Purpose: To describe mounting of DSC-8430 Flush Mount to Channel
The purpose of this manual is to describe general installation of DSC-8430 Flush Mount to Channel.
This manual should be used in conjunction with any instrument-specific installation guides. Please read
this manual and all instrument-specific installation material before installing or using this product.
Parts Reference
The following parts and hardware are included in this installation kit:
(
Hardware not shown)
Item #
Description
1
Flush Mount
2
Slide in Adapter Plate
3
M3 x 20mm SEMS Pan Head Machine Screw
4
.250 Nylon Spacer
Tools Required:
1/8" Hex Wrench (Provided)
Phillips Screw Driver (Not Provided)
Metal File or Similar (Not Provided)
Fukuda Denshi Flush Mount for DSC-8430
www.gcx.com
Installation Guide
Qty.
1
1
4
4
DU-FD-0033-04 Rev A 09/21/16 GCX Corp Page 1 of 3
1
2
