Connector Pin
1 SGND
YC4
Connected to 2 SGND
LCD
3 CK
4 SGND
5 SGND
6 SC
7 R0(LSB)
8 R1
9 R2
10 SGND
11 R3
12 R4
13 R5(MSB)
14 SGND
15 G0(LSB)
16 G1
17 G2
18 SGND
19 G3
20 G4
21 G5(MSB)
22 SGND
23 B0(LSB)
24 B1
25 B2
26 SGND
27 B3
28 B4
29 B5(MSB)
30 SGND
31 H_SYNC
32 SGND
33 V_SYNC
34 SGND
35 ENB
36 CM
37 3.3V
Signal I/O
- -
-
-
O
0/3.3 V DC (pulse) LCD clock signal
-
-
-
-
O
0/3.3 V DC
O
0/3.3 V DC
O
0/3.3 V DC
O
0/3.3 V DC
-
-
O
0/3.3 V DC
O DC0V/3.3V
O DC0V/3.3V
- -
O DC0V/3.3V
O DC0V/3.3V
O DC0V/3.3V
- -
O DC0V/3.3V
O DC0V/3.3V
O DC0V/3.3V
- -
O DC0V/3.3V
O DC0V/3.3V
O DC0V/3.3V
- -
O DC0V/3.3V
O DC0V/3.3V
O DC0V/3.3V
- -
O 0/3.3 V DC(pulse)
- -
O 0/3.3 V DC(pulse)
- -
O DC0V/3.3V
O DC0V/3.3V
O
3.3 V DC
Voltage
Ground
Ground
Ground
Ground
LCD Control signal
LCD Control signal
LCD Control signal
LCD Control signal
Ground
LCD Control signal
LCD control signal
LCD control signal
Ground
LCD control signal
LCD control signal
LCD control signal
Ground
LCD control signal
LCD control signal
LCD control signal
Ground
LCD control signal
LCD control signal
LCD control signal
Ground
LCD control signal
LCD control signal
LCD control signal
Ground
LCD horizontal synchronizing signal
Ground
LCD vertical synchronizing signal
Ground
LCD enable signal
LCD mode switch signal
3.3 V DC power output to LCD
2-3-42
Description
