- Page 1 NOVA GO SONIC USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS To obtain the PDF manual OVERVIEW Enter the following URL in your SPECIFICATIONS browser: https:/ /www.enya-music.com/ I/O PANEL pages/downloads-user-manual BODY PANEL GET TO KNOW YOUR NOVA GO SONIC DEVICES CONNECTION INSTALL APP APP INTERFACE 2 MANUAL... - Page 3 CONTENTS TONE PRESET SWITCHING SWITCH TONE PRESETS VIA APP TONE PRESET MANAGEMENT PRESET REPLACEMENT PRESET PARAMETER EDITING EFFECT TYPE SWITCHING TONE SAVING REPLACE STRINGS NECK ADJUSTMENT WARRANTY MANUAL 3...
-
Page 4: Overview
OVERVIEW Headstock Zero Fret Strings Frets Strap Button Neck Pickup Bridge Pickup Main Knob Saddle Pickup Selector Switch Volume Knob / Coil Switch Sound Hole I/O Panel 4 MANUAL... -
Page 5: Specifications
SPECIFICATIONS 970 mm 325 mm Model Nova Go Sonic Frets Round-End Metal MANUAL 5... - Page 6 Pick up Enya Custom Dual-Coil 628mm Scale Length Body Carbon Fiber Monocoque Construction Fretboard Carbon Fiber Monocoque Construction Bridge Carbon Fiber Monocoque Construction Dimensions 970mm*325mm*115mm Carbon Fiber & Zero Fret Design Strings D’Addario® EXL110 6 MANUAL...
- Page 7 Finish Satin Battery 7.4V/2600mAh Charging Power Wireless V5.0 Speaker Enya AR Tech, 10W stable, 20W peak power >94.2 dB Signal-to-Noise Ratio System Enya ES3 Smart Audio Weight 2.78 KG MANUAL 7...
-
Page 8: I/O Panel
I/O PANEL Type C Port Charging, data transfer. Output Jack (TS) 3.5mm Jack For connecting monitor headphones. 8 MANUAL... -
Page 9: Body Panel
BODY PANEL Neck Pickup Main Knob Volume Knob / Coil Switch Pickup Selector Switch Main Knob Hold to power on/off. Double-click for wireless pairing (blinking light ring), single-click to switch tones. Rotate to adjust speaker volume (not output). Volume Knob / Coil Switch Adjusts pickup output volume. - Page 10 (Position 2), or neck pickup for warm tones (Position 3). Neck Pickup Pickup Coil Switching: The Nova Go Sonic's dual-coil pickup operates in series (default) or parallel (pull knob). Parallel mode yields a sin- gle-coil-like tone with less noise.
-
Page 11: Get To Know Your
After powering on, the pickup signal is processed through the effects system before output. The Nova Go Sonic can also function as a traditional electric guitar. When turned off, connect it using a 6.35mm jack to output the pickup signal directly. -
Page 12: Devices Connection
DEVICE CONNECTION To charge your NEXG 2, please follow these instructions: 1. Connect the provided power adapter to the NEXG 2's charging port. Or place the NEXG 2 on the charging stand, and connect Monitor Headphones the adapter to stand’s charging port. 2. -
Page 13: App
After logging in as prompted, the sys- tem will then scan for nearby Enya smart audio devices. Choose to con- nect to the Nova Go Sonic for editing. If multiple Nova Go Sonic devices are nearby, for easier future connections, you can rename your Nova Go Sonic in the app. -
Page 14: App Interface
App Interface ② ① ③ ④ ⑤ ⑥ ❶ Menu Switching - Displays the current page. Click to access dif- ferent option pages. By default, the system enters the Guitar Tone Options upon startup. ❷Tone Preset Storage Groups (Banks) - Shows the currently active Bank. -
Page 15: Tone Preset Switching
Tone Preset Switching The Nova Go Sonic has four preset storage groups (Banks), each indicated by the main knob's light in green, blue, cyan, and purple. These can be switched by clicking the main knob. Within each group, there are four preset data (Presets), which can only be selected and switched through the app. -
Page 16: Switch Tone Presets Via App
Switch Tone Presets via App Click the upper circular area to change Banks. Tap the lower image area to select a Preset within the current Bank. Selected Banks and Presets will be highlighted. 16 MANUAL... -
