THERAPY RANGE PRODUCTS
INSTRUCTIONS FOR USE
DOC No. 03-100-UM-UK
ISSUE 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ST1551 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seers Medical ST1551

Summary of Contents for Seers Medical ST1551

  • Page 1 THERAPY RANGE PRODUCTS INSTRUCTIONS FOR USE DOC No. 03-100-UM-UK ISSUE 4...
  • Page 2 This User Manual applies to the following Couches in the SEERS Medical Therapy Product Range. Therapy Hygiene Tables ST1551 (A,B,C), ST1561(A,B,C) , ST1651(A,B,C), ST 1661(A,B,C) Therapy 2 Section Couches ST2557, ST2567, ST2558, ST2568, ST2559, ST2569 Therapy 3 Section Couches ST3557, ST3567, ST3558, ST3568, ST3559, ST3569...
  • Page 3 INDEX 1. GENERAL INFORMATION – INTENDED USE, WARNINGS & CAUTIONS 2. HOW TO USE – a. WHEEL SYSTEM - b. ADJUSTABLE FOOT c. ADJUSTING THE HEIGHT OF THE COUCH d. ALTERING THE BACKREST & FOOT SECTION ANGLES e. ADJUSTMENT OF ARMS ON PLUS HEAD SECTION MODELS f.

  • Page 4: General Information

    1. GENERAL INFORMATION. CONGRATULATIONS on the purchase of your SEERS MEDICAL Product. If these operating instructions are adhered too, this product will provide many years of safe use. IF THESE INSTRUCTIONS FOR USE ARE NOT FOLLOWED - YOUR WARRANTY COULD BE INVALID! Always keep these Instructions for Use available for reference.
  • Page 5 WARNINGS! Warnings identify potential hazards which if not followed correctly, could result in serious injury, or possibly even death! • Ensure electric couches are not used in the presence of flammable gasses such as an anaesthetic agent. • DO NOT EXCEED the Maximum Safe Working Load of the product •...

  • Page 6: Adjustable Foot

    2. HOW TO USE. WHEEL SYSTEM Lever DOWN = Wheels ACTIVATED and Lever UP = Wheels RETRACTED and OFF WARNING! This Couch is not designed for patient transportation Ensure Wheels are retracted prior to patient transfer or treatment. Disconnect the electric lead prior to re-locating the couch, ensuring the lead is not trapped in the mechanism.
  • Page 7 LARGE MOBILE WHEEL DESIGN When close lock symbol Down: All castors locked Wheel Lever Horizontal: Castors un-locked When open lock symbol down – Directional steering castor engaged at rear of couch c. ADJUSTING THE HEIGHT OF THE COUCH Hydraulic Elevation (manually adjustable height couches) To elevate the couch, push the pedal downwards with your foot.
  • Page 8 1 way Hand Switch Linak 1 way Hand switch Timotion Raising the Couch Timotion footswitch 1. To elevate the couch, push the UP button on the hand or foot switch 2. Once the desired height is achieved release the button 3.
  • Page 9 d. ALTERING THE BACK REST & FOOT SECTION ANGLES To raise the backrest, simply grasp the release lever towards the upholstery and adjust the backrest to the angle desired. Releasing the lever automatically locks the section at that angle. To lower, grasp the lever again, and lower the backrest to the required angle.
  • Page 10 RAISING AND LOWERING THE POWERED MID SECTION (DRAINAGE MODELS) WARNING! Ensure Patient is secure, with not too much angle applied, so the patient is not tipped off the couch! Ensure patient entrapment will not occur when operating powered mid section Raising the Drainage Mid Section (Deluxe Drainage Models only) 1.

  • Page 11: Optional Accessories

    OPTIONAL ACCESSORIES SIDE SUPPORTS & RAILS WARNING! Children must not play with the couch at any time. Adequately supervise children in the proximity of the couch. Ensure the Side Support Rails are Fully Engaged into Socket prior to use To Raise the side support rail, simply lift and To Lower the side support rail, simply lift out rotate 180 degrees, and then engage fully of socket and rotate down 180 degrees to...

  • Page 12: Leg Supports

    UPPER LIMB SUPPORT 1. To adjust position of Arm Support Pad, undo the locking clamp on underside of pad anticlockwise. 2. Once loosened, move pad to desired position and re-tighten locking clamp to secure. 3. If height adjustment is required, undo the locking clamp on the vertical stem.
  • Page 13 H. APPROVED SEERS ACCESSORIES FOR THERAPY RANGE ONLY PDF format available in demmand 03-100-UM-UK ISSUE 4...

  • Page 14: Cleaning Instructions

    CLEANING INSTRUCTIONS WARNING! Disconnect the couch from the mains power supply prior to carrying out any cleaning or decontaminating. DO NOT SATURATE PRODUCT IF PRODUCT GETS SATURATED DURING CLEANING, THIS COULD ACCELERATE CORROSION, REDUCING PRODUCTS LENGTH OF SERVICE. Recommended Cleaning Method – SEERS Anti-Bacterial Cleaning Wipes The perfect solution for cleaning SEERS Examination Couches.
  • Page 15 Ink, Ball point pen, Denim, hard stains: Rub the stain by means of gentle circular movements with tissue dampened with 96°alcohol and water (1:1) After this rub the surface with gentle circular movement with tissue paper to dry it. Butter, oil, grease stains: Wipe excess butter, oil or grease off the surface with a clean 100% Cotton white dry cloth.

