Morbark 3200 Operator's Manual

Wood hog
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3200
WOOD HOG
SAFETY
OPERATOR
MANUAL
76347-348
10/11
1
•

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Morbark 3200

Summary of Contents for Morbark 3200

  • Page 1 3200 WOOD HOG SAFETY OPERATOR MANUAL 76347-348 10/11 •...
  • Page 2 Morbark parts and service, the solution to your problems. Buying your parts elsewhere just does not pay. To keep your equipment performing at its peak use GENUINE MORBARK PARTS 800-255-8839 800-832-5618 fax www.morbark.com •...
  • Page 3 MANUAL REVISION LOG Revision: Date Issued: Pages Affected: Description of Changes: June 13, 2013 Initial Release January 15, 2016 3, 38-39 Rev log added, Updated Routine Maintenance Schedule, added Mill Bearing Lube Decal.TOC Updated. February 24, 2016 3, 38-39 Updated Routine Maintenance Schedule, added Mill Bearing Lube Decal.
  • Page 4 •...

  • Page 5: Introduction

    Thank you for purchasing a Morbark, Inc. product. Before we begin this manual, the people at Morbark, Inc. want you, the owner-operator, to know this piece of equipment can be very dangerous if safety procedures and warnings are ignored. Read & understand this manual carefully, page by page before operating machine.

  • Page 6: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION ���������������������������������������������������������������������������������������������������������������������������������������������5 LOCKOUT PROCEDURES �����������������������������������������������������������������������������������������������������������������������������8 SPECIFICATIONS �������������������������������������������������������������������������������������������������������������������������������������������9 MAIN COMPONENTS �����������������������������������������������������������������������������������������������������������������������������������10 SAFETY �������������������������������������������������������������������������������������������������������������������������������������������������������� 11 SAFETY SIGNS ��������������������������������������������������������������������������������������������������������������������������������������������15 CRIME PREVENTION ����������������������������������������������������������������������������������������������������������������������������������� 17 ENGINE CONTROLS ������������������������������������������������������������������������������������������������������������������������������������20 REMOTE CONTROLS ����������������������������������������������������������������������������������������������������������������������������������23 CENTER SECTION CONTROLS ������������������������������������������������������������������������������������������������������������������26 VALVE BANK CONTROLS ���������������������������������������������������������������������������������������������������������������������������27 SAFETY OPERATION ����������������������������������������������������������������������������������������������������������������������������������28 NEW POWER UNIT BREAK-IN ..............................
  • Page 7 ADJUSTING THE DISCHARGE CONVEYOR .......................... 60 CENTERING THE DISCHARGE CONVEYOR ......................... 60 ADJUSTING THE INFEED BED CHAIN ........................... 61 SERVICING TIRES ................................... 62 CLEAN ENGINE AREA ................................63 ENGINE OIL ....................................63 FUEL SPECIFICATIONS ................................64 RADIATOR ....................................65 BATTERIES ....................................66 SERVICING SUSPENSION ..............................

  • Page 8: Lockout Procedures

    Morbark equipment is designed to be quickly and easily locked out whenever maintenance or repairs are performed� 6�...

  • Page 9: Specifications

    SPECIFICATIONS General Length......................................40' 10 in Width ......................................8 ft 6 in Height .......................................12 ft Weight ......................................48,820 lb Axle Weight ....................................32,400 lb Electrical System ..................................24 Volts Power Options Caterpillar Cummins John Deere ............................. 440 - 600 hp Mill Features Infeed Opening ................................28 in x 57 1/2 in Drum Shaft ....................................

  • Page 10: Main Components

    MAIN COMPONENTS RECEIVING HOPPER YOKE YOKE LOCK RADIATOR SCREEN HOOD HYDRAULIC TANK MAGNETIC DRUM (OPTIONAL) FRONT STABILIZER BELLY CONVEYOR DEBRIS SLIDE BELT SHIELD AXLE •...

