OWNER'S MANUAL
FRENCH DOOR
REFRIGERATOR
Read this owner's manual thoroughly before operating the
appliance and keep it handy for reference at all times.
ENGLISH
LRMDS3006* / LRMVS3006* / LRMDC2306* / LRMVC2306* / LLMXS3006* /
LRMXS3006*
www.lg.com
MFL69497032
Copyright © 2020-2024 LG Electronics. All Rights Reserved
Rev.11_080124
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for LG LRMVS3006S.ASTCNA0
Summary of Contents for LG LRMVS3006S.ASTCNA0
- Page 1 Read this owner's manual thoroughly before operating the appliance and keep it handy for reference at all times. ENGLISH LRMDS3006* / LRMVS3006* / LRMDC2306* / LRMVC2306* / LLMXS3006* / LRMXS3006* www.lg.com MFL69497032 Copyright © 2020-2024 LG Electronics. All Rights Reserved Rev.11_080124...
-
Page 2: Table Of Contents
Ice and Water Dispenser In-Door Ice Bin Automatic Icemaker Storing Food Crisper Drawers Refrigerator Shelves InstaView Door-in-Door Door Bins Durabase Full-Convert Drawer 41 SMART FUNCTIONS LG ThinQ Application Smart Grid Function Smart Diagnosis Feature 46 MAINTENANCE Cleaning Air Filter Water Filter 51 TROUBLESHOOTING... -
Page 3: Read All Instructions Before Use
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE Safety Messages Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and follow all safety messages. - Page 4 IMPORTANT SAFETY INSTRUCTIONS • Do not bend or pinch the power cord excessively or place heavy objects on it. • When positioning the appliance, ensure the supply cord is not trapped or damaged. • Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance. Operation •...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS • Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer. • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. •...
- Page 6 IMPORTANT SAFETY INSTRUCTIONS Risk of Fire and Flammable Materials This symbol alerts you to flammable materials that can ignite and cause a fire if you do not take care. This appliance contains a small amount of isobutane refrigerant (R600a), which is combustible. When transporting and installing the appliance, care should be taken to ensure that no parts of the refrigerating circuit are damaged.
-
Page 7: Product Overview
PRODUCT OVERVIEW PRODUCT OVERVIEW Product Features The images in this guide may be different from the actual components and accessories, which are subject to change by the manufacturer without prior notice for product improvement purposes. Exterior † This feature is only available on some models. Control Panel Sets the refrigerator temperature and freezer temperature, the water filter condition and the dispenser mode. - Page 8 PRODUCT OVERVIEW Interior Standard Door : LLMXS3006* / LRMXS3006* Door-in-Door: LRMDS3006* / LRMDC2306*...
- Page 9 PRODUCT OVERVIEW InstaView Door-in-Door: LRMVS3006* / LRMVC2306* LED Interior Lighting Lights up the inside of the refrigerator. Air Filter Reduces odors inside the refrigerator compartment. In-Door Icemaker (Refrigerator) This is where ice is automatically produced and stored. Door Mullion Prevents the cold air in the refrigerator from escaping when the doors are closed. CAUTION •...
- Page 10 10 PRODUCT OVERVIEW Cheese & Butter and Condiment Bins Cheese & Butter and Condiment bins are specially designed for these items, making spreading butter and slicing cheese easier. Adjustable Refrigerator Shelf The refrigerator shelves are adjustable to meet individual storage needs. Folding Shelf Store taller items, such as gallon containers or bottles, by pushing the front half of the shelf underneath the back half of the shelf.
-
Page 11: Installation
INSTALLATION INSTALLATION Before Installing Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. Unpacking the Refrigerator Choosing the Proper Location Disassembling/Assembling Connecting the Water Line Leveling and Door Alignment WARNING •... -
Page 12: Choosing The Proper Location
12 INSTALLATION Unpacking the Refrigerator kPa), you can install a booster pump to compensate for the low pressure. WARNING • Use two or more people to move and install the refrigerator. Failure to do so can result in back Electricity injury or other injury. - Page 13 INSTALLATION Dimensions and Clearances • Check the dimensions of the appliance and the installation path to ensure there is sufficient room to move the refrigerator through doors or narrow openings. • If an opening is too narrow to fit the refrigerator through, remove the refrigerator doors. See Removing/ Assembling the Doors and Drawers in this manual.