  • Page 16: Maintenance

    4. MAINTENANCE WARNING! Disconnect the couch from the mains power supply prior to carrying out any maintenance. All electrical maintenance should be performed by a suitably qualified person. BLUE or BROWN wires must not be connected to any earth terminal. Actions to be done by clinician Daily Weekly...
  • Page 17 Look for any visual signs of damage. Ensure all nuts, bolts and other fasteners are ✓ present and fitted where expected. If loose (can be undone by hand), re- tighten using suitable tools – but taking care to not over tighten as this could cause binding, juddering, identifiable by a likely creaking noise Check any accessories fitted to the couch, paying close attention to fasteners and moving ✓...

  • Page 18: Warranty

    W: www.seersmedical.com © SEERS MEDICAL Limited Manufactured in the UK by SEERS MEDICAL Limited. As part of our ongoing development programme SEERS MEDICAL Limited reserves the right to modify specifications and materials of this couch without prior notice. 03-100-UM-UK ISSUE 4...

  • Page 19: Troubleshooting

    6.TROUBLESHOOTING Fault Possible Cause Solution Electrical functions not working Mains cable has become disconnected, Locate control box and see whether the power light correctly either from the wall socket or the control is illuminated and that the lead is connected at both ends.
  • Page 20 7.TECHNICAL DATA – HYGIENE THERAPY TABLES Index ST1551 ST1561 ST1651 ST1661 Configuration Elevation Control Hydraulic Electric Hydraulic Electric Wheel System LMWD Overall Length (cm) Large A – 186cm, Medium B – 152cm or Small C – 130cm Width (cm) 65 as standard...
  • Page 21 TECHNICAL DATA – 3 SECTION THERAPY COUCHES Index ST3557 ST3567 ST3558 ST3568 ST3559 ST3569 Configuration Elevation Control Hydraulic Electric Hydraulic Electric Hydraulic Electric Overall Length (cm) Mid Section Length (cm) Head Length (cm) Foot Section Length (cm) Width (cm) 65cm or 70cm Minimum Height (cm) Maximum Height (cm) Safe Working Load &...
  • Page 22 TECHNICAL DATA –THERAPY DROP END COUCHES Index ST3556 ST3566 Configuration Elevation Control Hydraulic Electric Overall Length (cm) Mid Section Length (cm) Head Length (cm) Foot Section Length (cm) Width (cm) 65cm or 70cm Minimum Height (cm) Maximum Height (cm) Safe Working Load & 240 Kg (528lbs) Lifting Capacity 03-100-UM-UK...
  • Page 23 TECHNICAL DATA – DELUXE THERAPY COUCHES – STANDARD HEAD Index ST3347 ST3547 ST3347S ST3547S Configuration Elevation Control Electric Overall Length (cm) Mid Section Length (cm) Mid Section Angles 0° to +25° 0° to +25° Head Length (cm) Head Section Angles -25°...
  • Page 24 TECHNICAL DATA – DELUXE THERAPY COUCHES – BASIC HEAD Index ST3348 ST3548 ST3348S ST3548S Configuration Elevation Control Electric Overall Length (cm) Mid Section Length (cm) Mid Section Angles 0° to +25° 0° to +25° Head Length (cm) Head Section Angles -25°...
  • Page 25 TECHNICAL DATA – DELUXE THERAPY COUCHES – PLUS HEAD Index ST3349 ST3549 ST3349S ST3549S Configuration Elevation Control Electric Overall Length (cm) Mid Section Length (cm) Mid Section Angles 0° to +25° 0° to +25° Head Length (cm) Head Section Angles -25°...
  • Page 26 TECHNICAL DATA –THERAPY MAT TABLES Index ST5551 ST5561 ST5551W ST5561W ST5561L Configuration Elevation Control Hydraulic Electric Hydraulic Electric Electric Overall Length (cm) Width (cm) Minimum Height (cm) Maximum Height (cm) Safe Working Load & 250 Kg (550lbs) Lifting Capacity 03-100-UM-UK ISSUE 4...
  • Page 27 TECHNICAL DATA –BOBATH THERAPY COUCHES Index ST4552 ST4562 ST4542 ST4642 ST4552W ST4562W ST4542 ST4642W Configuration Elevation Control Hydraulic Electric Electric Electric Hydraulic Electric Electric with with with with with with with electric backrest manual manual electric electric manual manual backrest backrest backrest backrest...

  • Page 28: Electrical Information

    ELECTRICAL INFORMATION Electrical Data Control Box Linak Timotion Input 100 – 240V AC, 50/60Hz, 2.5 A 100 – 240V AC, 50/60Hz, 2.5 A IP Rating IPX6 washable IP54 Output 32V, 128VA Duty Cycle 10% max, 2 min ON / 18 min OFF Electrical Classification IEC 60101- Double Insulated Electrical Classification...
  • Page 29 Symbols Safe working load Double Insulated (Class II) Alternating current (a.c.) Manufacturer Total weight of the equipment Manufacturing date including its safe working load Complies with the European Caution/Warning Regulatory affair Refer to instructions For Use Serial number Type BF applied part. Model number Waste Electrical and Electronic Do not sit on the edge marked in...
  • Page 30 03-100-UM-UK ISSUE 4...
  • Page 31 03-100-UM-UK ISSUE 4...
  • Page 32 IP14 6LA t: +44 (0)1728 861590 f: +44 (0)1728 861868 info@seersmedical.com w: www.seersmedical.com © SEERS MEDICAL Limited 2020 Advena Limited. Tower Business Centre, 2 Flr. Tower Street, Swatar, BKR 4013 Malta. mark on this product demonstrates conformity with the MDD...
