. Great Plains hydraulic hoses are color coded to help you hookup hoses to your tractor outlets. Hoses that High Pressure Fluid Hazard: go to the same remote valve are marked with the Relieve pressure before disconnecting hydraulic lines.
Page 24: Purging Hydraulic System
 up to wing with the 1 x 3 usable pin (6), 1.5 x 1.0  x.075 machine washer and x 2 cotter pin. Bend cotter pin over to secure. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 25 78. Attach gauge link (7) to ear on front of center frame gang bar and gauge bracket assembly (5), secure with    hex bolts (8) and top lock nuts. 79. Bolt may be tightened to specs, See “Torque Values Chart” on page 41. 69598 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 26: Rear Lights
RH (2) light brackets to plates of center drag   frame (4) with the x 2 bolts (3), lock washers  nuts. 85. Tighten all bolts to specs, See “Torque Values Chart” on page 41. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 27 Angle to Fore/Aft Leveling between the lead to the tractor, and the harness that connects to the proximity sensors. If this is not done correctly then 69799 Switching From Fore/Aft to Gang will ONLY work when the machine is folded. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 28 (4) leads. 93. Be sure and get all wiring harnesses fastened up securely with hose wraps or clamps (if routed close to hydraulic hoses) or use cable ties. 77249 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 29 ”, from front of proximity sensor (3) to rear before unfolding. Be sure wing safety lock pins are of wing tube (4) as shown. installed. 95. Re-tighten nuts (2) to secure proximity sensor (1). 77240 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 30 (4) leads. 100. Be sure and get all wiring harnesses fastened up securely with hose wraps or clamps (if routed close to hydraulic hoses) or use cable ties. 69628 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 31 ”, from front of proximity sensor (3) to rear of before unfolding. Be sure wing safety lock pins are wing tube (4) as shown. installed. 102.Re-tighten nuts (2) to secure proximity sensor (1). 43015 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 32: Install Decals
105.Install one, 848-972C bypass valve operating instruction decal (3) on front of truss (left side) (4). 106.Install two, model number decals (5) on front of brace bar (one each side). 69607 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 33: Rolling Harrow (Optional)
 Re-installation instructions are to place left ball joint brackets (6) in proper location from layout drawing and torque u-bolts to 150 ft-lb. Leave right ball joint bracket (7) loose, as it may need move a little while you bolt up the left rolling harrow bracket (3). 42439 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 34  Please note the direction of travel, if chopper reels are not installed with the indication arrows pointing forward damage may occur. Please see layouts for dimensions and placement, and Part Manual for a complete list of parts. Great Plains | 586-831Q | 06/04/2024 Table of Contents...
Page 35 HT1100-20 - HT1100-30 Table of Contents Index Assembly Arrows on Chopper Wheel indicate direction of rotation. 77387 Travel Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 36  Please note the direction of travel, if chopper reels are not installed with the indication arrows pointing forward damage may occur. Please see layouts for dimensions and placement, and Part Manual for a complete list of parts. Great Plains | 586-831Q | 06/04/2024 Table of Contents...
Page 37 HT1100-20 - HT1100-30 Table of Contents Index Assembly Arrows on Chopper Wheel Arrows on Chopper Wheel indicate direction of rotation. indicate direction of rotation. Travel Travel 77179 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 38  The assembly instructions are the same for the Single Round Tube Reel option.  See “HT1100-20 & 25 Single Reel Hydraulic Layout” starting on page 52 for hose routing or the parts manual for complete part breakdown. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 39 HT1100-20 - HT1100-30 Table of Contents Index Assembly 69686 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 40  The assembly instructions are the same for the Double Round Tube Reel option.  Please see layouts for dimensions and placement, and Part Manual for a complete list of parts. Great Plains | 586-831Q | 06/04/2024 Table of Contents...