  • Page 11: Safety

    If these instructions are not followed, it could result in damage to the machine. DO NOT MODIFY MACHINE Any modification to the machine must be approved by Morbark. Unauthorized modifications to the machine may impair the function and/or safety and affect machine life or cause serious injury or death.
  • Page 12 SAFETY OPERATE SAFELY CAUTION: Do not allow familiarity (gained from frequent use of your machine) to become commonplace� Always remember that a careless fraction of a second is sufficient to inflict severe injury� Be sure everyone is clear of the machine. Sound horn 2 or 3 times to alert all personnel and anyone else close by that you are ready to start up the power unit.
  • Page 13 SAFETY AVOID CONTACT WITH MOVING PARTS There are hazards associated with conveyor belts, V-belts, and chains. Objects or body parts can become crushed between conveyor belts, rollers, V-belts ,pulleys, chains, and sprockets. Stay away from these areas when the machine is running and follow Lockout/Tagout procedures before adjusting or performing any maintenance on any of these systems.
  • Page 14 SAFETY AVOID HIGH PRESSURE FLUIDS High pressure oil easily punctures skin causing serious injury, gangrene or death. • If injured, seek emergency medical help • Do not use finger or skin to check for leaks • Lower load or relieve hydraulic pressure before loosening fittings BATTERY SAFETY Batteries generate explosive gases.

  • Page 15: Safety Signs

    SAFETY SIGNS DANGER! STRONG MAGNET 39512-493 5” x 3 3/4” Chipper disc, drum or rotor, and their drive belts will coast for several minutes after power is shut off. DO NOT REMOVE GUARDS, OPEN DOORS, OR PERFORM MAINTENANCE UNTIL THE DISC, DRUM OR ROTOR HAS COME TO A COMPLETE STOP! FAILURE TO WAIT UNTIL DISC, DRUM OR ROTOR HAS COMPLETELY STOPPED COULD RESULT IN PERSONAL INJURY OR DEATH...
  • Page 16 SAFETY SIGNS WARNING CRUSH HAZARD Keep hands away from rollers. 39511-287 •...

  • Page 17: Crime Prevention

    CRIME PREVENTION GOOD ADVICE • Keep your machine damage-free • Reduce vandalism, discourage theft, and help recover your machine if it is stolen RECORD IDENTIFICATION NUMBERS • Record Serial Number (S/N) of machine and identification numbers of engine, clutch, hydraulic components etc. EXACTLY as they appear on the plates •...
  • Page 18 CRIME PREVENTION PARK INDOORS OUT OF SIGHT WHEN POSSIBLE 1� Remove ignition key and lock the main power switchbox. Place hard-to-move equipment in front of exits. 2� If machine is being stored, remove the battery or any essential component in the electrical system. 3�...
  • Page 19 CRIME PREVENTION REPORT THEFT 1� If a theft occurs, notify the law enforcement agency having jurisdiction and the insurance carrier immediately. 2� Give a full description and a complete set of serial and identification numbers (found on the road side of the infeed bed near the front) to the investigating officer and insurance carrier.

  • Page 20: Engine Controls

    ENGINE CONTROLS •...
  • Page 21 ENGINE CONTROLS 1� DISPLAY PANEL - Displays machine information and functions. 2� MICS DIOGNOSTIC PORT - USB connection for MORBARK INTERGRATED CONTROL SYSTEM. 3� DATA LINK HOOKUP - Provides access for caterpillar tech computer. 4� DATA LINK HOOKUP - Provides access for cummins and john deere tech computer.
  • Page 22 Morbark parts and service, the solution to your problems. Buying your parts elsewhere just does not pay. To keep your equipment performing at its peak use GENUINE MORBARK PARTS 800-255-8839 800-832-5618 fax www.morbark.com •...

  • Page 23: Remote Controls

    REMOTE CONTROLS RADIO CONTROL The remote control transmitter and receiver provided with this machine have matched radio signals that prevents unintentional operation by stray signals. However stray radio signals, high voltage power lines, and other forms of interference can cause the remote control system to stop working or work erratically.
  • Page 24 REMOTE/TETHER CONTROLS •...
  • Page 25 REMOTE/TETHER CONTROLS DANGER/CRUSH, ENTANGLEMENT HAZARD: Keep everyone clear of feedworks during operation� 1� THROTTLE - Push up to increase, push down to decrease engine RPM. 2� CONVEYOR SPEED- Push up to increase the conveyor speed, push down to decrease conveyor speed 3�...

  • Page 26: Center Section Controls

    YOKE LOCK SWITCH - Engages and disengages the yoke lock. WARNING: When the yoke switch is released, the yoke assembly will lower to the infeed bed� INFEED BED Shuts the engine down. OVERVIEW OF 3200 Woodhog Engine Master Disconnect Sets the yoke lock Raises or lowers...

