SPLIT SYSTEM AIR CONDITIONER
INSTALLATION MANUAL
HCCI/O-48DC4
No. 0150543445
y This product must only be installed or serviced by qualified personnel.
Please read this manual carefully before installation.This appliance is filled with R32.
Keep this manual for future reference.
Original instructions
Contents
Advertisement
Table of Contents
Related Manuals for Haier HCCI/O-48DC4
Summary of Contents for Haier HCCI/O-48DC4
- Page 1 SPLIT SYSTEM AIR CONDITIONER INSTALLATION MANUAL Contents HCCI/O-48DC4 No. 0150543445 y This product must only be installed or serviced by qualified personnel. Please read this manual carefully before installation.This appliance is filled with R32. Keep this manual for future reference.
- Page 2 EUROPEAN REGULATIONS IMPORTANT INFORMATION REGA- CONFORMITY FOR THE MODELS RDING THE REFRIGERANT USED Contains fluorinated greenhouse gases All the products are in conformity with the following covered by the Kyoto Protocol European provision: - Low voltage Directive - Electomagnetic Compatibility ROHS The products are fulfilled with the requirements in the directive 2011/65/EU of the European parliament...
- Page 3 The air conditioner can not be discarded or scrapped Randomly If you need please contact customer service personnel of Haier to scrap in order to obtain the correct disposal methods. Reusable mechanical connectors and flared joints are not allowed indoor.
- Page 4 WARNING If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 5: Meaning Of Warnings And Symbols
It may also be used to alert against unsafe practices. Haier. NOTICE Safety considerations Indicates situations that may result in equipment or property-damage accidents only. - Page 6 „ Make sure that all wiring is secure, using the specified DANGER: DO NOT TOUCH PIPING AND wires and ensuring that external forces do not act on INTERNAL PARTS the terminal connections or wires. „ Incomplete connection or fixing may cause a fire. Do not touch the refrigerant piping, water piping „...
-
Page 7: Before Installation
„ Where corrosive gas, such as sulphurous acid gas, is NOTICE: Insulation resistance of the produced. compressor Corrosion of copper pipes or soldered parts may If, after installation, refrigerant accumulates in the cause the refrigerant to leak. compressor, the insulation resistance can drop, but if „... -
Page 8: Selecting Installation Site
Accessories - Do not climb, sit or stand on top of the unit. - Be sure that sufficient precautions are taken, in Check if the following accessories are included with the unit: accordance with applicable legislation, in case of See the figure below for the location of the accessories. refrigerant leakage. - Page 9 General „ For seacoast applications, block the unit from direct exposure to sea breeze by installing the unit behind a structure (such as a building) or a protective wall that is 1.5 times higher than the unit, leaving 700 mm of space between the wall and unit for air circulation.Consult an installation expert about taking anti-corrosion measures, such as removing salinity on the heat exchanger and applying a rust inhibitor more frequently than once a year.
-
Page 10: Precautions On Installation
5. Precautions on installation NOTICE If drain holes of the outdoor unit are covered by a mounting base or by floor surface, raise the unit in order to provide a free space of more than 130mm under the outdoor unit. A leg pitch1 B leg pitch2 1U125N... -
Page 11: Drain Pipe Disposal
„ Regarding the required air outlet space, position the When barriers exist above the unit units with consideration to the space required for the onsite refrigerant piping work as well. Consult your dealer if the work conditions do not match those in the drawings. -
Page 12: Necessary Tools And Materials
6.1. Necessary Tools and Materials Prepare the following tools and materials necessary for installing and servicing the unit. Necessary tools for use with R410A/R32(Adaptability of tools that are for use with R22 and R407C). 1. To be used exclusively with R410A/R32 ( Not to be used if used with R22 or R407C ) Tools/Materials Notes Gauge Manifol... - Page 13 6.2. Piping Materials Types of Copper Pipes (Reference) Maximum Operation Pressure Applicable Refrigerants 3.4MPa R22, R407C 4.15MPa R410A 4.3MPa y Use pipes that meet the local standards. Piping MaterialslRadial Thickness Use pipes made of phosphorus deoxidized copper. Since the operation pressure of the units that use R410A is higher than that of the units for use with R22, use pipes with at least the radial thickness specified in the chart below.
