- Page 1 UHD 6G-SDI POV Camera UHD6G-200 O PE R AT I O N G U I D E Version 1.0 / April 2020 Reproduction of this manual, in whole or in part, by any means, is prohibited.
- Page 2 CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING PRECAUTION This symbol indicates that dangerous This exclamation point symbol is intended to alert the user to the presence of important operating and voltage consisting a risk of electric shock...
- Page 3 Warning continues 5. Do not install the unit in humid, dusty, or sooty locations. Doing so may cause fire or electric shock 6. If any unusual smells or smoke come from the unit, stop using the product. Immediately disconnect the power source and contact the service center.
- Page 4 UHD6G-200...
- Page 5 FEATURES • 4K UHD 1/2.5 Progressive Scan CMOS sensor captures sharp and vivid UHD video even under low light conditions. • Advanced digital imaging processor provides vivid and detailed images by utilizing Dynamic Range, Auto White Balance, and Noise Reduction. •...
- Page 6 EXPOSURE AUTO EXPOSURE Auto mode will adjust the exposure level automatically. *AE MODE AUTO SHUTTER Detailed fine tuning options are available under this menu. IRIS • AGC MAX : OFF, LOW, MIDDLE, HIGH, DMIN, DMID, DMAX “AGC MAX” sets the maximum gain value to control the video noise caused by AGC MAX HIGH SENS UP...
- Page 7 EXPOSURE AGC FIX EXPOSURE AGC FIX mode provides more detailed gain option. *AE MODE AGC FIX SHUTTER All other controls are tuned for the selected gain value. IRIS • AGC : AUTO, 0dB ~ 27dB, d2X ~ d9X AUTO AGC MAX HIGH Gain level can be set.
-
Page 8: White Balance
WHITE BALANCE WHITE BALANCE Auto trace white mode will adjust white balance within 1,900˜K ~ 11,000˜K temperature. *MODE • SPEED : 0 ~ 7 PUSH BLUE White balance adjust speed can adjusted. • OFFSET-B : 0 ~ 100 SPEED “OFFSET-B” adjusts Blue gain within the range of 0 to 100. OFFSET-B OFFSET-R •... - Page 9 WHITE BALANCE INDOOR WHITE BALANCE “INDOOR” mode will adjust white balance to indoor lighting conditions. *MODE INDOOR OUTDOOR PUSH “OUTDOOR” mode will adjust white balance to outdoor lighting conditions. BLUE SPEED OFFSET-B OFFSET-R RETURN MANUAL WHITE BALANCE “MANUAL” mode will adjust white balance manually. *MODE MANUAL •...
-
Page 10: Day & Night
DAY & NIGHT Adjust color or B&W setting from this menu. DAY & NIGHT • MODE : DAY(COLOR), NIGHT(B&W) *MODE DAY (COLOR) NIGHT COLOR Set camera to either color mode or B&W mode. COLOR BURST • NIGHT COLOR : ON, OFF RETURN When “NIGHT COLOR”... -
Page 11: Privacy Mask
PRIVACY Privacy zone can be setup from this menu. PRIVACY MASK *MODE MODE : ON, OFF TYPE SQUARE Enable “PRIVACY ZONE” ON or OFF. MASK NO. MASK 1 DISPLAY TYPE : SQUARE, POLYGON COLOR BLACK POLY PIXEL Select privacy zone shape. POSITION-X MASK NO : MASK1 ~ MASK8 POSITION-Y... - Page 12 EFFECT EFFECT Camera image control can be adjusted from EFFECT menu. LENS SHADING LENS SHADING : ON, OFF *GAMMA CORRECT Optical vignetting issue can be corrected from this menu. CONTRAST GAMMA CORRECTION OPTION BRIGHTNESS GAMMA CORRECT : ON, OFF (1.0) SATURATION *FRONT GM EN DEFAULT...
- Page 13 SPECIAL Camera special functions can be adjusted from SPECIAL menu. SPECIAL D ZOOM : ON, OFF ( Digital Zoom and PIP function can be enabled from this menu ) *DZOOM DEFOG • ZOOM CONTROL : RATIO, POSITION, RETURN DWDR Adjust the digital zoom ratio and position. MOTION DETECT BACKLIGHT Use LEFT / RIGHT button to adjust the ratio, then press select.
- Page 14 SPECIAL DEFOG : ON, OFF, AUTO DEFOG SETUP “DEFOG” menu improves foggy image. *STRENGTH • STRENGTH : 0 ~ 16 THRESHOLD AUTO LEVEL Change defog strength. RETURN • THRESHOLD : 0 ~ 3 Threshold value sets minimum sensitivity value for automatic defog control. Higher value makes defog-on control reluctant.
- Page 15 SPECIAL HLM : OFF, ON BACKLIGHT - HLM HLM can be adjusted. AREA *AREA DISPLAY • AREA DISPLAY : ON, OFF SIZE/POSITION HLM AREA DISPLAY can be turned ON or OFF. LEVEL BLACK MASK • SIZE/POSITION : SIZE, POSITION, RETURN DEFAULT Adjust BLC area window size.
- Page 16 SPECIAL DISPLAY FUNCTION : OFF, ON DISPLAY FUNCITON Adjust image display features from this menu. *FREEZE MIRROR MIRROR IMAGE EFFECT NEGATIVE • FREEZE : OFF, ON ROTATION Image freeze can be turned ON or OFF. PICTURE STYLE VIVID RETURN • MIRROR : OFF, MIRROR, V-FLIP, BOTH(H/V) Image mirror or flip can be operated. •...
- Page 17 SETUP Camera setup can be adjusted from this menu. SETUP CAM TITLE : OFF, ON *CAM TITLE RS485 Camera title can be turned ON or OFF. MENU COLOR RS-485 : FACTORY RESET SYSTEM INFO VISCA communication control can be adjusted. OUTPUT FORMAT 1080P60 RETURN...
-
Page 18: Specification
SPECIFICATION VIDEO LENS Image Sensor 1/1.7” Progressive CMOS Lens C/CS Mount Sensor Size Diagonal 9.93mm(17:9) (with 4K 3.6mm - 11mm varifocal lens) AUDIO INPUT Effective Pixels Horizontal: 4096, Vertical: 2160 Pixel Size 1.85 µm x 1.85 µm Input 3.5mm TRS Stereo Resolution 4096 x 2160, 3840 x 2160, Mic-in &... - Page 19 QUESTIONS Visit us: www.aidaimaging.com/support E-mail us: support@aidaimaging.com Give us a Call: Toll Free: 844.631.8367 Tel: 909.333.7421 Operating Hours: Mon-Fri 8:00am – 5:00pm PST...
- Page 20 Disposal of Old Appliances 1. When this crossed-out wheel bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately form the municipal waste stream in accordance to laws designated by the government or the local authorities. 3.