  • Page 27: Valve Bank Controls

    VALVE BANK CONTROLS 1� CONVEYOR FOLD - This lever will fold and unfold the top conveyor. 2� CONVEYOR LIFT - This lever will raise and lower the conveyor. 3� BELLY CONVEYOR - This lever will start and stop the belly conveyor. 4�...

  • Page 28: Safety Operation

    SAFETY OPERATION For a safe and productive operation, read the safety section thoroughly along with the controls section before start up. All personnel (not just the operator) shall read this section and understand the operation of this machine and the dangerous areas to avoid.

  • Page 29: Pre-Operational Checklist

    SAFETY OPERATION PRE-OPERATIONAL CHECKLIST 1� It is the operator’s responsibility to inspect the machine before the start of each workday by completing a pre-operation inspection. 2� It is recommended that each operator inspect the machine before operating, even if another operator has already put the machine into service.

  • Page 30: Starting Machine

    SAFETY OPERATION STARTING MACHINE Review the condition of the machine. 1� Place all hydraulics in the neutral position. 2� Make sure clutch is disengaged. 3� Turn main power switch to the ON position. 4� Give several blasts of the warning horn to clear area with remote or tether. 5�...
  • Page 31 SAFETY OPERATION STARTING MACHINE CON'T WARNING: Never engage the clutch with safety guards missing or with the yoke in the raised position� 9� Throttle up power unit all the way. NOTE: The feedworks will not engage until the engine RPM reaches the HI speed switch settings.

  • Page 32: Safety Procedures

    SAFETY OPERATION SAFETY PROCEDURES 1� Always make sure all filler plugs, caps, and guards are in place. DANGER/THROWN DEBRIS HAZARD Never under any circumstances, open the hood without first making sure the mill has completely stopped� CAUTION: Do not use your hand to check for mill movement� 2�...

  • Page 33: Yoke Lock Procedure

    SAFETY OPERATION YOKE LOCK PROCEDURE 1� Throttle engine down to an idle and disengage the clutch. NOTE: If your machine is equipped with a hydraulic rod puller, it must be swung away from machine before the yoke can be raised or lowered for maintenance. DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Make sure the mill has come to a complete stop before attempting any maintenance�...

  • Page 34: Hood Lock Procedure

    SAFETY OPERATION HOOD LOCK PROCEDURE 1� Throttle engine down to an idle and disengage the clutch. DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Make sure the mill has come to a complete stop before attempting any maintenance� CAUTION: Do not use your hand to check for mill movement� 2�...

  • Page 35: Machine Shut Down

    SAFETY OPERATION MACHINE SHUT DOWN 1� Place all hydraulics in neutral. 2� Throttle engine down to an idle and disengage clutch. 3� Allow engine to idle 3-5 minutes and then shut off. 4� Turn off key switch and remove ignition key. 5�...

  • Page 36: Transporting

    SAFETY OPERATION TRANSPORTING 1� Check to make sure the clutch is disengaged. 2� Make sure the mill has completely stopped, fold the conveyor to transport position. 3� Secure the conveyor with chains and binders for transport. 4� Raise machine using the stabilizers to the height needed to hook the machine to the tractor. 5�...
  • Page 37 Morbark parts and service, the solution to your problems. Buying your parts elsewhere just does not pay. To keep your equipment performing at its peak use GENUINE MORBARK PARTS 800-255-8839 800-832-5618 fax www.morbark.com •...

  • Page 38: Routine Maintenance Schedule

    ROUTINE MAINTENANCE SCHEDULE Please note that the following maintenance intervals apply for normal operating conditions only. Intervals are hours of operations based on 8 hours per day, 5 days per week. If your operating conditions are different, adjust the specified intervals accordingly. GENERAL Complete machine visual inspection (condition, leaks), clean if necessary...
  • Page 39 ROUTINE MAINTENANCE SCHEDULE Please note that the following maintenance intervals apply for normal operating conditions only. Intervals are hours of operations based on 8 hours per day, 5 days per week. If your operating conditions are different, adjust the specified intervals accordingly. HYDRAULICS Hydraulic pump belts tighten to correct tension...

