USER MANUAL
AMYET EV900S Electric Bike

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EV900S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AMYET EV900S

Summary of Contents for AMYET EV900S

  • Page 1 USER MANUAL AMYET EV900S Electric Bike...
  • Page 2 Quick Start Guide...

  • Page 3: Table Of Contents

    CONTENTS Important Safety Information EV900S Parts Identification Configuration Table Pre-Ride Safety Checklist 05-07 Driving Safety 08-10 Assembly Instructions 11-15 Display and Setting 16-21 Error Codes of The Display Charging and Battery Atention 23-24 Inspection Instructions Notes and Cautions 25-26 Warranty...

  • Page 4: Important Safety Information

    AMYET EV900S E-bike IMPORTANT SAFETY INFORMATION Warning Electric bikes can be dangerous to use. The user or consumer assumes all risk of personal injuries, damage, or failure of the bicycle or system and all other losses or damages to themselves and others and to any property arising as a result of using the bicycle.

  • Page 5: Ev900S Parts Identification

    AMYET EV900S E-bike EV900S PARTS IDENTIFICATION Integrated Colorful Display 7 Speed Gears Twist-grip Throttle Turn Signals Control Rear mount Bike Frame Seat LED Headlight Rear Light Removable battery Disc Brake Bike motor Tire Rear derailleur Pedals Crank...

  • Page 6: Configuration Table

    AMYET EV900S E-bike Configuration Table Item Name Product specification The vehicle size 70*27*45 inch 63*14.57*34.65 inch Packing Size Color Black and White The frame material Aluminum /AL6061 Net Weight 79.37lb Gross Weight 100.32lb Max. Support Weight 330lb Power cycling/Before the...

  • Page 7: Pre-Ride Safety Checklist

    AMYET EV900S E-bike Pre-Riding Safety Checklist Notice:Before every riding,and after every 25-45 miles,we advise following the pre-riding safety checklist in the table below. Safety Check Basic Steps Ensure front and rear brakes work properly Check brake pads for wear and ensure they are not...
  • Page 8 AMYET EV900S E-bike Pre-Riding Safety Checklist Ensure all bearings are lubricated,run freely,and display no excess movement grinding,or rattling 5.Bearings Check headset,wheelbearings,pedal bearings,and bottom bracket bearings Ensure pedals are securely tightened to the cranks 6.Cranks and Pedals Ensure the cranks are securely tightened and are...
  • Page 9 AMYET EV900S E-bike Pre-Riding Safety Checklist Look over connectors to make sure they are fully seated,free from debris or moisture 11.Electrical Cables Check cables and cable housing for obvious signs of damage Ensure headlight,taillight,and brake light are functioning adjusted properly,and unobstructed Ensure all reflectors are properly fitted and not obscured...

  • Page 10: Driving Safety

    AMYET EV900S E-bike Drive Safety Please strictly abide by the traffic rules and safe driving speed control within safe speed,(default of safe speed is 30km/h) Before you dive,please be familiar with the contents of this manual. Then find an empty,flat training,have complete control of the vehicle diving essentials and familiar with its structure, it is the foundation of safe driving.
  • Page 11 AMYET EV900S E-bike Drive Safety 7. Check whether the front and rear screw lock and chain conditions are in good condition. 8. Check the shaft fastening condition,ensure the front and rear axles and handlebar clamp reliable. Drive properly: 1. Please stand before you start the bike to the left of the main bracket stand, view the vehicle without exception.
  • Page 12 AMYET EV900S E-bike Drive Safety 6.Still tighten the control of of motor speed after driving should be avoided in the brake of the phenomenon.so as to avoid the motor overload and damage other parts too much. 7.In the mud or as far as possible when driving on rough road with human drives.

  • Page 13: Assembly Instructions

    AMYET EV900S E-bike Assembly Instructions The following assembly steps are only a general guide to assist in the assembly of your bike from electric bikes and is not a complete or comprehensive manual of all aspects of assembly, maintenance, and repair.
  • Page 14 AMYET EV900S E-bike ASSEMBLY 1. Handlebars Use a screwdriver to twist the 4 screws of Unscrew this part to initially secure the the driving rod; handlebars; Pick up the handlebars to fix the position adjust the Angle, tighten the 4 screws, pay attention to lock the screws to prevent loosening;...
  • Page 15 AMYET EV900S E-bike ASSEMBLY 2.Front wheels Clamp the front wheel in the correct position, as shown in the following figure； Pass the quick release through the front wheel, install spring and a nut on its other side,and finally tighten the quick release；...
  • Page 16 AMYET EV900S E-bike ASSEMBLY 3.Front fender Secure the left and right sides of the front Put the front fender through as shown in the fender to the positions shown on the two picture; sides of the front fork; 4.Headlight Take out the headlight, open the patch on...
  • Page 17 Thread the left pedal onto the left crank gently by hand, turning counter-clockvsise. Then tighten pedal by allen wrench; Note: If the pedal/ chain doesn't run smoothly or something seems misaligned, please contact AMYET Support.

  • Page 18: Display And Setting

    AMYET EV900S E-bike DISPLAY AND SETTING Braking Fault Alarm Charging Battery Lever Display Backlight SPEED Speed Speed Unit Km/h Pow Trip ODO Time Pedal Assist Level Odometer Mile LCD Display Controls Operation Directions Press and hold U until power engages(turn Turn on bike the battery first) (3)
  • Page 19 AMYET EV900S E-bike DISPLAY AND SETTING Functional Specification: 1. Display Function Speed display, power gear display, power indicator, fault warning, total mileage, single mileage, headlight display, single travel time display. 2. Control And Set Functions Power switch control, headlight switch control, 6Km/h point control, wheel diameter setting, maximum speed setting, idle automatic sleep time setting, backlight brightness setting, voltage level setting.
  • Page 20 AMYET EV900S E-bike DISPLAY AND SETTING Pow Trip ODO Time 3.3 Multifunction display area Mile Total mileage ODO, single mileage TRIP, digital voltage Pow, singleride Time time, metric mileage Km, British mileage Mile; 3.4 Pedal assist mode 0-9 modes can be displayed, 6km boost and cruise display 3.5 Speed display area...
  • Page 21 AMYET EV900S E-bike DISPLAY AND SETTING 3.7 Setting P01: Backlight brightness, level 1 is the darkest, level 3 is the brightest; P02: Unit of mileage, 0: KM; 1: MILE; P03: Voltage level: 24V, 36V, 48V, default 36V; P04: Sleep time: O, no sleep; Other numbers are sleep time, ranging from 1 to 60;...
  • Page 22 AMYET EV900S E-bike DISPLAY AND SETTING P11: Assist sensitivity setting range: 1-24; P12: PAS setting range: 0-5; P13: The type of the assisted magnetic steel plate is set in 3 types: 5,8,12 magnetic steel; P14: The default current limiting value of the controller ranges from 1 to 20A;...
  • Page 23 AMYET EV900S E-bike DISPLAY AND SETTING (2) Short Press PAS - 1 2. Switching speed display Long press Change the speed display mode 3. Set/deactivate 6Km/h cruise, switch headlights on and off, ODO clear zero When the vehicle is stationary, press and hold Enter 6KM/h cruise mode and exit cruise mode with your hands off;...

  • Page 24: Error Codes Of The Display

    AMYET EV900S E-bike ERROR CODES OF THE DISPLAY Status code (decimal) Indications Note Normal Reserved Brake PAS Sensor Failure (riding mark) Not Realized 6km/h Cruise Real-Time Cruise Low Battery Motor Failure Throttle Failure Controller Failure Communications Receiving Failure Communications Sending Failure...

  • Page 25: Charging And Battery Atention

    AMYET EV900S E-bike CHARGING AND BATTERY ATTENTION Charging Instructions 1. Find the battery charging port (near the battery compartment' s key port). 2. First, connect the output plug of the charger with the charging port of the bicycle properly, and then connect the input plug of the charger to the power socket.
  • Page 26 AMYET EV900S E-bike CHARGING AND BATTERY ATTENTION shorten its service life. 9. Keep battery on the dry conditions. Do NOT let the water into the battery, which may lead to electric shock or short circuit. If water enters the battery, do NOT charge the battery until the water evaporates completely.

  • Page 27: Inspection Instructions

    AMYET EV900S E-bike INSPECTION INSTRUCTIONS 1. Check the tension of the chain and spokes to make sure there is no noise or loosening. 2. Ensure that all mechanical components can work normally, i.e., wheels, pedals and handlebars turn freely without unnecessary noise.

  • Page 28: Notes And Cautions

    AMYET EV900S E-bike NOTES AND CAUTIONS 5. Do NOT clean the electric bicycle under water or using the highpressure cleaning machine. 6. Clean the frame, front fork, saddle and wheels with a soft, wring-out, damp cloth. 7. Clean the electrical components or electrical related parts with a soft dry cloth.
  • Page 30 Support@amyet.com AMYET EV900S ELECTRIC BIKE The manufacturer reserves the right to make changes to the product and manual at any time...