Page 17: Tone Preset Management
Tone Preset Management ① ⑤ ② ③ ④ After selecting a Preset, you can edit its tone preset information: ❶ View the currently active Bank and Preset. ❷ Edit the effect parameters for the current Preset. ❸ Replace the current Preset with one from the cloud. ❹... -
Page 18: Preset Replacement
Preset Replacement In the Guitar Tones section, select a Preset file and click Replace to open the cloud tone interface. After entering the cloud tone library interface, you can choose be- tween Custom Tones and Official Tones. Click Replace to down- load your selection. -
Page 19: Preset Parameter Editing
Preset Parameter Editing In the Guitar Tones menu, select a preset and click Edit to adjust its parameters. Nova Go Sonic has six effects: Noise Reduction, Speaker Simulation, EQ, Modulation, Delay, and Reverb. Rotate the knob to adjust: clockwise to increase, counterclockwise to de- crease. -
Page 20: Effect Type Switching
Effect Type Switching When selecting certain effect modules, options appear in the top left, indicating multiple effect types available for that module. Switchable effect modules include Modulation (MOD) with choic- es of Chorus, Tremolo, and Vibrato; and Amplifier (AMP) with De- luxe (Clean) and SLO (Distortion) options. -
Page 21: Tone Saving
Tone Saving After adjusting the tone, use the save button in the top right corner to store the tone preset, replace the image, and rename it. If chang- es to the current Preset are detected, clicking the back button in the top left corner prompts a save confirmation. - Page 22 STRING REPLACEMENT Remove the rubber strap on the back of the body to access the string holes. Remove & install strings through the holes. 22 MANUAL...
- Page 23 Tighten the strings and wind them around the tuning knobs to complete the string replacement. CAUTION – replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium battery types); –...
-
Page 24: Neck Adjustment
NECK ADJUSTMENT The Nova Go Sonic's neck is made of than wood. However, prolonged ex - posure to certain environments may some users' preference for personal neck adjustment. FCC Compliance Statements This device complies with Part 15 of the FCC Rules. Operation is subject to the... -
Page 25: Warranty
LIMITED WARRANTY ENYA MUSIC, INC. WARRANTS ITS PRODUCT TO BE FREE FROM DE- FECTS IN MATERIALS AND WORKMANSHIP UNDER NORMAL USE FOR A PERIOD OF ONE YEAR FROM THE DATE OF ORIGINAL PUR- CHASE. DURING THE WARRANTY PERIOD, AND UPON PROOF OF PURCHASE, THE PRODUCT WILL BE REPAIRED OR THE PRODUCT WILL BE REPLACED WITH THE SAME OR SIMILAR MODEL. - Page 26 AFTER 30 DAYS OF DELIVERY, INTERNATIONAL SHIPPING COSTS FOR REPLACEMENT OR REPAIRS WILL NO LONGER BE COVERED UNDER THE WARRANTY. THE CUSTOMER SHALL NOT HAVE ANY CLAIM UNDER THIS WARRANTY FOR REPAIR OR ADJUSTMENT EXPENSES IF: • The product is purchased from anyone other than an authorized product deal- er or upon which unauthorized repair or service work has been carried out.
- Page 27 • Damage resulting from exposure to extreme temperatures, humidity, acts of nature, dry climates, or salt air climates. Failure to use a humidifier on the product will void your warranty if any cracking occurs. Warranty claims may not be considered if a quality humidifier is not used with your product while it is stored in its case or bag.
- Page 28 Enya Music, Inc. will repair the defective products, the cost of repairing is on the customer. The amount of repair cost is case by case. Enya Music, Inc. will notify the customer of the amount of the fixing fee.
- Page 29 ENYA MUSIC (CHINA) Qiuchang, Huiyang, Huizhou, Guangdong 516221 www.enyamusical.com ENYA MUSIC (USA) 6132 Westline Dr, Houston, TX 77036 www.enya-music.com...