  • Page 40: Routine Lubrication Schedule

    ROUTINE LUBRICATION SCHEDULE •...
  • Page 41 ROUTINE LUBRICATION SCHEDULE Please note that the following maintenance intervals apply for normal operating conditions only. Intervals are hours of operations based on 8 hours per day, 5 days per week. If your operating conditions are different, adjust the specified intervals accordingly. X = ONE SHOT OF GREASE 1) Infeed Chain drive and driven bearings 2) Yoke pivot pins (cylinder pins every 40 hrs.)
  • Page 42 Drain all oil out of feed wheel. With feed wheel in position shown fill hose 1 with proper amount of 80/90 gear oil. Hose 2 is for venting while filling. W6 hub (2600) 50 oz. of oil W7 hub (3200, 3800) 90 oz. of oil W12 hub (4600xl, 6600, 7600) 128 oz. of oil •...

  • Page 43: Routine Maintenance

    ROUTINE MAINTENANCE TIGHTENING TORQUE GUIDE •...

  • Page 44: How To Use A Belt Tension Gauge

    ROUTINE MAINTENANCE HOW TO USE A BELT TENSION GAUGE Before adjusting the belt tension: 1� Throttle the engine down and disengage the clutch. 2� Shut off the engine, remove the key. DANGER/CUT and PINCH HAZARD: Shut power unit off and install lockout devices before any maintenance is performed�...
  • Page 45 ROUTINE MAINTENANCE Figure 1 Figure 3 Small 0’ ring Deflection Force Scale Table 1 Small Sheave Deflection force in lbs. for Drive Speed Ratio of; V-belt- Section Speed Range Diameter 4.0+ 1200 - 1800 Figure 2 1200 - 1800 1200 - 1800 1200 - 1800 900 - 1800 900 - 1800...

  • Page 46: Changing Mill Hammers

    ROUTINE MAINTENANCE CHANGING MILL HAMMERS CAUTION: Read maintenance safety procedures carefully before beginning� This procedure should be followed whether you are changing one hammer, all hammers or changing to a different hammer pattern. Personnel performing this procedure should always wear proper safety clothing, including gloves. NOTE: Do not install the inserts on the hammers until after the hammers are installed.
  • Page 47 9� Thread the rod driver into the end of the rod. The rod driver was furnished by Morbark with your machine. 10� As each hammer or raker is guided into position, drive the rod into place until all hammers and rakers are installed and the rod is driven flush.
  • Page 48 ROUTINE MAINTENANCE CHANGING MILL HAMMERS CON'T 12� Insert the second rod in the 12 o’clock hole and attach the rod driver. 13� Position the second row of hammers, one at a time and drive the rod into position engaging the back of the first row of hammers and the front row of the second row of hammers.

  • Page 49: Hammer Rod Puller Instructions

    ROUTINE MAINTENANCE HAMMER ROD PULLER INSTRUCTIONS CAUTION: Read maintenance safety procedures carefully before beginning� This procedure should be followed whether you are changing one rod or all rods. Personnel performing this procedure should always wear proper safety clothing, including gloves. NOTE: Do not install the inserts on the hammers until after the hammers are installed.
  • Page 50 ROUTINE MAINTENANCE HAMMER ROD PULLER INSTRUCTIONS CON'T 4� Removing rods is a two (2) man job. One man should be positioned on the infeed bed. The second man should be on the side of the machine opposite the drive sheave. 5�...

  • Page 51: Changing Mill Inserts

    ROUTINE MAINTENANCE CHANGING MILL INSERTS WARNING: Read maintenance safety procedures carefully before beginning� 1� Place all hydraulics in neutral. 2� Throttle engine down to an idle and disengage clutch. DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Make sure the mill has come to a complete stop before attempting any maintenance� CAUTION: Do not use your hand to check for mill movement�...

  • Page 52: Raker Maintenance

    ROUTINE MAINTENANCE RAKER MAINTENANCE NOTE: Some mill hammer patterns are designed to run with rakers. To prevent damage to the mill and surrounding components, make sure that rakers are in place and are properly maintained. Damage resulting from poor raker maintenance is not warrantable.
  • Page 53 ROUTINE MAINTENANCE RAKER MAINTENANCE CON'T 4� Locate the raker gauge on top of the mill plate, next to the raker you are checking. With the gauge in a vertical position, note the top of the raker in relation to the raker gauge. Acceptable raker height is between the top of the gauge and the notch in the front of the gauge.

