INTRODUCTION

Complete the following steps to install a KMC Conquest
BAC-5900A Series BACnet General Purpose Controller.
For controller specifications, see the
kmccontrols.com. For additional information, see the
KMC Conquest Controller Application

MOUNT CONTROLLER

NOTE: Mount the controller inside a metal
enclosure for RF shielding and physical
protection.
NOTE: Input accuracy can be directly affected
by both internal and external factors.
Pay close attention to installation best
practices, mount product and temperature
measuring devices and other input devices
away from outside walls and drafts that
can Interfere with accurate measurements.
NOTE: To mount the controller with screws on a
flat surface, complete the steps in
Flat Surface on page
controller on a 35 mm DIN rail (such as
integrated in an
complete the steps in
page 1.
KMC Controls, 19476 Industrial Drive, New Paris, IN 46553
BAC-5900A Series Controller
data sheet at
Guide.
On a
1. Or to mount the
HCO-1103 enclosure),
On a DIN Rail on
On a Flat Surface
1. Position the controller on a flat surface so that the
color-coded terminal blocks
for wiring after the controller is mounted.
NOTE: The black terminals are for power. The
green terminals are for inputs and outputs.
The gray terminals are for communication.
2. Secure a #6 sheet metal screw through each corner
of the controller.
2
1
On a DIN Rail
1. Position the DIN rail
terminal blocks are easy to access for wiring after
the controller is mounted.
2. Pull out the DIN latch
3. Position the controller so that the top four tabs
of the back channel rest on the DIN rail.
3
/ 877.444.5622 / Fax: 574.831.5252
Installation Guide
are easy to access
1
so that the color-coded
3
until it clicks once.
4
/ www.kmccontrols.com
5
5
4