-
Page 14: Removing/Assembling Handles
14 INSTALLATION Removing/Assembling Assembling Refrigerator Handles Handles If needed, reassemble the mounting These instructions are for models which ship with fasteners on the door with a 1/4 in. Allen the handles assembled. For models shipped with wrench. the handles disassembled, follow the instructions included in the handle package. -
Page 15: Removing/Assembling Doors And Drawers
INSTALLATION located at the bottom of the front side of the cover Place the handle on the door by fitting the with a flat-head screwdriver. handle footprints over the mounting fasteners and tightening the set screws with a 3/32 in. Allen wrench. •... - Page 16 16 INSTALLATION Rotate the hinge lever counterclockwise. Lift the top hinge free of the hinge lever latch CAUTION • When lifting the hinge free of the latch, be careful that the door does not fall forward. Rotate the hinge lever clockwise.
- Page 17 INSTALLATION • Be careful of sharp hinges on both sides of the drawer. • When you lay the drawer down, be careful not to damage the floor. • Do not sit or stand on the freezer drawer. • To prevent accidents, keep children and pets away from the drawer.
- Page 18 18 INSTALLATION Hold both sides of the door and remove it from the rails. Lower the door into its final position and insert the screws in the rails on both sides. Assembling the Freezer Drawer Pull out both rails simultaneously, until they are fully extended.
- Page 19 INSTALLATION Fit the hinge over the hinge lever latch Assembling the Full-Convert and slot it into place. Rotate the lever Drawer counterclockwise to secure the hinge. This feature is only available on some models. Grasp the door on each side and lower it into place on the rails.
-
Page 20: Connecting Refrigerator To Water Supply
20 INSTALLATION NOTE • Disassembling/Assembling the Water Lines Fit the hinge over the hinge lever latch and slot it into place. Rotate the lever clockwise and fasten the hinge. Collet Tube Insert line Clip • Gently press the collet and insert the tube until only one line shows on the tube. - Page 21 INSTALLATION • ½ in. or adjustable wrench. WARNING • Flat-blade and Phillips screwdrivers. • Connect to potable water supply only. • Two ¼ in. outer diameter compression nuts and 2 ferrules (sleeves) to connect the copper tubing to the shutoff valve and the refrigerator CAUTION water valve.
-
Page 22: Leveling And Door Alignment
22 INSTALLATION Packing Nut Tubing Clamp Shutoff Valve ¼ in. Tubing Compression Nut ¼ in. Compression Nut Ferrule (sleeve) Ferrule (sleeve) Refrigerator Connection Flush out the tubing into a bucket. • Flush out the tubing coming from the home water supply until the water is clear. Shut Turn the water on at the shutoff valve. - Page 23 INSTALLATION If the space between the doors is uneven, follow the instructions below to align the left door: Use the wrench (included with the owner's manual) to turn the nut in the door hinge to adjust the height. Turn the nut to the right to raise the door or to the left to lower it.
-
Page 24: Turning On The Power
24 INSTALLATION • The icemaker will not begin to operate until it CAUTION reaches its operating temperature of 15 °F (–9 °C) or below. It will then begin operation • The door is heavy. To avoid injury, use two or automatically if the icemaker power switch is in more people to lift and align the refrigerator the ON (I) position. -
Page 25: Operation
OPERATION OPERATION Before Use Checklist Clean the refrigerator. Clean the refrigerator thoroughly and wipe off all dust that accumulated during shipping. CAUTION • Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator. -
Page 26: Control Panel
26 OPERATION Control Panel Depending on the model, some of the following functions may not be available. The actual control panel may differ from model to model. Control Panel Features Ice Plus This function increases both ice making and freezing capabilities. Press the Ice Plus button to illuminate the icon and activate the function for 24 hours. - Page 27 Wi-Fi The Wi-Fi button, when used with the LG ThinQ app, allows the refrigerator to connect to a home Wi-Fi network. Refer to Smart Functions for information on the initial setup of the application. icon shows the status of the refrigerator's network connection. The icon illuminates when the refrigerator is connected to the Wi-Fi network.
