Plum WATER MacREJ 5 W Installation Manual

MacREJ 5 W
Water supply network
parameter data logger
Installation manual
Applies to the following firmware:
Program series (SV): S013.xx
Implicitly read the user manual, which contain all necessary information about appliance, including
safety information. This is only a supporting document, which includes only selected information,
useful during device installation. Installation manual is only an annex to the main document.
User manual along with information regarding safety and a template of EU conformity declaration is
available on website https://water.plum.pl/en/
link in QR code).
Safety
It is forbidden to open the housing of MacREJ 5 W in conditions that allow water (e.g. rain, snow) or dirt to enter the
device.
The manufacturer's declaration of the IP66 housing tightness class will be valid only if cables with appropriate diameters
for the cable bushings are used, the bushings are properly tightened, and ensuring proper placement of gasket and
tightening of the housing cover to the device casing.
Metal bushings of product and metal parts of its pressure sensors are galvanically connected. Device can be installed
as fully floating or bonded.
The use of MacREJ 5 W version with an integrated modem is only possible in areas where the GSM module does not
cause interference with other equipment (e.g. medical equipment).
The function and parameters of some inputs/outputs depend on the product version, details are given in user manual of
the device.
Powering from battery
The device is powered with lithium-thionyl batteries with nominal voltage of +3,6V, size D, in compliance with IEC 60086-1.
Any works with the battery can be done only by trained personnel.
It is recommended to use only battery types provided below:
•
LS 33600, manufactured by Saft Specialty Battery Group
•
EVE ER34615, manufactured by Eve Energy CO., LTD.
(using this battery environmental temperature should be in range of: Ta= -25°C..+50°C)
•
SL-2780, manufactured by Tadiran Batteries GmbH
There is also a backup battery concealed under the main board cover. Recommended types of backup batteries SAFT
LS14250 or FANSO ER14250H (for hardware H1.3.0) and GP Batteries CR1620 or RENATA Batteries CR1632 (for hardware
H1.8.0).
under Products / Data loggers / MacREJ 5 W section (direct
QR code link:
