POWER SOURCES

(This picture is for illustration purpose only and may look different from the actual unit)
Connecting the AC Adapter
The AC adapter provides power for operating
your workstation and charging the batteries.
Connecting the AC Adapter
1. Plug the DC output cable into the DC-in of
your workstation.
2. Plug the AC adapter into an AC electrical
outlet. (Above Figure)
14
DC-in
DC Output Cable
AC Adapter
AC Cable
The Li-ion battery is not charged at the
point of purchase. Remember to connect
an AC adapter to your workstation to
charge it when you use it for the first time.