Page 41 HT1100-20 - HT1100-30 Table of Contents Index Assembly 77209 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 42 138. Hook the hydraulic hoses to the cylinders, rod to rod, and base to base. 139.Purge the hydraulics of air and check for leaks.  Please see layouts for dimensions and placement, and Part Manual for a complete list of parts. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 43 HT1100-20 - HT1100-30 Table of Contents Index Assembly 69613 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 44: Weight Package Assembly (Optional)
 washers and nuts.  148.Torque x 2 Gr. 8 bolts (1) to 375 ft-lbs to be sure bolts do not work loose and cause damage to machine. 42408 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 45: Appendix: Reference Information
Rolling Harrow Spike Bolt 1 1/2”-6 650-750 Foot-pounds (175 lbs on 4’ cheater). Wheel Bolt Torque Values 1/2”-20 (75-85ft-lbs) Wheel Bolt Torque Values 9/16”-18 (80-90ft-lbs) Wheel Bolt Torque Values 5/8”-18 (85-100ft-lbs) Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 46: Tire Inflation Chart
-18 ORB w/jam nut 16-22 12-16  -18 ORB straight 24-33 18-24  -16 JIC 37-53 27-39  -16 ORB w/jam nut 27-41 20-30  -16 ORB straight 37-58 27-43 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 47 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information This page intentionally left blank. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 48: Hydraulic Lift Layout
HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information Hydraulic Lift Layout TP-69641 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 49 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 & 25 Hydraulic Fold Layout TP-69636 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 50 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Hydraulic Fold Layout TP-69637 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 51 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 & 25 Hydraulic Gang Angle Layout TP-69642 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 52 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Hydraulic Gang Angle Layout TP-69643 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 53 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 & 25 Double Reel Hydraulic Layout TP-69644 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 54 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Double Reel Hydraulic Layout TP-69645 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 55 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information This page intentionally left blank. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 56 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 & 25 Single Reel Hydraulic Layout TP-77401 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 57 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 & 25 Single Reel Hydraulic Layout TP-77402 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 58 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Single Reel Hydraulic Layout TP-77403 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 59 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Single Reel Hydraulic Layout TP-77404 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 60 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-20 Machine Layout TP-69640 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 61 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information This page intentionally left blank. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 62 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-25 Machine Layout TP-69638 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 63 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-25 Machine Layout TP-69639 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 64 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Machine Layout TP-69646 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 65 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information HT1100-30 Machine Layout TP-69647 Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 66 Appendix - Reference Information HT1100-20 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) Round Bar Double Reel Arm & Reel Assembly TP-77250 Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 67 Appendix - Reference Information HT1100-20 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) Round Bar Double Reel Arm & Reel Assembly TP-77251 Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 68 Appendix - Reference Information HT1100-20 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69649 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 69 Appendix - Reference Information HT1100-20 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69650 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 70 Appendix - Reference Information HT1100-25 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) TP-77252 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 71 Appendix - Reference Information HT1100-25 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) TP-77253 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 72 Appendix - Reference Information HT1100-25 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69651 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 73 Appendix - Reference Information HT1100-25 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69652 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 74 Appendix - Reference Information HT1100-30 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) TP-77254 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 75 Appendix - Reference Information HT1100-30 Double Reel/Rolling Harrow Layout (S/N GP-E2612H+) TP-77255 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 76 Appendix - Reference Information HT1100-30 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69653 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 77 Appendix - Reference Information HT1100-30 Double Reel/Rolling Harrow Layout (S/N GP-E2611H-) TP-69654 Round Bar Double Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 78 Index Appendix - Reference Information HT1100-20 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77399 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 79 Index Appendix - Reference Information HT1100-20 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77400 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 80 Index Appendix - Reference Information HT1100-20 Single Reel/Chopper Layout (S/N GP-E2954H-) TP-77191 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 81 Index Appendix - Reference Information HT1100-20 Single Reel/Chopper Layout (S/N GP-E2954H-) TP-77192 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 82 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77397 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 83 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77398 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 84 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2612H-E2654H) TP-77311 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 85 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2612H-E2954H) TP-77312 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 86 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2611H-) TP-77193 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 87 Index Appendix - Reference Information HT1100-25 Single Reel/Chopper Layout (S/N GP-E2611H-) TP-77194 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 88 Index Appendix - Reference Information HT1100-30 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77395 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 89 Index Appendix - Reference Information HT1100-30 Single Reel/Chopper Layout (S/N GP-E2955H+) TP-77396 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 90 Index Appendix - Reference Information HT1100-30 Single Reel/Chopper Layout (S/N GP-E2954H-) TP-77195 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 91 Index Appendix - Reference Information HT1100-30 Single Reel/Chopper Layout (S/N GP-E2954H-) TP-77196 Flat Bar Reel Arm & Reel Assembly Locations will be the same as shown on each model layout. Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 92 HT1100-20 - HT1100-30 Table of Contents Index Appendix - Reference Information Great Plains | 586-831Q | 06/04/2024 Table of Contents Index...
Page 93 ............. 2 GP-C2556H+) ........24 weight package........40 left-hand, defined ......... 5 HT1100-30 ...........4 Numerics level ............7 hydraulic hoses ........19 11L-15SL 12-Ply .........42 lifters ............ 1 Hydraulic Reel Down Pressure Kit ..38 Great Plains | 586-831Q | 06/04/2024 Cover Table of Contents...
Page 94 HT1100-20 - HT1100-30 Cover Table of Contents Index 12.5Lx15" 12-Ply ........42 586-831M, manual .......4 586-831P, manual ........4 586-831Q-ENG, manual .......4 586-831Q, manual ........4 9.5Lx15" 8-Ply ........42 Great Plains | 586-831Q | 06/04/2024 Cover Table of Contents...
Page 95 Table of Contents Index Table of Contents Index...
Page 96 Table of Contents Index Great Plains, Mfg. 1525 E. North St. P.O. 5060 Salina, KS 67402...

This manual is also suitable for:
