Q U I C K S T A R T
What's what?
Important components labeled
RTE Unit Faceplate
(Front)
G U I D E
Unpack box and make sure you have everything shown here.
1
RTE Unit
Transceiver
(includes battery)
Lock
For securing interior
of RTE Unit
Exit Button
Triggers gate/door
to open
Key Switch
For enabling and
disabling unit
(Unit is disabled as
shown)
RTE Unit Faceplate
Internal wiring not shown for clarity.
Key Switch Keys
Lock Key
Carriage Bolt
(may look different)
Pairing Buttons
For pairing RTE unit
with transceiver
Relay Release Button
For manually releasing
relay when active
CR2032 Battery
On underside of
circuit board
Status LED
Indicates
transmitting status
(Back)
Internal wiring not shown for clarity.
Model
Hex Nut
Hole Plug
( 4x )
( 4x )
Connection Terminals
For wiring to compatible
AC/DC power source and
gate operator or door opener
Power LED
Indicates whether or
not unit has power
Relay Status LED
Indicates whether relay is
active or inactive
(Relay is active when lit)
Programming Button
For pairing transceiver
with RTE unit
Programming LED
Indicates status of
pairing process
Transceiver
Shown with cover removed.
1 of 4
14-RTE433
Screwdriver

Advertisement

loading
Need help?

Need help?

Do you have a question about the Ridge RTE 14-RTE433 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Security Brands Ridge RTE 14-RTE433

  • Page 1 1 of 4 Q U I C K S T A R T G U I D E 14-RTE433 Model Unpack box and make sure you have everything shown here. RTE Unit Transceiver Key Switch Keys Lock Key Carriage Bolt Hex Nut Hole Plug Screwdriver...
  • Page 2 Power Source Power Source Terminals vary widely across Terminals vary widely across ALWAYS USE SAFETY DEVICES! (Not Included) (Not Included) manufacturers and models. manufacturers and models. © 2024 Security Brands, Inc. All rights reserved. IG-14RTE433-EN-US Rev. A (8/2024)
  • Page 3 3 of 4 Q U I C K S T A R T G U I D E 14-RTE433 Model Remove transceiver cover; then Remove RTE unit faceplate. Hold down both Pairing Buttons until Status LED hold down Programming Button on flashes.
  • Page 4 Step 2 - If antenna wire coil is in wrong position, unscrew terminal block, move wire coil to next terminal block, and screw down to secure. Call (972) 474-6422 Email support@summitcontrol.com We are available Mon–Fri / 8am–5pm Central © 2024 Security Brands, Inc. All rights reserved. IG-14RTE433-EN-US Rev. A (8/2024)
