- Page 1 J/RS232-xx-01 Stand-Alone Media Converter User Guide Part Number 33285 Revision E August 2024...
- Page 2 J-RS232-xx-01-User-Guide Intellectual Property © 2024 Lantronix, Inc. All rights reserved. No part of the contents of this publication may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Lantronix is a registered trademark of Lantronix, Inc. in the United States and other countries.
-
Page 3: Table Of Contents
Lantronix J-RS232-xx-01-User-Guide Contents Product Description ..............................4 Ordering Information ..............................4 For More Information ..............................4 Safety Warnings and Cautions ..........................4 Installation ................................. 5 Install the Fiber Cable ............................... 6 Power the Media Converter ............................7 Operation .................................. 7 Cable Specifications .............................. -
Page 4: Product Description
Anyone using this product in such an application without express written consent of an officer of Lantronix does so at their own risk and agrees to fully indemnify Lantronix for any damages that may result from such use or sale. -
Page 5: Installation
Lantronix J-RS232-xx-01-User-Guide Installation DTE and DCE Each J/RS232-xx-01 model is configured as a: • DTE (Data Terminal Equipment) with a male RS-232 port, or a DCE (Data Communication Equipment) with a female RS-232 port. • So, the type of media converter and the application in which it is used determines which type of RS-232 cable is needed: •... -
Page 6: Install The Fiber Cable
Lantronix J-RS232-xx-01-User-Guide 3. J/RS232-CF-01 Media Converter / DTE Device: Use a straight-through RS-232 cable with a male connector when connecting a J/RS232-CF-01 or J/RS232-CF-01(SC) media converter to a DTE device/ 4. J/RS232-TF-01 Media Converter / DTE Device: Use a null-modem RS-232 cable with a female connector when connecting a J/RS232-TF-01 or J/RS232-TF-01(SC) media converter to a DTE device. -
Page 7: Power The Media Converter
Lantronix J-RS232-xx-01-User-Guide Power the Media Converter NOTE: The external power supply provided with this product is UL listed by the power supply’s manufacturer. • Connect the barrel connector on the power adapter to the media converter’s power port (located on the back of the media converter). -
Page 8: Cable Specifications
Lantronix J-RS232-xx-01-User-Guide Cable Specifications The physical characteristics must meet or exceed IEEE 802.3™ specifications. Fiber Cable Bit Error Rate: <10-9 Multimode fiber (recommended): 62.5/125 µm Multimode fiber (optional): 100/140, 85/140, 50/125 µm J/RS232-CF-01 1300 nm multimode Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm... -
Page 9: Technical Specifications
Lantronix J-RS232-xx-01-User-Guide Technical Specifications For use with Transition Networks Model J/RS232-xx-01 or equivalent Data Rate 120 Kb/s, asynchronous Dimensions 3.0" x 3.9" x 1.0" (76 mm x 99 mm x 25 mm) Shipping Weight 6 oz. (181 g) (approximately) Power Consumption... -
Page 10: Troubleshooting
Lantronix J-RS232-xx-01-User-Guide Troubleshooting If the media converter fails, isolate and correct the failure by determining the answers to the following questions and then taking the indicated action: 1. Is the PWR (power) LED on the media converter lit? • Is the power adapter the proper type of voltage and cycle frequency for the AC outlet? (See “Technical... -
Page 11: Compliance Information
Lantronix J-RS232-xx-01-User-Guide Compliance Information CISPR22/EN55022 Class A + EN55024; CE Mark FCC Regulations This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 12 48 Discovery, Suite 250 Irvine, CA 92618, USA Toll Free: 800-526-8766 Phone: 949-453-3990 Fax: 949-453-3995 Technical Support https://www.lantronix.com/technical-support/ Sales Offices For a current list of our domestic and international sales offices, go to the Lantronix web site at www.lantronix.com/about/contact. 33285 Rev. E https://www.lantronix.com...
