Side view of CELSIUS
■ ■ Left view
(This picture is for illustration purpose only and may look different from the actual unit)
1. Kensington Lock
It allows you to attach an optional physical
lock down device.
LAN Connector
2.
It allows you to connect to a LAN (local area
network) using an optional LAN cable.
3. VGA Connector
It allows you to connect external display
devices.
HDMI Connector
4.
You can use this port to connect to a TV with
Display Port for high quality video output.
The Display Port supports both video and
audio output.
USB 3.2 (Gen 1) Connector
5.
with charging function
4
1 2 3 4 5 6 6 7 8
TM
6. Thunderbolt 3 Connector
7. Smartcard Slot
8. SD Card Slot
The Secure Digital (SD)/SDHC card slot
allows you to install a flash memory card
for data storage. Flash memor y cards
allow you to transfer data to and from a
variety of different digital devices.