-
Page 28: Sabbath Mode
28 OPERATION Press the Freezer button repeatedly to toggle between the 3 ICE and 6 ICE modes. After 5 seconds of idle time, the last mode set will be saved, and the display will return to normal. NOTE • For more ice, select the 6 ICE mode. For clearer ice, select the 3 ICE mode. NOTE Display Mode and InstaView Display Mode (For Store Use Only) •... -
Page 29: Ice And Water Dispenser
60 seconds OFF. This is also necessary if the refrigerator has not been used for a long time. • If ice or water dispenses unexpectedly, turn off the water supply and contact an LG Electronics Customer Information Center. Using the Measured Fill •... -
Page 30: In-Door Ice Bin
Detaching the In-Door Ice Bin CAUTION • Only qualified service personnel from an LG Electronics service center should disassemble or repair the icemaker. In-Door Ice Bin Gently pull the handle to open the ice Before Using the In-Door Ice Bin compartment. -
Page 31: Automatic Icemaker
OPERATION Before Using the In-Door Icemaker To remove the in-door ice bin, grip the front handle, slightly lift the bottom, and slowly pull out the bin as shown. NOTE • Ice is made in the automatic in-door icemaker and sent to the dispenser. The icemaker produces 70 - 182 cubes in a 24-hour period, depending on freezer compartment temperature, room temperature, number of... - Page 32 32 OPERATION NOTE CAUTION • The amount and shape of ice may vary according • Do not insert round ice into the in-door ice bin, to the environment (ambient temperature as it can damage the ice and water dispenser. around the appliance, frequency of the door being opened, amount of food stored in the appliance, water pressure, etc.).
-
Page 33: Storing Food
OPERATION • The icemaker water valve buzzes as the CAUTION icemaker fills with water. If the icemaker power button is in the ON position, it will buzz even if it • Do not overfill or pack items too tightly into door has not yet been hooked up to water. -
Page 34: Crisper Drawers
34 OPERATION • Heavy-duty aluminum foil NOTE • Plastic-coated paper • Do not store food with high moisture content • Non-permeable plastic wraps towards the top of the refrigerator. The moisture • Specified freezer-grade self-sealing plastic bags could come into direct contact with the cold air and freeze. -
Page 35: Refrigerator Shelves
OPERATION Insert the cover into the refrigerator with both hands and lower it onto the guides. Lift the front of the cover up with both hands until it detaches from the back wall of the cabinet, then pull it out. Line up the tabs on the Door-in-Door case with the slots on the door and push down until it snaps into place. - Page 36 36 OPERATION Using the Folding Shelf This feature is only available on some models. Store taller items, such as a gallon container or bottles, by pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf forward to return to a full shelf.
-
Page 37: Instaview
OPERATION To access the InstaView Door-in-Door compartment, lightly press the button on the right refrigerator door handle. InstaView This feature is only available on some models. InstaView Door-in-Door Knock twice on the glass to turn the LED light inside the InstaView on or off. The LED light turns off automatically after 10 seconds. - Page 38 38 OPERATION CAUTION • Empty the contents of EasyLift Bin before raising or lowering it to avoid personal injury or damage to the bin or its contents. • If the bin is not level after adjusting it, gently raise it until it clicks into place. Door-in-Door Case To open the Door-in-Door case, press on the area marked Pull to open.
-
Page 39: Door Bins
OPERATION The Durabase may differ depending on the model. WARNING • If the Durabase divider is removed, there is enough open space for children or pets to crawl inside. To prevent accidental child and pet Door Bins entrapment or suffocation risk, DO NOT allow children or pets to touch or go near the drawer. - Page 40 40 OPERATION for the drawer is on the right wall of the refrigerator interior. Refrigerator Mode To use the convertible drawer as a refrigerator, press the Select/Freezer button repeatedly to toggle through the four temperature settings. Store meat and seafood at 29 °F (-1 °C), cold drinks at 33 °F (1 °C), deli items and snacks at 37 °F (3 °C), and chilled wine at 41 °F (5 °C).
-
Page 41: Smart Functions
When Ice Plus is finished, you will receive a push message. Run the LG ThinQ application and sign in with • Smart Diagnosis your existing account or create an LG account to sign in. - Page 42 Wi-Fi button for 3 seconds to the party responsible for compliance could void temporarily turn it off. Run the LG ThinQ the user’s authority to operate the equipment. application and follow the instructions in the application to connect the appliance.
