User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPBIO320 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for inbody BPBIO320

Summary of Contents for inbody BPBIO320

  • Page 1 User’s Manual...
  • Page 2 InBody Co., Ltd. shall not be liable for any errors, incidental, or consequential damages that occurred by not complying with the content of the User’ s Manual. Visit our website (inbody.com) to view and download additional information about the InBody.

  • Page 3: Table Of Contents

    Table of Contents I. BPBIO320/320n Installation ....5 Product Components ........5 Operating Environment ......5 Installation Instructions ......5 Loading and Reloading Printer Paper (BPBIO320 only) ..........7 Replacing Cuff Cover .........8 Setup .............9 G. Precautions for Maintenance ....12 II. Blood Pressure Test ......13 Precautionary Steps ........
  • Page 4 Safety Symbols used in the User’s Manual. Failure to comply with safety Warnings and regulations can cause serious injury Warning or death. Failure to comply with safety precautions Caution can damage the equipment. Reading the notes can help you get the Note most out of your device.

  • Page 5: Bpbio320/320N Installation

    Open the BPBIO320/320n box, and remove the air BPBIO320/320n cushion (small size). Unfold the air cushion (large size) and take out the BPBIO320/320n from the box, and then remove the protective box. Take off the protective vinyl out of the BPBIO320/320n, and remove the packing material.
  • Page 6 Mount the Information Panel onto the BPBIO320/320n. Caution • Do not carry the equipment by holding the cuff. • Keep packing material to repack the BPBIO320/320n at a later time. Dispose of trash according to local laws and regulations. • Refer to the figure below when transporting the BPBIO320/320n.

  • Page 7: Loading And Reloading Printer Paper (Bpbio320 Only)

    Use the anti-theft groove to prevent theft. jam or damage the printer head. * Theft protection cable is sold separately. Turn the BPBIO320/320n on by pressing the power switch located on the back of the device. Paper cut with scissors Ripped paper Open the cover by pressing ‘PUSH’...

  • Page 8: Replacing Cuff Cover

    BPBIO320/320n Installation E. Replacing Cuff Cover Caution The cuff cover of the BPBIO320/320n should be replaced • The printer will not work if the paper is inserted incorrectly. periodically for sanitary purposes. Follow the guide below to replace the cuff cover.

  • Page 9: Setup

    Set values are automatically saved. Front Cover Note • Two cuff covers are provided with the BPBIO320/320n. (One is already mounted in the equipment.) Press and hold button for 2 seconds to return to the home screen.
  • Page 10 BPBIO320/320n Installation * The following is an example showing how to * The following is an example showing how to change a ‘manual output’ Automatic printing change the screen timeout duration. ➊ options. While on the home screen, press and hold ➊...
  • Page 11 The arithmetic mean of the second and the third mode setting measurements measurements One time measurement mode * Automatic printing options and Result sheet item are applicable only to BPBIO320, so they do not appear at BPBIO320n. * “QR Code” is registered trademark of DENSO WAVE INCORPORATED.

  • Page 12: Precautions For Maintenance

    * Today Count : 00002 * Total Count : 000075 • In the event of an incident related to cybersecurity, side effect or accident, contact InBody Customer Service. It should be reported to the manufacturer and competent authority. Total test counts Check the following before turning the equipment on.

  • Page 13: Blood Pressure Test

    • Test in a relaxed state. • User should not talk or move during the test. • The BPBIO320/320n uses the right arm. Test results may be Press button to start the test. inaccurate if the left arm is used.
  • Page 14 Blood Pressure Test * The user can check results by using ‘Check Blood The cuff is automatically released after completing the Pressure Result’ at the bottom right of the Information test. Wait for the cuff to fully loosen and pull out your Panel arm.

  • Page 15: Test Posture

    Sit as close as possible to the BPBIO320/320n * Be sure to place the elbow in the elbow groove before starting the test. * Remove thick clothes. Do not roll up sleeves.

  • Page 16: Iii.transportation And Storage

    Caution Place the large air cushion on the bottom of the packing box and place the BPBIO320/320n on it. Cover with the • When transporting the equipment alone, keep the device small air cushion and seal the box with tape.

  • Page 17: Transportation And Storage Environment

    Transportation and Storage Caution • When transporting the equipment alone, keep the device horizontal. C. Transportation and Storage Environment The BPBIO320/320n should be transported or stored under the following conditions. Temperatures range -20 to 70ºC Relative humidity 10 to 95% RH(No Condensation)

  • Page 18: Faq

    • Make sure the power cable (AC 250V 10A) provided by InBody is in use. Question: The device is not turning on. Cause: The fuse is blown. • Turn off the BPBIO320/320n, and replace the measures: fuse.

  • Page 19: Regarding The Test

    • The user may have tested without sufficient rest. Take the test after resting at least 5 minutes. • Do not talk or move during the test. * Blood pressure may vary throught the day. InBody recommends testing at different times of the day.
  • Page 20 Can results vary depending on the testing Question: environment and temperature? • The BPBIO320/320n can operate at 5 ~ Answer: 40ºC. However, if the examinee feels that the temperature is too low or high, the blood vessels expand or contract, which will affect the blood pressure results.

  • Page 21: Others

    V Others * The BPBIO320/320n was manufactured by the quality  Volume control knob control procedures of InBody Co., Ltd. InBody Co.,  RS232C (9-pin serial) connection terminal Ltd. complies with ISO9001 and ISO13485 which are international quality management systems.  A port used to connect a mercury monitor in order to...

  • Page 22: Product Classification

    Others D. Product Specifications Safety Symbols Danger: high voltage Test Oscillometric Instructions Warning / Caution Pressure: 0 to 300 mmHg Test range Pulse: 30 to 240 bpm Note Degree of Pressure: ± 2mmHg BF-type equipment precision Pulse: Within ± 1.5% Power on Systolic blood pressure, diastolic blood Test result...
  • Page 23 Others Temperature 5 ~ 40ºC(41 ~ 104°F), Operating Humidity 15 ~ 90% RH, environment Atmospheric pressure 70 ~ 106 kPa Temperature -20 ~ 70ºC(-4 ~ 158°F), Storage Humidity 10 ~ 95% RH(No Condensation), environment Atmospheric pressure 50 ~ 106 kPa * Specifications are subject to change without ntoice for purposes of product improvement.

  • Page 24: Emc Declaration

    Others E. EMC Declaration Basic EMC Operating Phenomenon Port tested Test Voltage Test level/requirement standard or test method mode 100 V, 50 Hz CISPR 11:2015 100 V, 60 Hz Mains terminal +A1:2016+A2:2019 Continuous AC Mains 120 V, 60 Hz Group 1, Class B disturbance voltage EN 55011:2016 operation mode...
  • Page 25 The [BPBIO320/320n] is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. Portable RF communications equipment should be used no closer than 30 cm (12 inches) to any part of the [BPBIO320/320n]. Otherwise, degradation of the performance of this equipment could result.
  • Page 28 1639 ©2023 InBody Co., Ltd. All rights reserved. IM-82-ENG-B-231227...
