- Page 1 I N S T R U C T I O N M A N U A L APV UFMS4 Aseptic Pressure Relief Valve MODELS: APV UFMS4 FORM NO.: H347026 REVISION: 01/2024 GB REV. 0 READ AND UNDERSTAND THIS MANUAL PRIOR TO...
-
Page 5: Table Of Contents
Installation of seals and assembly of valve 11.4. Installation of valve Assembly Tool 13.1. Installation of seat seal in valve shaft Trouble Shooting Spare Parts Lists APV UFMS4 DIN and Inch designs: RN 01.064.11 APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 1... -
Page 6: General Terms
Do not touch the open valve or yoke! Risk of injury by sudden valve operation. Before any maintenance work, depressurize the line and cleaning system and discharge the lines if possible. Disconnect electric and pneumatic connections. During disassembly you may find liquid residues in the valve. 2 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 7: Intended Use
2014/68/EU. According to Article 13, the following allocation applies for the fluids processed in the valves. Product media – Fluid group 2 – valves in all dimensions. CIP-cleaning liquids – Fluid group 1 – valves in the dimensions ≤ DN100/4“ can be used at temperatures up to 140 °C, valves in the dimensions > DN100/4“ at temperatures up to 100 °C. APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 3... -
Page 8: Mode Of Operation
Leakages at the diaphragm are indicated in the yoke area through a leakage drain. The APV UFMS4 valve is used to prevent a desired product pressure from being exceeded due to process requirements or to discharge a certain product quantity. -
Page 9: Auxiliary Equipment
If the customer decides to use valve position indicators other than those listed above, SPX FLOW cannot assume any liability for the functionality of the valve. APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 5... -
Page 10: Seat Lift Actuator
Depending on the degree and contents of soiling, the cleaning liquids, times and processes for the individual application must be scheduled. Caution! The cleaning liquid applied must be compatible with the respective seal material. 6 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 11: Installation And Commissioning
/ spindle at the actuator. 3. Test the relief pressure by increasing the pressure in the system. The valve should open when the pressure reaches the set pressure. control unit proximity switch holder APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 7... -
Page 12: Welding Instructions
If these welding instructions are not followed, any resulting damage will not be covered by the warranty. 8 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 13: Dimensions And Weights
4" 97,6 10,2 10,8 4" 97,6 17,1 17,7 * Min. response pressure is depending on the installation position and friction > 0, ** Without/With Control Unit, *** Without/With Control Unit APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 9... -
Page 14: Technical Data
Content of oil: quality class 1, max. 0,01 mg/m³ The oil applied must be compatible with Polyurethane elastomer materials. 10 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 15: Kvs Values
2,0 - 6,6 6,1 - 10 DN80 0 - 0,9 0,4 - 1,8 1,6 - 5,2 4,7 - 10 DN100/4" 0 - 0,6 0,2 - 1,2 1,0 - 3,5 3,0 - 10 APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 11... -
Page 16: Valve Stroke / Opening Cross Section
Technical Data 9.6. Valve stroke / Opening cross section (X) Dimensions in mm Stroke 22,5 19,5 Inch 1" 1,5" 2" 2,5" 3" 4" 12 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 17: Maintenance
Less suited grease types can influence function and service life. 10.1. Assembly tool To simplify the installation of the seat seal, the following assembly tools are available, see chapter 13. APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 13... -
Page 18: Service Instructions
7. Unscrew the yoke (9) from the actuator (17). Note! The actuator can be maintained. See chapter 12. Service Instructions for Actuator. 8. Detach the O-Ring (13) and guide bushing (11). 14 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 19: Installation Of Seals And Assembly Of Valve
(22) and fasten it. Hold up the centering washer during this process. Tightening torque: 40 Nm. O-ring (16) diaphragm (5) 5. Install the CU adapter on Actuator (17). tie rod (8) lower shaft (3) seat seal (2) APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 15... -
Page 20: Installation Of Valve
12. Place the actuator in the closed limit position and carry out positioning of the second proximity switch. positioning screws o-ring feedback cam hex nut centering washer guide rod hex. screw M8 16 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... -
Page 21: Assembly Tool
1" 000 51-13-110/17 H179465 1,5" on request 2" 000 51-13-112/17 H179467 threaded bolt 2,5" 000 51-13-12017 H179468 000 51-13-113/17 H179469 3" 000 51-13-121/17 H179470 000 51-13-114/17 H179471 4" on request APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00 | 17... -
Page 22: Trouble Shooting
Please indicate the following data to place an order for spare parts: - number of required parts - reference number - designation Data are subject to change. 18 | APV UFMS4 SERIES INSTRUCTION MANUAL GB REV. 00... - Page 38 APV UFMS4 Aseptic Pressure Relief Valve Production Design Center Stanisława Jana Rolbieskiego 2 Gottlieb-Daimler-Straße 13 Bydgoszcz 85-862 59439 Holzwickede Poland Germany P: (+48) 52 566 76 00 P: (+49) (0) 2301-9186-0 F: (+48) 52 525 99 09 F: (+49) (0) 2301-9186-300 www.spxflow.com/APV Improvements and research are continuous at SPX FLOW, Inc.
