Thomas Regout BalanceBox 400 Installation Manual

Height adjustable manual mount
Hide thumbs Also See for BalanceBox 400:

Advertisement

Quick Links

Download this manual
Installation manual
®
Mobile Stand Mix
item number: 481A71001
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the BalanceBox 400 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Thomas Regout BalanceBox 400

Summary of Contents for Thomas Regout BalanceBox 400

  • Page 1 Installation manual ® Mobile Stand Mix item number: 481A71001...

  • Page 2: General Warnings

    ® Mobile Stand Mix General Warnings 10° Important warnings WARNING WARNING STAY ABOVE CART MAXIMUM SLOPE DO NOT PULL-DOWN WHEN MOVING before use 10 DEGREES SLOPE DOWN SLOPE Tools...
  • Page 3 ® Mobile Stand Mix Content of the box Bag with screws...
  • Page 4 ® Mobile Stand Mix Content of Bag with Screws Key-size: Needed tool: F: 4x M10x30 G: 4x M8x20 H: 2x M6x30 K: 4x M8 Not included...
  • Page 5 ® Mobile Stand Mix Mount the casters Mount the casters with the brake at the front (the long end of the legs) (2x) Put both legs on the table flat side down to push the casters into their mounting holes (2x) E DO NOT USE A...
  • Page 6 ® Mobile Stand Mix Assemble the wheelbase and column (2x) (1x) (2x) F (1x) B TIGHTEN MIN. 15 ft-lb / 20Nm F: 4x M10x30 Make sure the top plate of each leg touches the topside of the cross bream before tightening the screws...
  • Page 7 ® Mobile Stand Mix ® Mounting BalanceBox 400* on the Mobile stand (*not included) Position 1 Adult use ® BalanceBox 400* Position 2 Child use ® Mount the BalanceBox 400* at the desired position Please follow the mounting instructions of the ®...
  • Page 8 ® Mobile Stand Mix Mounting VESA bracket 481A70* on the Mobile Stand (*not included) Position 1 Adult use Position 2 Child use VESA bracket 481A70* Mount the VESA bracket 481A70 Please follow the mounting instructions of 481A70 2x M6x12 2x M8x12...
  • Page 9 ® Mobile Stand Mix Mounting 3rd party VESA bracket on the Mobile Stand (*not included) Position 1 Adult use Position 2 Child use Party VESA bracket Mount the 3rd party VESA bracket Please follow the mounting instructions of the 3rd party K: M8 VESA bracket K: M8...
  • Page 10 Regout Balance Systems B.V. Thomas Regout Inc. Industrieweg 40 145 Bluffs Court 6219 NR Maastricht Canton, GA 30114 The Netherlands...

This manual is also suitable for:

481a71001
