Product Diagram
Front View
Component
1
Status LED
2
DB-9 Serial Port
Serial Communication LED
3
Indicators
4
Factory Reset Button
5
Mounting Bracket Holes
To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support
2
3
5
4
• Refer to LED Chart
• Connect an RS-232 Serial Device
• Refer to LED Chart
• Resets the Serial Device Server to
factory defaults
• Refer to Factory Reset
• Install the DIN Rail Kit or Wall
Mounting Bracket using the included
Mounting Bracket Screws
• Two on each side and four on the
bottom of the Serial Device Server
4
1
Function