  • Page 54: Hammermill Maintenance

    ROUTINE MAINTENANCE HAMMERMILL MAINTENANCE It is a good idea to get into the habit of inspecting the hammermill for wear, cracks, loose fasteners etc.while performing routine hammermill maintenance. 1� Look for cracked welds between the rotor plates. If cracks are found, refer to “ Rotor Maintenance”...
  • Page 55 ROUTINE MAINTENANCE HAMMERMILL MAINTENANCE CON'T CAUTION: Two (2) people are required at all times when performing mill maintenance� 3� If cracks are found it is highly recommended that you make the repairs before an unnecessary failure occurs. 4� The cracks will need to be ground out. The proper procedure is to grind the crack the full length with a gouge 1/8"...

  • Page 56: Hammer Pattern

    ROUTINE MAINTENANCE HAMMER PATTERN •...

  • Page 57: Replacing Grates With Supplied Chain Hoist

    ROUTINE MAINTENANCE REPLACING GRATES WITH SUPPLIED CHAIN HOIST CAUTION: Read maintenance safety procedures carefully before beginning� CAUTION: Two (2) People required at all times when changing grates� 1� Place all hydraulics in neutral. 2� Throttle engine down to an idle, disengage clutch. DANGER/THROWN DEBRIS, CUT, PINCH HAZARD: Make sure the mill has come to a complete stop before attempting any maintenance�...
  • Page 58 ROUTINE MAINTENANCE REPLACING GRATES CON'T 4� Remove rod puller from holder and install in holes on bottom side of hood. CAUTION: Refer to hoist instructions supplied with come along for proper use� 5� Position hoist onto rod puller and hook grates according to hoist instructions. 6�...
  • Page 59 ROUTINE MAINTENANCE MILL BEARING GREASING INSTRUCTIONS The mill bearings support the mill drum shaft and should be cleaned and repacked twice per year. Before performing maintenance on the mill bearings: 1� Follow steps to shut-down the machine. 2� Inspect the drum shaft. Ensure that it is smooth, free of any nicks or cuts, straight and clean. 3�...

  • Page 60: Adjusting The Discharge Conveyor

    ROUTINE MAINTENANCE ADJUSTING THE DISCHARGE CONVEYOR DANGER/THROWN DEBRIS, CUT, CRUSH HAZARD: Shut power unit off and follow lockout procedures before any maintenance is performed� If the conveyor belt slips under a load, adjust as follows. Loosen the three (3) bolts on the bearing (A) and carrier (B.) Turn adjusting bolt (C) one full turn clockwise.

  • Page 61: Adjusting The Infeed Bed Chain

    ROUTINE MAINTENANCE ADJUSTING THE INFEED BED CHAIN DANGER/THROWN DEBRIS, CRUSH, CUT HAZARD: Shut power unit off and follow lockout procedures before any maintenance is performed� If conveyor chain is not properly adjusted it will wear on itself, the drive, and idler sprockets more than normally.

  • Page 62: Servicing Tires

    ROUTINE MAINTENANCE SERVICING TIRES Maintaining proper air pressure is critical to safe operation. Correct air pressure provides balance and stability during transportation and operation. Never exceed maximum inflation pressures when sealing tire beads on rims. To add air to the tires remove the stem cap and place the air pump nozzle securely on the stem. Avoid twisting or bending the stem while adding air.

  • Page 63: Clean Engine Area

    ROUTINE MAINTENANCE CLEAN ENGINE AREA CAUTION: Never clean engine with engine running� A combination of dirt, oil, wood dust, and chip material in the engine area presents a risk of fire� Clean engine and mill area daily by blowing debris out from around power unit with compressed air.

  • Page 64: Fuel Specifications

    ROUTINE MAINTENANCE FUEL SPECIFICATIONS No. 2D diesel fuel is recommended for use in all diesel power units. In extreme cold temperatures see engine manufacturer for recommended fuel options. In selecting a fuel, note that distillate fuels are especially desirable because the fuel is heated to vaporous state and condensed, thus eliminating all sediment and residue.

  • Page 65: Radiator

    ROUTINE MAINTENANCE RADIATOR WARNING: Never open cap on a hot radiator� Check coolant level only, when engine is stopped and radiator cap is cool enough to touch with your hand� Prior to cold weather, be sure cooling system has a proper amount of antifreeze. Use a quality brand of permanent-type ethylene glycol antifreeze which contains a rust inhibitor and lubricant.