-
Page 43: Smart Grid Function
If the refrigerator receives a Demand Response LG Electronics will also provide open source code signal, the refrigerator will operate in Delay to you on CD-ROM for a charge covering the cost Appliance Load (DAL) or Temporary Appliance of performing such distribution (such as the cost of Load Reduction (TALR) mode. -
Page 44: Smart Diagnosis Tm Feature
Smart Grid mode. LG ThinQ application. When you override the Smart Grid function, the • Launch the LG ThinQ application and select the refrigerator ignores the Demand Response signal Smart Diagnosis feature in the menu. Follow and is no longer controlled by the utility company the instructions provided in the LG ThinQ until the next Demand Response signal is sent. - Page 45 SMART FUNCTIONS Hold the mouthpiece of your phone in front of the speaker that is located on the right hinge of the refrigerator door. Press and hold the Freezer button for three seconds while continuing to hold your phone to the speaker. After you hear three beeps, release the Freezer button.
-
Page 46: Maintenance
46 MAINTENANCE MAINTENANCE Cleaning Inside Walls • Allow the freezer to warm up so the cloth will not stick. WARNING To help remove odors, wash the inside of the • Use non-flammable cleaner. Failure to do so can refrigerator with a mixture of baking soda and result in fire, explosion, or death. -
Page 47: Water Filter
MAINTENANCE • Use replacement air filter: LT120F Press and hold the Fresh Air Filter button on the control panel for 3 seconds to reset the Rotate the filter cover counterclockwise to filter sensor. release the tabs, and remove the cover. Water Filter Before Replacing the Water Filter Remove the filter from the inside of the cover... - Page 48 Press and release the dispenser pad for cycles of 30 seconds ON and 60 seconds OFF. CAUTION • LG strongly recommends that you use LG- Remove the disposable water filter. authorized water filters to prevent water quality issues, water leakage and appliance malfunction.
- Page 49 MAINTENANCE Performance Data Sheet Model: LT1000P, LT1000PC, LT1000PCS NSF System Trade Name Code: MDJ64844601 The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system as specified in NSF/ ANSI Standard 42, Standard 53 and Standard 401.
- Page 50 NOTE • While the testing was performed under standard laboratory conditions, actual performance may vary. For replacement filters, visit your local dealer or distributor or search under "water filters" on the lg.com website. For further assistance, contact the LG Electronics Customer Information Center.
-
Page 51: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING FAQs Frequently Asked Questions What are the best temperature settings for my refrigerator and freezer? The default setting for the refrigerator is 37° Fahrenheit (3° Celsius). The default setting for the freezer is 0° Fahrenheit (-18° Celsius). Adjust these settings as necessary to keep food at desired temperatures. - Page 52 52 TROUBLESHOOTING Before Calling for Service Review this section before calling for service; doing so will save you both time and money. Cooling Problem Possible Cause & Solution Refrigerator is not The refrigerator control is set to OFF (some models). cooling or has no •...
- Page 53 TROUBLESHOOTING Problem Possible Cause & Solution Interior moisture Weather is humid. buildup. • Humid weather allows additional moisture to enter the compartments when the doors are opened leading to condensation or frost. Maintaining a reasonable level of humidity in the home will help to control the amount of moisture that can enter the compartments.
- Page 54 54 TROUBLESHOOTING Problem Possible Cause & Solution Refrigerator or Unit is installed in a hot location. Freezer section is too • The refrigerator should not be operated in temperatures above 110 °F (43 °C). warm. A large amount of food or hot food was added to either compartment. •...
- Page 55 TROUBLESHOOTING Problem Possible Cause & Solution Icemaker is not Reverse osmosis filtration system is used. making enough ice. • Reverse osmosis filtration systems can reduce the water pressure below the minimum amount and result in icemaker issues. (Refer to the Connecting the Water Line section.) Tubing connecting refrigerator to house supply valve is kinked.
- Page 56 56 TROUBLESHOOTING Problem Possible Cause & Solution Ice has bad taste or The ice storage bin needs to be cleaned. odor. • Empty and wash the bin (discard old cubes). Make sure that the bin is completely dry before reinstalling it. Icemaker is making Icemaker shutoff (arm/ sensor) is obstructed.
