88 9100 103C
Granite Top
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occurring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
W.
Top
1 pc.
Hardware List
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
9100 Series
9100 Series
Top Assembly Instructions
V.
V.
Support Top
Support Top
2 pcs.
M6x30
Head Cap Bolt
6 pcs. (+1 extra)
Advertisement
Related Manuals for Home Styles 88 9100 103C
Summary of Contents for Home Styles 88 9100 103C
- Page 1 9100 Series 9100 Series completed product as it was designed. Top Assembly Instructions Part List Support Top Support Top 2 pcs. 1 pc. Hardware List M6x30 Head Cap Bolt 6 pcs. (+1 extra) Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 9100 Series Top Assembly Instructions STEP 1 Put back end of Top Supports (V) into the pre-drilled holes in unit and attach with Head Cap Bolts. Head Cap Bolt STEP 2 Place Top (W) onto the unit and then tighten all Head Cap Bolts.
- Page 3 We have taken great care in the design of this product and request that you carefully and strictly 9200 Series follow our assembly instructions to ensure a Top Assembly Instructions completed product as it was designed. Part List 1 Pc. Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 4 9200 Series Top Assembly Instructions Steel Plate Connector Flat Washer Spring Washer Head Cap Bolt (short) Figure 1 STEP 1 Remove the drawers from the unit. Place Top (W) onto the unit and attach it to the body with the Steel Plate Connectors, Flat Washers, Spring Washers and Head Cap Bolts (short).
