Monitor Introduction; Front View - Asus ProArt PA278CFRV User Manual

1.3

Monitor introduction

1.3.1

Front view

Light Sensor:
1.
•
Detects ambient light source & color temperature,automatically adjust
screen brightness.
2.
Power button/power indicator
• Turns the monitor on/off. Press and hold this button for 0.6 seconds will
shut down the monitor.
• The color definition of the power indicator is as the below table.
3.
QuickFit Plus button:
• Press this button to display the OSD menu when the OSD is off.
• Selects the QuickFit Plus function.
4.
Signal button:
• Press this button to display the OSD menu when the OSD is off.
• Press this button to switch to next active input source (if available).
1-2
1
2
Status Description
White On
Amber Standby mode
Off Off
3 4 5 6
Chapter 1: Product introduction
7 8
