Product And Cavity Dimensions - Haier HWO60 Installation Manual

Mounting under cooktop
The cabinetry should follow the dimensions shown . This allows for sufficient airflow behind the oven and
between the oven and cooktop for cooling . If the cabinetry base is fully sealed, an opening should be
provided to allow cool air to enter .
8
Air
entry
Product Dimensions
Overall height of oven
1
Overall width of oven
2
Overall depth of oven
3
4 Height of chassis
5 Width of chassis
6 Depth of chassis
7 Depth of door / control panel
10

PRODUCT AND CAVITY DIMENSIONS

9
!0
!1
4
6
3
7
Minimum Clearances
mm
Minimum inside height of cavity
595 8
(includes a 5mm air exit gap)
595
9 Minimum inside width of cavity
568
10 Minimum inside depth of cavity
575
Air exit vent
11
550
548
20
5
2
1
mm
600
560
560
560 x 45
