Summary of Contents for BirdReel HM01
- Page 1 HM01/HM02 智能蜂⻦喂⻝器 2024.01.16 说明书 2024.01.16 1.单⻚尺⼨ : 125*125mm 2.105g双铜+4C印刷+表⾯连线光油 最后⼀⻚ 封⾯ 空⽩⻚ ⽬录 第1⻚ 第2⻚ 第3⻚ 第4⻚ 第5⻚ 第6⻚ 第7⻚ 第8⻚ 第9⻚ 第10⻚ 第11⻚ 第12⻚ 第13⻚ 第14⻚ 第15⻚ 第16⻚ 第17⻚ 第18⻚ 第19⻚ 第20⻚...
- Page 2 Smart Hummingbird Feeder User Manual...
-
Page 4: Table Of Contents
CONTENT Warm tips...........................1 What’s in the box.......................2 Specifications for bird feeder ..................3 Introduction for bird feeder.....................4 Indicator light........................5 How to connect to the APP ..................6-10 APP interface introduction...................11 How to install ......................12-16 How to charge........................17 FAQ ..........................18-20... -
Page 5: Warm Tips
5.Please use 2.4 GHz WI-FI to connect the application. 6.Please stay away from the strong light when pairing. 7.Please keep the bird feeder within the range of WI-FI signal. HM01 HM02 Take HM01 as an example and install it as follows. -
Page 6: What's In The Box
WHAT’S IN THE BOX Bird House Nectar Plate Brackets Green screws Screw for Screw for Charging cable spacers *4 bracket *4 perch*2 Reset Pin Transparent Nut Waterproof Drill Sticker Screws rubber... -
Page 7: Specifications For Bird Feeder
SPECIFICATIONS FOR BIRD FEEDER Product Model HM01/HM02 Charging Solar panels and mobile power Battery 5000 mAh Rechargeable Lithium-Ion Battery Resolution 2.0MegaPixels Photos and 1080P HD Live Stream Video Operating Temperature -5°F to 120°F (-20.5°C to 48.5°C) Wireless Type WIFI 2.4Ghz Field of View 130°... -
Page 8: Introduction For Bird Feeder
INTRODUCTION FOR BIRD FEEDER Bird Feeder Cover Solar Panel White Lights Bracket PIR (Infrared Motion Sensor) Camera Speaker Perch Indicator light Microphone Light Sensitive Probe... -
Page 9: Indicator Light
INDICATOR LIGHT 1.Camera turn on: Red light always ON. 2.Pairing mode: Red light fast blinking. 3.Network connecting: Green light fast blinking. 4.Network connected: Green light always ON. 5.Abnormal status : Red light slow blinking.(Need to reset) 6.During firmware update: Yellow light always ON. 7.Charging status: White light always ON during charging and OFF after fully charged. -
Page 10: How To Connect To The App
HOW TO CONNECT TO THE APP Download or scan the QR code and install the Bird Lover App for either IOS or Android. Once downloaded, the APP will prompt you to register your device. Enter your phone number or email address which one makes you feel comfortable and select the country you live in. - Page 11 1.Turn on the power switch. Ttye-c Ttye-c 2. Open the APP and connect according to the following steps.
- Page 12 3.Enter the WIFI password. * * * * ** * * * * * ** *...
- Page 13 4.Scan the QR code with the camera, and enter the connection after hearing the sound of the camera prompt. NOTE: The QR code needs to be aimed at the camera below...
- Page 14 5.Wait for the connection to complete, and click "Done" .
-
Page 15: App Interface Introduction
APP INTERFACE INTRODUCTION 1.Quality adjustment: you can choose HD or SD 2.Battery Remaining Capacity 3.Voice switch 4.Zoom in the screen for camera 5.Screen horizontal and vertical adjustment 6.Take photo 7.Bird recognition 8.Shot videos 9.Playback for previous 10.View photos or videos took 11.Check out the bird collection 12.Share the device 13.Motion detection(Click to turn on/off) -
Page 16: How To Install
HOW TO INSTALL Top cover installation Align the top cover with the groove of the birdhouse and press down, Twist and snap the top cover. - Page 17 Food plates installation (Please select 1 or 2): 1. Install nectar plate into the bird house from the top and fix , it can be filled with honey and water, it also can be removable and easy to wash it. 2.
- Page 18 Bracket Installation Method 1 (Hitting the screws): 1.Stick the sticker on the tree or wall and drill holes within the range marked on the sticker. 2.Insert the green plastic screw spacers into the hole.
- Page 19 3.Fix the bracket with long screws. 4. Snap the bird feeder into the bracket from the top and fix it with the transparent nut screw.
- Page 20 Method 2 (Bird feeder pole mount): 1. Find a suitable pole to fix bracket. 2. Snap the bird feeder into the bracket from the top and fix it with the transparent nut screw. 26mm...
-
Page 21: How To Charge
HOW TO CHARGE Remove the battery from the battery slot on the side. ① ② Insert the Type-C charging port to charge, the red light is always on during charging, and the green light is always on when fully charged. ③... -
Page 22: Faq
Q: Do I need to create an account to use the App? A: Yes, you need to use email address or phone number to get a verification code for registering an account . Q: What operating systems are the App compatible with? A: The App is compatible with Apple iOS and Android system. - Page 23 Q: What’s the language of the App? A: The App’s language will match your device's system language. But the Language of AI recognition result only supports English or Chinese now. Q: Why is the camera battery draining so fast? It is low power consumption camera. Plus the solar panel power in charge, it can maintains the daily energy consume in sunny day.
- Page 24 Q: Why the recognition result is wrong? A: The accuracy rate depends on the angle and clarity of the bird image. To get more accurate result, please ensure the picture is clear enough. The identify features (bird’s head, tail wings and pattern of feathers) should not be obscured.
- Page 25 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 26 -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected -Consult the dealer or an experienced radio/TV technician for help. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