- Page 57 TROUBLESHOOTING Problem Possible Cause & Solution Water is not New installation or water line recently connected. dispensing. • Dispense 2.5 gallons of water (flush for approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 58 58 TROUBLESHOOTING Problem Possible Cause & Solution Water has bad taste Refrigerator was recently installed. or odor. • Dispense 2.5 gallons of water (flush for approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 59 TROUBLESHOOTING Problem Possible Cause & Solution The interior of the The refrigerator is located near a fire source, such as a fireplace, chimney, or candle. refrigerator is • Make sure that the refrigerator is not located near a fire source, such as a fireplace, covered with dust or chimney or candle.
- Page 60 During Wi-Fi setup, the app is requesting a password to connect to the product (on certain phones). • Locate the network name which starts with "LG" under Settings > Networks. Note the last part of the network name. - If the network name looks like LGE_Appliance_XX-XX-XX, enter lge12345.
- Page 61 Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG will, at its option, repair or replace the Product. This limited warranty is valid only to the original retail purchaser of the Product ("You") and applies only when purchased lawfully and used within the United States including U.S.
- Page 62 Or by mail: LG Electronics Customer Service P.O. Box 240007 Huntsville, AL 35813 ATTN: CIC PROCEDURE FOR RESOLVING DISPUTES: ALL DISPUTES BETWEEN YOU AND LG ARISING OUT OF OR RELATING IN ANY WAY TO THIS LIMITED WARRANTY OR THE PRODUCT SHALL BE RESOLVED EXCLUSIVELY THROUGH BINDING ARBITRATION, AND NOT IN A COURT OF GENERAL JURISDICTION.
- Page 63 Notice of Dispute. In the event you intend to commence an arbitration proceeding, you must first notify LG in writing at least 30 days in advance of initiating the arbitration by sending a letter to LG at LG Electronics, USA, Inc. Attn: Legal Department- Arbitration 111 Sylvan Avenue, Englewood Cliffs, NJ 07632.
- Page 64 (b) the date on which the product was purchased; (c) the product model name or model number; and (d) the serial number (the serial number can be found (i) on the product; or (ii) online by accessing https:// www.lg.com/us/support/repair-service/schedule-repair-continued and clicking on “Find My Model & Serial Number”).
- Page 65 JURY TRIALS ARE NOT PERMITTED. PLEASE SEE THE SECTION TITLED “PROCEDURE FOR RESOLVING DISPUTES” BELOW. Should your LG Refrigerator ("Product") fail due to a defect in materials or workmanship under normal and proper use, during the warranty period set forth below, LG Electronics Canada, Inc. ("LGECI") will, at its option, repair, replace or pro rate the Product upon receipt of proof of the original retail purchase.
- Page 66 (ASC), as determined by LG Canada. If your Product is located outside a 150 km radius from a ASC, as determined by LG Canada, it will be your responsibility to bring the Product, at your sole expense, to the ASC for in-warranty repair.
- Page 67 If you and LG are unable to resolve the dispute within 30 days of LG’s receipt of the Notice of Dispute, the dispute shall be resolved by binding arbitration in accordance with the procedure set out herein.
- Page 68 If you opt out, neither you nor LG can require the other to participate in an arbitration proceeding. To opt out, you must send notice to LG no later than 30 calendar days from the date of the first consumer purchaser’s purchase of the product by either (i) sending an e-mail to optout@lge.com, with the subject line: “Arbitration Opt Out;”...
- Page 69 LIMITED WARRANTY Conflict of Terms. In the event of a conflict or inconsistency between the terms of this Limited Warranty and the End User License Agreement (“EULA”) in regards to dispute resolution, the terms of this Limited Warranty shall control and govern the rights and obligations of the parties and shall take precedence over the EULA.
- Page 70 70 Memo...
- Page 71 Memo...
- Page 72 LG Customer Information Center Centro de Información al Cliente LG Centre de Service à la Clientèle de LG For inquiries or comments, Para consultas o comentarios, visite Pour des questions ou des commentaires, visit www.lg.com or call: www.lg.com o llame por teléfono: visitez www.lg.com/ca_fr ou appelez :...