  • Page 66: Batteries

    ROUTINE MAINTENANCE BATTERIES All models are equipped with two 12 volt 8D low maintenance batteries. The batteries are located on the side of the frame. Two 12 volt-batteries are connected in series to furnish 24 volts. SERVICING BATTERIES 1� Keep battery and battery box clean. Keep all connections clean and tight. Remove all corrosion and wash terminals with a solution of baking soda and water.

  • Page 67: Servicing Suspension

    ROUTINE MAINTENANCE SERVICING SUSPENSION DANGER/LOSS OF VEHICLE CONTROL HAZARD: We strongly emphasize that each of the maintenance procedures that we will discuss have a significant safety purpose� Failure to maintain proper torque values on each of the suspension components can result in a failure of suspension components�...
  • Page 68 ROUTINE MAINTENANCE SERVICING SUSPENSION CON'T Loose operation of this bolt can result in wear requiring that new components be installed to avoid structural damage. During your visual inspection, if you observe any visible wear or loosening in the bushing, it is imperative that you immediately replace the radius rod bushing and bolt.

  • Page 69: Understanding Hydraulics

    UNDERSTANDING HYDRAULICS HYDRAULIC SAFETY NOTE: Never boost pressure settings on hydraulics. This will void the manufacturer's warranty. Be careful of: Leaks A hydraulic pump makes oil flow but there must be resistance a. Puddles of fluid are slippery and hazardous. for the flow to generate pressure.If a motor or a cylinder does b.
  • Page 70 UNDERSTANDING HYDRAULICS TESTING HYDRAULIC FLUID Test the fluid regularly. A number of formal test kits are available to evaluate the condition of hydraulic fluid or a fluid sample can be sent to a lab for evaluation. However, there are simple signs of fluid degradation such as a color shift, bad aroma or feel of grit in a sample.

  • Page 71: Servicing Hydraulics

    SERVICING HYDRAULICS THE SEVEN STEPS OF TROUBLE SHOOTING 1. Talk to the operator. 5. Test probable causes. 2. Know the system - schematics. 6. Repair the system. 3. Inspect the machine. 7. Check for root causes. 4. List probable causes. GATHER INFORMATION (STEPS 1, 2 AND 3) Information is very important.
  • Page 72 SERVICING HYDRAULICS NOISY PUMP Intake clogged: Make sure tank is cleaned periodically. Fluid must be kept 3/4 full. Air in the system: Check fittings, cracked hoses, and other parts Air leak in intake: If any air is going through pump, it will cause on the pump intake.

  • Page 73: Air Filter Maintenance

    AIR FILTER MAINTENANCE 1� REMOVE THE AIR FILTER GENTLY - Accidentally bumping the air filter against the filter housing will contaminate the clean side of the housing, before the new filter element has a chance to do its job. 2� ALWAYS CLEAN THE INSIDE OF THE FILTER HOUSING AND THE GASKET SEALING SUFACES CAREFULLY - Use a clean damp cloth to wipe every surface clean.
  • Page 74 AIR FILTER MAINTENANCE NOTE: Its the customer's responsibility to follow all steps of air filter maintenance every 200 hours or every engine oil change. Low pre-cleaner efficiency will cause short element life. Low pre-cleaning efficiency can be caused by: • Leaking dust cup to air cleaner body joint;...

  • Page 75: Troubleshooting

    4. Check all motor fluid levels. ELECTRICAL NOTE: Your Morbark equipment may have an electronic engine and electronic controls. These sensitive controls have many electrical grounds throughout the machine. These grounds must be clean for the electronics to work properly. When a problem with the electrical system is suspected, first make sure all grounds are clean, dry, and have a good connection before continuing troubleshooting.

  • Page 76: Steps To Follow If You Feel You Have A Warrantable Failure

    All returned parts must be shipped freight prepaid. 4. The white, yellow and green copies need to be mailed in an envelope to Morbark Warranty, PO Box 1000, Winn, MI 48896. Both the parts and claim need to bereceived for warranty consideration.

  • Page 77: Warranty

    PURCHASERS EXCLUSIVE REMEDY� The exclusive remedy for the purchaser in the event the equipment does not conform to thisWarranty, shall be the repair or replacement of the equipment is returned to Morbark’s factory 8507 Winn Road, Winn, Michigan, or at such other location designated in writing by Morbark.
