H-HDPerformux-16
Step 1: Connections
Connect included
power supply
Step 2: Login to NMS
Connect the NMS port to your PC using an ethernet cable
Open web browser and go to http://192.168.0.136
Login/Password: admin/admin
Step 3: Encoder
https://thorbroadcast.com
13
14
15
16
1
2
3
4
Select
"Encoder"
from the
main menu
Input Lock MUST be
green and showing
bitrate info
800-521-8467
Quick Setup Guide
HDMI INPUTS
5
6
7
8
DATA
NMS
Select Encoder Channel
Repeat these steps
as needed for all
encoders and
sales@thorfiber.com
9
10
11
12
channels
Advertisement
Related Manuals for Thor Broadcast H-HDPerformux-16
Summary of Contents for Thor Broadcast H-HDPerformux-16
- Page 1 800-521-8467 sales@thorfiber.com H-HDPerformux-16 Quick Setup Guide Step 1: Connections Connect included HDMI INPUTS power supply Step 2: Login to NMS DATA Connect the NMS port to your PC using an ethernet cable Open web browser and go to http://192.168.0.136...
- Page 2 Step 4: Configure Outputs 1). Select 3). Click “Parse Program” “TS Config” from the main menu 2). Select SPTS or MPTS 6). Assigned programs will display under output. Click for more options. 4). Detected programs will ” 5). Press “ Button to assign appear in right pane.
- Page 3 Step 5: IP Streaming IMPORTANT: TO ACCESS STREAMS, CONNECT DEVICES TO THE DATA PORT USING AN ETHERNET CABLE 1). Select “IP Stream” from the main menu 2). Channel status must be green and showing active bitrate 3). Click top pencil icon to edit all, or click pencil icon on the same 4).
- Page 4 YOU MUST SAVE CONFIGURATION OR CHANGES WILL BE LOST AFTER Select “Configuration” RESTARTING THE UNIT from the main menu Click “Save config” Scan for more info: Confirmation message will appear briefly until saving is complete. H-HDPerformux-16 Quick Setup Guide https://thorbroadcast.com 800-521-8467 sales@thorfiber.com...
