Flushmate 504 Series Owner's Service Manual
Flushometger toilet tank system
Hide thumbs
Also See for 504 Series:
- Pocket manual (15 pages) ,
- Owner's operation and installation manual (9 pages) ,
- Owners operation and installation manual (12 pages)
Subscribe to Our Youtube Channel
Related Manuals for Flushmate 504 Series
Summary of Contents for Flushmate 504 Series
- Page 1 CLICK ANYWHERE on THIS PAGE to RETURN to WATER Owner’s Service Manual SAVING TOILETS at InspectApedia.com 503 and 504 Series FLUSHOMETER - TANK SYSTEM...
-
Page 2: Installation
FLUSHMATE ® 503 AND 504 SERIES FLUSHMATE ® Function: Less than 1.6 gpf/6.0 Lpf Installation Requirements: min. 20 psi static water pressure* FLUSHMATE ® Function: Less than 1.0 gpf/3.8 Lpf Installation Requirements: Cold potable water system, min. 25 psi static water pressure* *max. -
Page 3: Troubleshooting
Flush Valve Cartridge. It is not necessary to loosen the retainer clips. (See Figure 3) Remove the Flush Valve Cartridge using the handles of a pair of pliers. (See Figure 2). Turn the Flush Valve Cartridge counterclockwise until you can lift it out of the FLUSHMATE ® tank. - Page 4 Insert the Flush Valve Cartridge into the FLUSHMATE ® tank and thread it clockwise into place until one (1) black thread (on the FLUSHMATE tank) is ® showing above the Flush Valve Cartridge. (See Figure 5) Fully open the water...
-
Page 5: Points To Remember
Supply Shank. The recommended static pressure for the 503 Series is between 20 psi and 80 psi and for the 504 Series between 25 and 80 psi. Note:... - Page 6 (flushometer tank) operating system (the “unit”) to be free of defects in material and workmanship for a period of ten (10) years from the date of installation on original components and includes a lifetime limited warranty on the FLUSHMATE tank.
