NAMES OF THE PARTS
AND THEIR FUNCTIONS
5
7
8
9
(This picture is for illustration purpose only and may look different from the actual unit)

Front features of CELSIUS

HD Camera
1.
The location of the high definition camera.
2. Display Panel
The display screen of the workstation.
LED Status Indicators
3.
Power and Suspend/Resume Button
4.
This button allows you to power on or off the
workstation. You can use also this button
to suspend workstation activity without
turning off the power to it and to resume the
workstation from suspend mode.
5. Stereo Speaker
The built-in dual speakers provide stereo
sound.

Getting to Know Your CELSIUS

The phenomena described below are
characteristics of LCD panels and do not
indicate that LCD panels are defective.
• The LCD screen of your workstation,
composes of more than 6,220,800
picture elements (number of dots when
the screen resolution is set at 1,920by
1,080 pixels). It was manufactured
using advanced technologies. For
technical reasons, LCD screen may
have pixels that do not light and pixels
that are always lit.
• LCD panels may display slight varying
colors and uneven density.
1
2
3
4
5
6
1