-
Page 14: Refrigerant Piping
Cautions on handling the service port NOTICE „ For new installations, use the standard pipe sizes. When using existiong pipes, size-up is allowed as „ Always use a charge hose equipped with a valve mentioned in the table above. depressor pin, since the service port is a Schrader Additional restrictions towards allowable pipe lengths, type valve. -
Page 15: Piping Connection Method
Precautions for refrigerant piping B: Sideways C: Backward „ Do not twist or crush piping. „ Be sure that no dust is mixed in piping. D: Downward E: Power supply cable outdoor and indoor connection cable „ „ Bend piping with as wide angle as possible. Cutting out the two slits makes it possible to install as „... - Page 16 „ If the temperature is higher than 30and the humidity NOTICE is higher than RH 80, then thickness of the sealing materials should be at least 20mm in ouder to avoid „ Do not purge the air with refrigerants. Use a condensation on the surface of the sealing.
-
Page 17: Charging Refrigerant
„ This unit requires additional charging of refrigerant INFORMATION according to the length of refrigerant piping connected at the site. After opening the stop valve, it is possible that the pressure in the refrigerant piping does not „ Make sure to charge the refrigerant in liquid state to rise. -
Page 18: Total Charging Weight Of The Refrigerant (After A Leak, Etc.)
10. Electrical wiring work WARNING „ All wiring must be performed by an authorized electrician. All components procured on the side and all elecrtic construction shall comply with the applicable legislation. DANGER: HIGH VOLTAGE. To avoid electrical shock, make sure to disconnect the power supply 1 minute or more before servicing the electrical parts. -
Page 19: Connecting Power Supply And Inter- Unit Wiring
„ Secure the electrical wiring with cable ties as shown Outdoor unit in the figure in 10.2 . terminal blocks „ Make sure no external pressure is applied to the 1U105S2SS1FA terminal connectors. 1U125S2SN1FA „ When installing the earth leakage circuit breaker make Power supply: 1U140S2SN1FA sure that it is compatible with the inverter (resistant to... -
Page 20: Test Operation
„ Form the wires and fix the cover fimmly so that the 11.1. Pre-run checks cover may be fit in properly. Items to check „ When you do not use a wire conduit, be sure to Electrical „ Is the wiring as mentioned on the protect the wires with vinyl tubes to revent the edge of wiring Inter- wiring diagram? - Page 21 11.3 Before Installing (Relocating) the Unit or Performing Electric Work CAUTION Ground the unit. Do not spray water on the air conditioners or immerse the air conditioners in water. Do not connect the grounding on the unit to gas pipes,water pipes, lightning rods, or the grounding „...
-
Page 22: Failure Diagnosis
11.4. Failure diagnosis OUTDOOR UNIT TROUBLE SHOOTING Error Malfunction Description Diagnosis and Analysis. Remark code EEPROM chip damaged or data wrong or related EEPROM malfunction Non-resumable circuit damaged. PIM (power intelligent module) Input over current occured been detected by Resumable hardware over current PIM’s hardware. - Page 23 Error Malfunction Description Diagnosis and Analysis Remark code AC power supply of the driver module get voltage lower DC voltage or AC voltage than 155VAC or driver module get high DC-BUS voltage Resumable lower than 180VDC. Indoor pipe temperature Tm over 63°C, error clear Indoor pipe temperature too within 3 minutes if temperature goes down and lower Resumable...
-
Page 24: Move And Scrap The Air Conditioning
12. Move and scrap the air conditioning y When moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support. y In the composition material ofair conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers are not more than 0.1% (mass fraction) and cadmium is not more than 0.01% (mass fraction).
