GE Just Cut 23142LO Manual

NHL Tree Model No. 23142LO
LED 500 C4 LIGHTS
FOR INDOOR USE ONLY
IMPORTANT SAFETY INSTRUCTIONS
When using electrical products, basic precautions should always be followed
including the following:
READ AND FOLLOW ALL SAFETY
a)
INSTRUCTIONS.
b) Do not use seasonal products outdoors unless marked suitable for indoor and
outdoor use. When products are used in outdoor applications, connect the product
to a Ground Fault Circuit Interrupting (GFCI) outlet. If one is not provided, contact
a qualified electrician for proper installation.
c) This seasonal use product is not intended for permanent installation or use.
d) Do not mount or place near gas or electric heaters, fireplaces, candles or other
similar sources of heat.
e) Do not secure the wiring of the product with staples or nails, or place on sharp
hooks or nails.
f) Do not let lamps rest on the supply cord or on any wire.
g) Unplug the product when leaving the house, when retiring for the night, or if left
unattended.
h) This is an electric product-not a toy! To avoid risk of fire, burns, personal injury and
electric shock it should not be played with or placed where small children can reach it.
i) Do not use this product for other than its intended use.
j) Do not hang ornaments or other objects from cord, wire, or light string.
k) Do not close doors or windows on the product or extension cords as this may
damage the wire insulation.
l) Do not cover the product with cloth, paper or any material not part of the product
when in use.
m)This product is equipped with push-in type lamps. Do not twist lamps.
n) Read and follow all instructions that are on the product or provided with the product.
SAVE THESE INSTRUCTIONS
o)
USE AND CARE INSTRUCTIONS
a) When the product is placed on a live tree, the tree should be well maintained and
fresh. Do not place on live trees in which the needles are brown or break off
easily. Keep the tree holder filled with water.
b) If the product is placed on a tree, the tree should be well secured and stable.
c) Before using or reusing, inspect product carefully. Discard any products that have
cut, damaged, or frayed wire insulation or cords, cracks in the lampholders or
enclosures, loose connections, or exposed copper wire.
d) When storing the product, carefully remove the product from wherever it is placed,
including tree, branches, or bushes, to avoid any undue strain or stress on the
product conductors, connections, and wires.
e) When not in use, store neatly in a cool, dry location protected from sunlight.
USER SERVICING INSTRUCTIONS
Replace the lamp.
1. Grasp plug and remove from the receptacle or other outlet
device. Do not unplug by pulling cord.
2. Pull lamp and plastic base straight out of lampholder.
3. Replace lamp with only 3.3 Volt, 0.066 Watt, LED type
lamp (provided with product).
If the new lamp base does not fit in lampholder, follow the steps below step 3.
a) Remove the base of burned out lamp by straightening lamp leads and gently pull
lamp out.
b) Thread leads of new lamp through holes in old base with one lead in each hole.
c) After lamp is fully inserted into base, bend each lead up, like other lamps in the
light set so that the leads will touch the contacts inside the lampholder.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning:
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
1. Replace lamps only with 3.3 volt, 0.066 watt spare lamps
provided with this product.
2. Risk of fire. This product does not contain lamp shunts, which allow the product
to operate if one lamp burns out. Do not replace lamps with other than the spare
lamps provided with this product.
Operate the Remote:
1. Pull out the plastic film from the battery cover to energize the remote. {Fig.1}
2. The remote has twelve buttons {Fig. 2}
a. ON/OFF – Turn set ON/OFF
b. Function – Press to change the light pattern.
Fig.2
BATTERY CAUTION:
• Always purchase the correct size and grade of battery most suitable for the
intended use.
• Replace only with lithium, type CR2025 battery.
• Clean the battery contacts and also those of the device prior to battery
installation.
• Ensure the battery is installed correctly with regard to polarity (+ and -).
• Remove battery from equipment which is not to be used for an extended
period of time.
• Remove used battery promptly.
• Non-rechargeable batteries are not to be recharged.
• Do not ingest batteries.
For questions and /or assistance, call customer service at 1-877-398-7337
or visit us on the web at www.geholidaylighting.com
©2023 Nicolas Holiday Ltd.
246 Spring Hill Road, Unit B, Trumbull CT 06611
Suite 2706 Skyline Tower, 39 Wang Kwong Road, Kowloon Bay, Kowloon,
Hong Kong All rights reserved.
GE is a trademark of General Electric Company and is under license
by Nicolas Holiday Ltd.
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE
If the product One or more of the based
does not light LEDs may have loosened
from the socket during
transporting. There is a break
in the circuit between the LED
leads and the socket
terminals. Male/female
connectors not fully inserted
together. Non working control
box. Foot pedal in off
position.
If a based One or more of the based
LED is bulbs may have come out of
missing the socket when transporting.
If an LED Incorrect LED, premature
fails to light LED failure or voltage is too
(shorts or high.
opens)
LEDs fail to If applicable, then a defective
switch from control box or color change
white to multi foot pedal.
Fig.1
FP-23 PRINTED IN CHINA
CORRECTIVE ACTION
Unplug the set at the outlet. Starting
with the first unlit LED, gently push
(don't twist) each LED base firmly
into the socket. If still does not light,
then remove each based LED and
check for out of place lead wires.
Make certain connectors fully
inserted and securing cap fully
tightened. Step on foot pedal to turn
LEDs on.
Mark socket(s) with a piece of tape
and unplug the set. Replace the
based LED or use one of the spare
based LEDs included with product.
The LED may be out or dimly lit.
Replace bad LEDs as soon as you
find them.
Contact Customer Support.
