Nemco Fresh-O-Matic 6625B Operating And Maintenance Instructions

Model: 6625B
INTRODUCTION
1. Please read instructions before using this appliance.
2. When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electric shock and
injury.
3. Clean machine thoroughly before and after all uses following cleaning instructions below.
ELECTRICAL REQUIREMENTS
Plug steamer into a grounded outlet with correct voltage and sufficient power capacity. Refer to the product label (serial plate) on the
Fresh-O-Matic ® for voltage and wattage requirements.
SAFETY INSTRUCTIONS
1. Warning! All power must be disconnected at power source before any service procedure is performed.
2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. Keep combustible materials, such as
drapes and other furnishings, away from appliance.
3. Extreme caution is necessary when any appliance is used by or near children and whenever the appliance is left unattended.
4. Always unplug appliance when not in use and before cleaning, adjusting or maintaining this machine. To disconnect appliance,
turn controls off and remove plug from power source.
5. Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, has been dropped, or damaged.
Return appliance to an authorized service facility for examination, electrical or mechanical adjustment, or repair.
6. Do not use outdoors. This appliance is not intended for use in wet or moist locations. Never locate appliance where it may fall
into water.
7. Connect to properly grounded outlets only. Avoid the use of extension cords. Do not run cord under carpeting, runners, or the
like. Arrange cord away from traffic area and where it will not be tripped over.
8. This appliance is equipped with a power cord with a three-blade plug. Plug ONLY into a matching three-blade outlet. DO NOT
cut or break off the third blade or attempt to use with a two-blade extension cord.
9. To prevent a possible fire, it is recommended that the unit is placed on a non-combustible surface.
10. This appliance has electrical parts. Do not use it in areas where gasoline, paint, or flammable liquids are used or stored.
PREPARATION
1. Set Fresh-O-Matic ® on a flat stable surface, near the power source.
2. Clean Fresh-O-Matic ® thoroughly before use.
3. If unit fails to work properly when first operated call NEMCO customer service at 1-800-782-6761.
OPERATION
1. Plug CORD into grounded electrical outlet of the correct voltage. Electrical shock can occur if appliance is not grounded.
2. Turn power on using the rocker switch. The steamer will be in "STANDBY" mode until the heater plate is fully heated. Pre-
heating will take approximately 20 minutes.
3. Lift "Snap Cap."
4. Fill water tank with only DISTILLED WATER until the top "FULL" water level light is illuminated (approximately 5-1/2 quarts).
Note: Do not use De-Ionized or Reverse Osmosis water. Refill as necessary - being sure to stop when the top green light is
illuminated. DO NOT OVERFILL. A funnel may be used, with care.
NOTE: IF WATER LEVEL LIGHTS FAIL TO WORK WHEN THE TANK IS INITIALLY FILLED, SLOWLY ADD TAP WATER TO
THE TANK UNTIL THE LIGHTS BEGIN TO WORK. ADD UP TO 1 CUP OF TAP WATER – DO NOT OVERFILL.
5. There is approximately 1/2 quart of water in the tank when the "LOW" light is on. The steam button may be used while the
"LOW" light is on. The "EMPTY" light will blink when the tank is empty and the steamer will not function properly until filled.
6. Fresh-O-Matic ® is ready for use when the "READY" light becomes solid green.
7. Lift cover; place food to be served in the Fresh-O-Matic ®.
8. Close cover; press Steam Button two (2) times approximately every 30 seconds. Note: Each push of the steam button releases
approximately 10 cc's (1/3 ounce) of steam/water. See "Cooking Options" for complete instructions. NOTE: The controls will
only allow the Fresh-O-Matic® to steam twice every 30 seconds.
9. When first filling the Fresh-O-Matic ®, the steam button may need to be pressed multiple times in order to prime the water
pump.
10. Open cover; food is hot, ready to serve.
NOTE: It is important to keep Fresh-O-Matic ® cover closed between uses so that proper temperature is maintained for maximum
efficiency. The cover must be closed to visually see steam and hold steam.
NEMCO FOOD EQUIPMENT
Phone: (419) 542-7751
Operating and Maintenance Instructions
Fresh - O - Matic ® Food Steamer
Fax: (419) 542-6690
www.nemcofoodequip.com
301 Meuse Argonne, Hicksville, OH 43526
Toll free: 1-800-782-6761
1
48182
3-21-2014
